Safety, Operation, Maintenance
034606 Engine, LT15G13 2002
Used with
LT15G13
WARNING! Read and understand this
!
manual before using this machine.
G13 Engine
& Parts Manual
Safety is our #1 concern!
April 2010
rev.D
Form #884
rev. E6.07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G13 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wood-mizer G13

  • Page 1 G13 Engine Safety, Operation, Maintenance & Parts Manual 034606 Engine, LT15G13 2002 rev.D Safety is our #1 concern! April 2010 Form #884 Used with LT15G13 rev. E6.07 WARNING! Read and understand this manual before using this machine.
  • Page 2 Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2023 Wood-Mizer LLC Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any...
  • Page 3: Table Of Contents

    LT15 Rev. D4.00 - D7.00 ..........4-6 Engine Assembly ................... 4-8 LT15 Rev. A1.00 - D3.00...........4-8 Throttle/Clutch Assembly ..............4-10 LT15 G13/G15Rev. E1.00 - E6.09 ........4-10 Throttle/Clutch Assembly ..............4-12 LT15 Rev. D4.00 - D7.00 ........4-12 Throttle/Clutch Assembly ..............4-14 LT15 Rev.
  • Page 4: Section 1 Safety

    Safety SECTION 1 SAFETY This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer sawmill. Refer to the sawmill opera- ® tor’s manual and manufacturer's manual before attempting to operate this equipment.
  • Page 5: Section 2 Operation

    Operation Starting The Engine SECTION 2 OPERATION Starting The Engine DANGER! Ensure the blade is disengaged and all persons are out of the path of the blade before starting. Failure to do so will result in death or serious injury. DANGER! Operate your engine only in well ventilated areas.
  • Page 6: Section 3 Maintenance

    Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless otherwise instructed in this manual. Fol- low the manufacturer’s recommendations for dusty conditions. This manual only provides information about additional procedures or procedures to be per- NOTICE formed at different time intervals than found in the manufacturer's manuals.
  • Page 7: Miscellaneous Maintenance

    Maintenance Miscellaneous Maintenance Check the RPM with a tachometer every 200 hours of operation. Engine High End RPM Low End RPM 3750 1800 Before checking the RPM, make sure belt and brake strap tensions are correct (See Sawmill Maintenance). Check oil, fuel, and coolant levels. Ensure the throttle cable does not affect the engine RPM when the clutch handle is disengaged.
  • Page 8: Section 4 Replacement Parts

    Replacement Parts Engine Assembly SECTION 4 REPLACEMENT PARTS Engine Assembly LT15Rev. E1.00+ PART # DESCRIPTION COMMENTS QTY. P12393 Cover, Engine 034806 ENGINE ASSEMBLY, 13 HP KOHLER W/CLUTCH 014809 Engine, 13 HP Kohler #PA22519 014718 Filter, Kohler Air #47-083-01 014719 Pre-Cleaner, Kohler Air #52-083-01 036653 Filter, Kohler Oil #28-050-01-S Shorter Oil Filter 036653...
  • Page 9 Replacement Parts Engine Assembly PART # DESCRIPTION COMMENTS QTY. 016498 Muffler Kit, G13 Kohler 016106 Muffler, Kohler #12-068-39 Available in assemblies only. 016494 Gasket, Kohler Muffler #12-041-03 016497 Deflector, Kohler Flat #12-755-27 016495 Arrestor, Kohler Spark #12-189-02 016105 Guard, Kohler Muffler #12-314-11 No longer available (5/16).
  • Page 10: Engine Assembly

    Engine, 13 HP Kohler #PA22519 014718 Filter, Kohler Air #47-083-01 014719 Pre-Cleaner, Kohler Air #52-083-01 014717 Filter, Kohler Oil #52-050-02 016498 Muffler Kit, G13 Kohler 016106 Muffler, Kohler #12-068-39 Available in assemblies only. 016494 Gasket, Kohler Muffler #12-041-03 016497 Deflector, Kohler Flat #12-755-27...
  • Page 11 QTY. 016495 Arrestor, Kohler Spark #12-189-02 016105 Guard, Kohler Muffler #12-314-11 No longer available (5/16). No replacement part available from Kohler or Wood-Mizer. P12757 Plug, Kohler Spark #12-132-02 (Cham- pion #RC12YC) 014720 Filter, Kohler In-Line Fuel #25-050-02 051992 Switch, Kohler PHI Oil #25-099-24-S...
  • Page 12: Lt15Rev. A1.00 - D3.00

    Cover, Engine 014801 ENGINE ASSY, 13 HP KOHLER W/CLUTCH 014809 Engine, 13 HP Kohler #PA22519 014718 Filter, Kohler Air #47-083-01 014719 Pre-Cleaner, Kohler Air #52-083-01 014717 Filter, Kohler Oil #52-050-02 016498 Muffler Kit, G13 Kohler WM doc 11/28/23 Replacement Parts...
  • Page 13 Terminal, 1/4” 14-16 Ga Ring NI Loose Throttle and Clutch Parts Section 4.5 P10082 Hose, Oil Drain P04332 Cap, Oil Drain Hose 014810 Plate, G13 Engine Mount F05011-3 Washer, 3/8” SAE Flat F05011-4 Washer, 3/8” Split Lock F05007-7 Bolt, 3/8-16 x 1” Hex Head F05007-131 BOLT, 3/8-16 X 1 1/4”...
  • Page 14: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 G13/G15Rev. E1.00 - E6.09 PART # DESCRIPTION COMMENTS QTY. 034616 PLATE, THROTTLE CABLE BRACKET LT15G F05005-1 SCREW, 1/4-20 X 3/4 FT HEX HEAD F05010-69 NUT, 1/4-20 NYLON LOCK SPRING, EXTENSION 3/8 X 3...
  • Page 15 Replacement Parts Throttle/Clutch Assembly PART # DESCRIPTION COMMENTS QTY. BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 034612 F05012-16 PIN, 3/16 X 1 1/4 ROLL 034605 LINKAGE ASSEMBLY, W/BEARING 016486 Bushing, 5/8” ID x 7/8” OD x 1 1/8” Long Flanged Bronze F05010-35 NUT, 1/2-13 FREE HEX, ZINC F05011-9 WASHER, 1/2 SPLIT LOCK F05010-31...
  • Page 16: Lt15 Rev. D4.00 - D7.00

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 Rev. D4.00 - D7.00 PART # DESCRIPTION COMMENTS QTY. 016470 PLATE, BRAKE ACTUATOR F05006-11 BOLT, 5/16-24 X 1” HEX HEAD F05011-13 WASHER, 5/16” SPLIT LOCK NUT, 1/4-20 SWAGED F05010-21 F05011-11 WASHER, 1/4” SAE FLAT 016503 PIVOT WELDMENT, THROTTLE LT15 014818...
  • Page 17 Replacement Parts Throttle/Clutch Assembly PART # DESCRIPTION COMMENTS QTY. BUSHING, 5/8” ID X 7/8” OD X 1 1/4” LONG 016486 FLANGED BRONZE BUSHING, 3/4” ID X 1” OD X 1 1/8” LONG 016485 FLANGED BRONZE PIN WELDMENT, MOTOR PIVOT 016477 F05010-25 NUT, 3/8-16 SWAGED LOCK F05007-27...
  • Page 18: Lt15Rev. D3.00

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15Rev. D3.00 PART # DESCRIPTION COMMENTS QTY. 014825 HANDLE, THROTTLE/CLUTCH 014835 GRIP, 1/2” I.D. X 3” LONG HANDLE 014820 COLLAR, 1/2” I.D. X 7/8” O.D. LOCK P08060 BUSHING, SF1260-6 BRONZE 014821 BRACKET, THROTTLE/CLUTCH HANDLE MOUNT BRACKET, THROTTLE/CLUTCH HANDLE PIVOT 014837...
  • Page 19 Replacement Parts Throttle/Clutch Assembly PART # DESCRIPTION COMMENTS QTY. 014816 Clutch, LT15 w/Brake Available in assemblies only. Kit includes Clutch and Spring-Loaded Turnbuckle. Use to retrofit LT15 prior to Rev. D3.00. 016446 Turnbuckle Assembly, LT15 Spring-Loaded Clutch 016443 Turnbuckle, LT15 Clutch Available in assemblies only.
  • Page 20: Lt15Rev. A1.00 - D2.00

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15Rev. A1.00 - D2.00 PART # DESCRIPTION COMMENTS QTY. 014825 HANDLE, THROTTLE/CLUTCH 014835 GRIP, 1/2” I.D. X 3” LONG HANDLE COLLAR, 1/2” I.D. X 7/8” O.D. LOCK 014820 P08060 BUSHING, SF1260-6 BRONZE 014821 BRACKET, THROTTLE/CLUTCH HANDLE MOUNT 014837 BRACKET, THROTTLE/CLUTCH HANDLE PIVOT...
  • Page 21 Replacement Parts Throttle/Clutch Assembly PART # DESCRIPTION COMMENTS QTY. 014815 Rod End, 5/16-24 Male Left-Hand 014880 Turnbuckle, 2 3/4” Clutch F05010-28 Nut, 5/16-24 Hex P09814 Rod End, 5/16-24 Male Right-Hand Replaces 014814 supplied before 5/98 (duplicate parts). F05006-1 BOLT, 5/16-18 X 1” HEX HEAD GRADE 2 S09174 SPACER, 1.016”...
