G13 Engine
Safety, Operation, Maintenance
& Parts Manual
LT15
rev. A.00 - E8.13
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
April 2010
Form #884

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G13 and is the answer not in the manual?

Questions and answers

Related Manuals for Wood-mizer G13

Summary of Contents for Wood-mizer G13

  • Page 1 G13 Engine Safety, Operation, Maintenance & Parts Manual LT15 rev. A.00 - E8.13 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. April 2010 Form #884...
  • Page 2 Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any photographic, electronic, mechanical or other means or used in any information storage and retrieval system without written permission from Wood-Mizer 8180 West 10th Street Indianapolis, Indiana 46214...

  • Page 3: Table Of Contents

    Rev. E1.00+ Engine Assembly..................4-3 LT15 Rev. D4.00 - D7.00 Engine Assembly..................4-5 LT15 Rev. A1.00 - D3.00 Throttle/Clutch Assembly ..............4-7 LT15 G13/G15 Rev. E1.00+ Throttle/Clutch Assembly ..............4-9 LT15 Rev. D4.00 - D7.00 Throttle/Clutch Assembly ..............4-11 LT15 Rev. D3.00 Throttle/Clutch Assembly ..............4-13 LT15 Rev.

  • Page 4: About This Manual

    SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer ® sawmill. Refer to the sawmill operator’s manual and manufacturer's manual before attempting to operate this equipment.

  • Page 5: Operation

    1. Turn the run/stop switch to the RUN position. See Figure 2-1. FIG. 2-1 G13 2. Close the engine choke by moving the choke lever to the start position. Operation...
  • Page 6 Operation Starting The Engine 3. Pull the start rope slowly until you feel resistance, then pull the cord quickly to start the engine. Repeat with the choke opened slightly if necessary. NOTE: If the engine is hard to start with the throttle in the idle posi- tion, push the throttle swivel plate down slightly and retry.

  • Page 7: Maintenance

    Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless oth- erwise instructed in this manual. Follow the manufacturer’s recommendations for dusty conditions. IMPORTANT! This manual only provides information about additional procedures or procedures to be performed at different time intervals than found in the manufacturer's manuals.

  • Page 8: Cooling System

    Maintenance Cooling System Cooling System Wash the engine or brush off sawdust and debris every 50 hours of operation. Clean the grass screen, cooling fins, and external surfaces. Remove any dust, dirt or oil. See engine manual for further instructions. Air Filter &...

  • Page 9: Miscellaneous Maintenance

    Maintenance Miscellaneous Maintenance See Table 3-1. Engine High End RPM Low End RPM 3750 1800 TABLE 3-1 Before checking the RPM, make sure belt and brake strap tensions are correct (See Saw- mill Maintenance). Also check oil, fuel, and coolant levels. Make sure the throttle cable does not affect the engine RPM when the clutch handle is disengaged.

  • Page 10: Replacement Parts

    Replacement Parts Engine Assembly SECTION 4 REPLACEMENT PARTS Engine Assembly LT15 Rev. E1.00+ 150145 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. Cover, Engine P12393 ENGINE ASSEMBLY, 13 HP KOHLER W/CLUTCH 034806 Engine, 13 HP Kohler #PA22519 014809 Filter, Kohler Air #47-083-01 014718...
  • Page 11 Shorter Oil Filter 036653 required for LT15G13 Rev. E4.00 and later to avoid interference with up/down assist mechanism. Either filter can be used for previous revisions. No longer available (5/16). No replacement part available from Kohler or Wood-Mizer. Replaces S21486 1/4” x 1” key. S04124 always used in production.

  • Page 12: Engine Assembly

    Replacement Parts Engine Assembly Engine Assembly LT15 Rev. D4.00 - D7.00 150081 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. Cover, Engine P12393 ENGINE ASSY, 13 HP KOHLER W/CLUTCH 016517 Engine, 13 HP Kohler #PA22519 014809 Filter, Kohler Air #47-083-01 014718 Pre-Cleaner, Kohler Air #52-083-01 014719...
  • Page 13 Bushing, QT x 1 016513 BELT, BX82 DRIVE 016505 WASHER, 3/8” SAE FLAT F05011-3 WASHER, 3/8” SPLIT LOCK F05011-4 BOLT, 3/8-16 X 1” HEX HEAD F05007-7 No longer available (5/16). No replacement part available from Kohler or Wood-Mizer. Replacement Parts G1397doc091819...

  • Page 14: Lt15 Rev. A1.00 - D3.00

    Replacement Parts Engine Assembly Engine Assembly LT15 Rev. A1.00 - D3.00 150058E DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. Cover, Engine P12393 ENGINE ASSY, 13 HP KOHLER W/CLUTCH 014801 Engine, 13 HP Kohler #PA22519 014809 Filter, Kohler Air #47-083-01 014718 G1397doc091819 Replacement Parts...
  • Page 15 Use muffler kit 016498 for service. Kit includes gasket, deflector and spark arrestor. Muffler 016106 no longer a sellable item (3/00). Spark arrestor 016495 replaces 016146 originally supplied prior to 3/00 (duplicate parts). No longer available (5/16). No replacement part available from Kohler or Wood-Mizer. Replacement Parts...

  • Page 16: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 G13/G15 Rev. E1.00+ 150098F DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. PLATE, THROTTLE CABLE BRACKET LT15G 034616 SCREW, 1/4-20 X 3/4 FT HEX HEAD F05005-1 NUT, 1/4-20 NYLON LOCK...

  • Page 17: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly BOLT, 1/4-20 X 1/2” HEX HEAD F05005-15 NUT, 1/4-20 SWAGED F05010-21 BUSHING, 5/8” ID X 7/8” OD X 1 1/8” LONG FLANGED BRONZE 016486 BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 034612 PIN, 3/16 X 1 1/4 ROLL F05012-16 LINKAGE ASSEMBLY, W/BEARING 034605 Bushing, 5/8”...

  • Page 18: Lt15 Rev. D4.00 - D7.00

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 Rev. D4.00 - D7.00 11 11 150080B DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. PLATE, BRAKE ACTUATOR 016470 BOLT, 5/16-24 X 1” HEX HEAD F05006-11 WASHER, 5/16” SPLIT LOCK F05011-13 NUT, 1/4-20 SWAGED F05010-21...
  • Page 19 Replacement Parts Throttle/Clutch Assembly HANDLE, LT15 CLUTCH 016487 PIN, 3/16 X 1 1/4” ROLL F05012-16 BUSHING, 5/8” ID X 7/8” OD X 1 1/4” LONG FLANGED BRONZE 016486 BUSHING, 3/4” ID X 1” OD X 1 1/8” LONG FLANGED BRONZE 016485 PIN WELDMENT, MOTOR PIVOT 016477...

  • Page 20: Throttle/Clutch Assembly

    Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 Rev. D3.00 150058-2 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. HANDLE, THROTTLE/CLUTCH 014825 GRIP, 1/2” I.D. X 3” LONG HANDLE 014835 COLLAR, 1/2” I.D. X 7/8” O.D. LOCK 014820 BUSHING, SF1260-6 BRONZE P08060 BRACKET, THROTTLE/CLUTCH HANDLE MOUNT...
  • Page 21 Replacement Parts Throttle/Clutch Assembly CLUTCH/TURNBUCKLE KIT, LT15 SPRING-LOADED 016514 Clutch, LT15 w/Brake  014816 Turnbuckle Assembly, LT15 Spring-Loaded Clutch 016446 Turnbuckle, LT15 Clutch 016443  Plunger, LT15 Clutch Turnbuckle 016444 Spring, 3/4” OD x 3” Long x .095” Wire Compression 016492 Ring, 3/4”...
  • Page 22 Replacement Parts Throttle/Clutch Assembly Throttle/Clutch Assembly LT15 Rev. A1.00 - D2.00 150058-1B DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. HANDLE, THROTTLE/CLUTCH 014825 GRIP, 1/2” I.D. X 3” LONG HANDLE 014835 COLLAR, 1/2” I.D. X 7/8” O.D. LOCK 014820 BUSHING, SF1260-6 BRONZE P08060...
  • Page 23 Replacement Parts Throttle/Clutch Assembly BOLT, 5/16-18 X 1 1/2” HEX HEAD GRADE 5 FULL THREAD F05006-76 TURNBUCKLE ASSEMBLY, LT15 CLUTCH  014934 Rod End, 5/16-24 Male Left-Hand 014815 Turnbuckle, 2 3/4” Clutch 014880 Nut, 5/16-24 Hex F05010-28 Rod End, 5/16-24 Male Right-Hand P09814 BOLT, 5/16-18 X 1”...

  • Page 24: Index

    INDEX maintenance air cooling system fuel filter miscellaneous RPM adjustments parts list engine assembly throttle/clutch 4-7, 4-9, 4-11, 4-13 starting G1397doc091819 Index...
