G18/G19 Engine
Safety, Operation, Maintenance
& Parts Manual
065192 Engine Module, LT15G19 rev. G
Safety is our #1 concern!
March 2011
Form #1744
Used with LT15s revision E8.13
LT15W
A1.14
G18 engines were re-designated G19 on
1/30/2015 per ECN 20372 to match the actual
rating of the engine.
WARNING! Read and understand this
!
manual before using this machine.
Advertisement
Table of Contents
Related Manuals for Wood-mizer G18
Summary of Contents for Wood-mizer G18
- Page 1 Safety is our #1 concern! March 2011 Form #1744 Used with LT15s revision E8.13 LT15W A1.14 G18 engines were re-designated G19 on 1/30/2015 per ECN 20372 to match the actual rating of the engine. WARNING! Read and understand this manual before using this machine.
- Page 2 Active Patents assigned to Wood-Mizer, LLC Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to research, innovation, development, and design. Learn more at: woodmizer.com/patents ©2021 Wood-Mizer LLC Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any...
-
Page 3: Table Of Contents
Table of Contents Section-Page SECTION 1 ABOUT THIS MANUAL SECTION 2 OPERATION Starting The Engine ................2-1 SECTION 3 MAINTENANCE Safety ..................... 3-1 Cooling System ..................3-1 Air Filter & Pre-Cleaner ................ 3-1 Fuel Filter....................3-2 Battery....................3-2 RPM Adjustments .................. 3-2 Miscellaneous Maintenance.............. -
Page 4: About This Manual
SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer sawmill. Refer to the sawmill oper- ® ator’s manual and manufacturer's manual before attempting to operate this equipment. -
Page 5: Operation
Operation Starting The Engine SECTION 2 OPERATION Starting The Engine DANGER! Ensure the blade is disengaged and all persons are out of the path of the blade before starting. Failure to do so will result in death or serious injury. DANGER! Operate your engine only in well ventilated areas. -
Page 6: Maintenance
Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless otherwise instructed in this manual. Fol- low the manufacturer’s recommendations for dusty conditions. IMPORTANT! This manual only provides information about additional proce- dures or procedures to be performed at different time intervals than found in the manufacturer's manuals. -
Page 7: Fuel Filter
Maintenance Fuel Filter Replace the air filter (cleaner) every 200 hours of operation. Replace the pre-cleaner (element wrapper) every 2000 hours of operation. Fuel Filter Replace the fuel filter every 100 hours of operation or as required for engine performance. Battery Check the battery electrolyte level every 50 hours of operation. -
Page 8: Miscellaneous Maintenance
Maintenance Miscellaneous Maintenance Miscellaneous Maintenance Inspect the spark plugs every 100 hours of operation. Remove any deposits and adjust gap if necessary. See engine manual for further information. Review the manufacturer's engine manual for maintenance intervals. WM doc 8/17/21 Maintenance... -
Page 9: Replacement Parts
Replacement Parts Fuel Tank SECTION 4 REPLACEMENT PARTS Fuel Tank LT15 Rev. E8.07+ 150244C DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. TRAY ASSEMBLY, LT15 FUEL TANK 103815 Weldment, Fuel Tank Tray 103802 Cover, Fuel Tank 103867 Tank, 5 Gallon Low Pro EPA Fuel 103878 Grommet, Shut Off... -
Page 10: Lt15 Rev. E8.04 - E8.06
Replacement Parts Fuel Tank Fuel Tank LT15 Rev. E8.04 - E8.06 150236-2 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. TANK ASSEMBLY, 6 GALLON GAS SERVICE 074643 Tank, Gas 076478 Fitting, 1/4” NPT Male Quick Disconnect 015583 FITTING, FEMALE QUICK DISCONNECT BARB 015582... -
Page 11: Lt15 Rev. E4.03 - E8.03
Replacement Parts Fuel Tank Fuel Tank LT15 Rev. E4.03 - E8.03 3H0415C DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. TANK ASSEMBLY, 5-GALLON RED GASOLINE A12285 Tank, 5-Gallon Red Fuel P12167 Pickup, 9" Fuel P12172 Cap, 3 or 5-Gallon Fuel Tank P09683 Fitting, 1/4"... -
Page 12: Engine Assembly
Replacement Parts Engine Assembly Engine Assembly 150199 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. Engine Assembly, LT15 G19 065191 Engine, 19HP Kohler CH620-3088 016899 Filter, Kohler Air 006907 Pre Cleaner, Kohler 006931 Starter, Kohler Engine KH# 25 098 21S 061371 Plug Spark, Kohler RFI #25 132 14-S 061417... - Page 13 Bolt, 3/8-16 x 3/4” Hex Head Grade 5 F05007-118 Nut, 3/8-16 Self-Locking Hex F05010-19 Belt, 2/3VFL900 Drive 047751 CONVERSION KIT, LT15G15 TO G18 (REQ’D TO CONVERT FROM G15 TO G18) 065379 Wheel Assembly, LT15 3V Drive 036657 Engine Assembly, LT15 Gas 18hp 065191...
-
Page 14: Throttle Assembly
Replacement Parts Throttle Assembly Throttle Assembly LT15G18 Rev. E6.09 - E7.00 150098F DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. PLATE, THROTTLE CABLE BRACKET LT15G 034616 SCREW, 1/4-20 X 3/4 FT HEX HEAD F05005-1 NUT, 1/4-20 NYLON LOCK F05010-69 SPRING, EXTENSION 3/8 X 3 014818... - Page 15 Replacement Parts Throttle Assembly LINKAGE, THROTTLE LT15D&G 034818 BOLT, 1/4-20 X 1/2” HEX HEAD F05005-15 NUT, 1/4-20 SWAGED F05010-21 BUSHING, 5/8” ID X 7/8” OD X 1 1/8” LONG FLANGED BRONZE 016486 BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 034612 PIN, 3/16 X 1 1/4 ROLL F05012-16 LINKAGE ASSEMBLY, W/BEARING 034605...
- Page 16 Replacement Parts Throttle Assembly LT15G18/19 Rev. E7.01+ 150201C 21 22 DESCRIPTION PART # QTY. ( Indicates Parts Available In Assemblies Only) KNOB, 5/8-11 BALL P04211 HANDLE, LT15 CLUTCH 016487 SCREW, 3/8-16 X 3/8 SOCKET HEAD CUP PT SET F05007-68 ACTUATOR WELDMENT, THROTTLE LT15D&G 034815 LINKAGE, THROTTLE LT15D&G 034818...
- Page 17 Replacement Parts Throttle Assembly BUSHING, 1 X 1 1/4 X 3/4 FLG BRONZE P737 BRAKE/CLUTCH ASSEMBLY, LT15 065874 Arm Weldment, Clutch/Brake LT15 065873 Bolt, 3/8-16 x 2 Hex Head Gr5 F05007-124 Nut, 3/8-16 Hex Nylon Lock F05010-10 Block, LT15 Brake 016488 Screw, 10-24 x 1”...
