G14 Engine
Safety, Operation, Maintenance
& Parts Manual
LT15S
rev. A1.00 - A1.03
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
November 2017
Form #2307

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G14 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wood-mizer G14

  • Page 1 G14 Engine Safety, Operation, Maintenance & Parts Manual LT15S rev. A1.00 - A1.03 Safety is our #1 concern! Read and understand all safety information and instructions before oper- ating, setting up or maintaining this machine. November 2017 Form #2307...
  • Page 2 Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by any photographic, electronic, mechanical or other means or used in any information storage and retrieval system without written permission from Wood-Mizer 8180 West 10th Street Indianapolis, Indiana 46214...
  • Page 3: Table Of Contents

    Table of Contents Section-Page SECTION 1 ABOUT THIS MANUAL SECTION 2 OPERATION Starting The Engine................2-1 SECTION 3 MAINTENANCE Safety......................3-1 Cooling System ..................3-2 Air Filter & Pre-Cleaner.................3-2 Fuel Filter ....................3-2 Miscellaneous Maintenance ..............3-2 SECTION 4 REPLACEMENT PARTS Engine Assembly..................3-3 Clutch Assembly ..................3-5 INDEX Table of Contents WMdoc091819...
  • Page 4: About This Manual

    SECTION 1 ABOUT THIS MANUAL This manual is provided as a supplement to the equipment manufacturer’s manuals. This manual provides information specific to the use of this equipment on the Wood-Mizer ® sawmill. Refer to the sawmill operator’s manual and manufacturer's manual before attempting to operate this equipment.
  • Page 5: Operation

    Operation Starting The Engine SECTION 2 OPERATION Starting The Engine DANGER! Ensure the blade is disengaged and all persons are out of the path of the blade before starting. Failure to do so will result in death or serious injury. DANGER! Operate your engine only in well ventilated areas.
  • Page 6 Operation Starting The Engine For more information, see the engine manufacturer’s operation manual. ENGINE SHUTOFF 1. Disengage the clutch handle to stop the blade if necessary. 2. Move the throttle control to slow or idle position. Stop the engine. 3. Close the fuel shut-off valve. WM doc 9/18/19 Operation...
  • Page 7: Maintenance

    Maintenance Safety SECTION 3 MAINTENANCE Refer to the manufacturer’s manual for maintenance intervals and procedures unless oth- erwise instructed in this manual. Follow the manufacturer’s recommendations for dusty conditions. IMPORTANT! This manual only provides information about additional procedures or procedures to be performed at different time intervals than found in the manufacturer's manuals.
  • Page 8: Cooling System

    Maintenance Cooling System Cooling System Wash the engine or brush off sawdust and debris every 50 hours of operation. Clean the grass screen, cooling fins, and external surfaces. Remove any dust, dirt or oil. See engine manual for further instructions. Air Filter &...
  • Page 9: Replacement Parts

    Replacement Parts Engine Assembly SECTION 4 REPLACEMENT PARTS Engine Assembly 150260-1 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. COVER, ENGINE P12393 ENGINE ASSEMBLY, LT15G14 START 110052 Engine, 14HP Kohler X200-1201 Deflector, Kohler 14HP Exhaust 110187 Plate, LT15 Start Drive Guard 110188 Washer, 3/8 Flat SAE F05011-3...
  • Page 10 Replacement Parts Engine Assembly Key, 1/4” X 1 11/16” S04124 Sheave, BK55QT 016512 Kit, Air/Precleaner Filter 17 883 03-S1 061330 Filter, Fuel Tank Fill 17 050 20-S 061331 Filter, Engine Fuel 25 050 21-S1 061332 Plug, Spark 25 132 19-S 061333 BOLT, 3/8-16X2 3/4 HH GR5 F05007-206...
  • Page 11: Clutch Assembly

    Replacement Parts Clutch Assembly Clutch Assembly 150260-2 DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY. KNOB, 5/8-11 BALL P04211 HANDLE, LT15 CLUTCH 016487 BUSHING, 5/8 ID X 7/8 OD X 1 1/8 LONG FL BRONZE 016486 COLLAR, 5/8 ID LOCK P05035 BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 065572...
  • Page 12 Replacement Parts Clutch Assembly Idler, 4" O.D. x 3/8 Bore 034602 Bolt, 3/8-16 x 2-3/4” Hex Head Gr5 Full Thread F05007-230 Washer, 3/8 Flat F05011-3 Nut, 3/8-16 Swaged Lock F05010-25 Spring, Idler Arm LT15/D/E/G 034810 Screw, 10-24 x 5/8” FSHC F05004-282 Plate, Brake Adjustment 065872...
  • Page 13: Index

    INDEX maintenance air cooling system fuel filter miscellaneous parts list clutch engine assembly starting Index WMdoc091819...
