PROOFER OVEN
WITH TOUCH SCREEN
CONTROLS (TSC)
Models:
TSC-6/18
CAUTION:
WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning
TSC-3/9
Please read this manual completely before attempting
to install, operate or service this equipment
This manual is Copyright © 2021 Duke Manufacturing Co. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
trademark of the Duke Manufacturing Co.
Installation and
Operation Manual
B A K IN G C E N T E R
P/N 512792
REV K 11/08/2021
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Duke TSC-6/18
Summary of Contents for Duke TSC-6/18
- Page 1 WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning This manual is Copyright © 2021 Duke Manufacturing Co. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered P/N 512792 trademark of the Duke Manufacturing Co.
-
Page 2: Table Of Contents
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls TABLE OF CONTENTS INTRODUCTION ..........................4 IMPORTANT SAFETY INSTRUCTIONS ..................5 SPECIFICATIONS ..........................6 MAIN FEATURES ..........................8 INSTALLATION ..........................9 OVEN/PROOFER START-UP ......................13 CHANGE TEMPERATURE UNITS .................... - Page 3 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls...
-
Page 4: Introduction
Touch Screen Controls INTRODUCTION The Duke TSC (Touch Screen Control) Proofer Oven was developed in response to the Customer’s need for uniform baking capabilities and to provide consistently high, quality just-baked bread. The Duke Proofer Oven utilizes Duke’s unique directional convection airflow technology that provides even heat distribution and a uniform bake without the need for turning pans during the bake cycle. -
Page 5: Important Safety Instructions
Do not use corrosive chemicals, water jet equipment, or other pressurized liquid spraying equipment to clean this unit. • This equipment should be serviced by qualified personnel only. Contact the nearest Duke authorized service facility for adjustment or repair. •... -
Page 6: Specifications
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls IMPORTANT SAFETY INSTRUCTIONS (continued) the unit. • Turn off external mains supply disconnect and allow unit to cool down before servicing or performing maintenance. • The procedures in this manual may include the use of chemical products. You must read the Material Safety Data Sheets before using any of these products. - Page 7 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls SPECIFICATIONS (continued) Compliance Declaration - TSC Proofer Oven with Touch Screen Control Standard: UL197 File: KNGT.E17421 Standard: CSA-C22.2 No. 109 File: KNGT7.E17421 Standard: ANSI / NSF 4 File: TSQT.E157479...
-
Page 8: Main Features
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls MAIN FEATURES LOW VOLTAGE LIGHTING SYSTEM 12V HALOGEN LAMP 10WATT MAX COOL TOUCH AIR- CONVECTION OVEN WASH DOOR 3 SHELVES TOUCH SCREEN CONTROL PANEL HIGH LIMIT PROTECTOR CIRCUIT BREAKER... -
Page 9: Installation
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls INSTALLATION using properly rated all poles mains protection, all UNPACKING UNIT poles mains disconnects, safety ground earthing, Inspect the shipping carton and/or container, and shall be a minimum of 48" (1.2 meter) long carefully noting any exterior damage on the delivery to allow the equipment to be moved for cleaning. - Page 10 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls INSTALLATION THIS RESTRAINING DEVICE MUST ALWAYS BE CONNECTED WHEN 1. This unit can be converted to other mains THE APPLIANCE IS IN SERVICE. supply configurations by Duke Manufacturing DISCONNECT ONLY FOR SERVICING approved service personnel.
- Page 11 O rings are continuous pressure conditions. in place, then lift up into filter head and rotate cartridge 1/4 turn counter clockwise until it The two main components of the Duke backflow comes to a complete stop. preventer system are: •...
- Page 12 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls INSTALLATION OF WALL-BRACKETS NOTE: Verify interconnections and function prior to installing optional wall brackets 1. Mount the Wall Mounting Brackets with screws provided with the Proofer Oven. 2. Extend the Wall Mounting Bracket towards the wall by sliding it through the slot provided but do not tighten the screws.
-
Page 13: Oven/Proofer Start-Up
2. Turn power on to the unit by using the circuit (3 short chirps) when the oven and/or proofer breaker on the right side of the unit. reach the ready state. Your Duke Proofer Oven is now ready to operate. 3. Verify that the touch screen illuminates upon If there are any problems, call the service power up. -
Page 14: Change Temperature Units
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls SPECIAL FUNCTIONS – PIN Number Entry CHANGE TEMPERATURE UNITS (F ˚ to C ˚) CENTIGRADE MODE **** PIN CODE Now Disabled SPECIAL FUNCTIONS – PIN Number Entry PIN CODE... -
Page 15: Programing Controls
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls PROGRAMMING CONTROLS SELECT OVEN PROFILE TO EDIT SPECIAL FUNCTIONS – PIN Number Entry BREAD BREAD 3 COOKIES BREAD 4 PIN CODE BREAD 2 BREAD 5 EXIT ENTER CLEAR EXIT Figure 11: Oven Profile Recipe Screen 3. - Page 16 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls EDIT PROFILE NAME {1} SELECT PROOFER PROFILES TO EDIT BREAD 60 MINUTES 60 MINUTES 20 MINUTES PROOFER DRY OUT 60 MINUTES < < > < > SAVE CANCEL EXIT...
- Page 17 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls...
-
Page 18: Revert To Factory Default Recipes
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls REVERT TO FACTORY DEFAULT RECIPES OVEN PROOFER 1. Press and hold the OVEN button for Approx 5 seconds or until the Special Functions Screen BREAD 60 MINUTES opens. COOKIES 20 MINUTES SPECIAL FUNCTIONS –... - Page 19 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls 2. Remove USB dust cap. USB Download Started 1 Download File(s) Found Processing DAILY_~1.SCR Figure 26: File Upload Screen 5. When Complete, the unit beeps once and reverts to the Oven/Proofer Main Menu screen.
-
Page 20: Proofer Operating Instructions
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls PROOFER OPERATING INSTRUCTIONS 2. Once the Proofer recipe has been selected PROOFER and the display has changed to the START buttons, the proofer's humidity should be 60 MINUTES visually verified before loading. -
Page 21: Oven Operating Instructions
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls OVEN OPERATING INSTRUCTIONS PROOFER – 60 MINUTES OVEN 1:00 ADD 5 MIN BREAD TEMP 105ºF COOKIES BREAD 2 0:00:00 0:39:59 BREAD 3 START BTM BREAD 4 BREAD 5 Figure 33: Oven Controls Screen Figure 32: Proofer Timer Screen 1. - Page 22 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls OVEN - BREAD OVEN - BREAD 14:00 ADD 1 MIN TIME 14:00 TEMP 350ºF TEMP 350ºF BAKE CYCLE 11:35 START PROGRESS BAR CANCEL RECIPE Figure 36: Oven Add 1 Min Button...
-
Page 23: Care And Cleaning
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls CARE AND CLEANING PROOFER 60 MINUTES WARNING 20 MINUTES OVEN & PROOFER INTERIOR AND RACKS 60 MINUTES ARE VERY HOT AND COOL SLOWLY. ALLOW TO COOL BEFORE HANDLING. 20 MINUTES... -
Page 24: Troubleshooting
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls TROUBLESHOOTING PROBLEM 1. Oven does not heat with oven switch in the ON position and Oven Temperature not set at 0°. a. Are oven indicator lights on? Observe Oven Fan. Go to “b”. -
Page 25: Wiring Diagram
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls WIRING DIAGRAM WIRING DIAGRAM TSC 6/18 & TSC 3/9 P.N. 512773 REV. E Humidity Sensor Oven Lights Proofer BLK 25 Lights Oven Temp. BLK 23 BLU 25 Touch Screen... -
Page 26: Wire Diagram For 2Nd Generation Units
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls WIRE DIAGRAM BELOW IS FOR UNITS THAT HAVE BEEN UPGRADED TO GENERATION 2. +12V CAN-TX CAN-RX COIL COIL COIL COIL BLK 1 RED 2 WHT 3 S ECONDARY S ECONDARY... -
Page 27: Customer Assistance
Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls CUSTOMER ASSISTANCE To aid in reporting this unit in case of loss or theft, please record below the model number and serial number located on the unit. We also suggest you record all the information listed and retain for future reference. - Page 28 Owner's Manual for DUKE TSC Proofer Oven with Touch Screen Controls Duke Manufacturing Co. Phone: 314-231-1130 Toll Free: 1-800-735-3853 2305 N. Broadway www.dukemfg.com Fax: 314-231-5074 St. Louis, MO 63102...
