Duke TSC-6/18M Maintenance Manual

Proofer oven with touch screen controls (tsc)

Hide thumbs Also See for TSC-6/18M:

Installation and operation manual (28 pages)

Installation instructions (4 pages)

Service manual (48 pages)

Table Of Contents

Quick Links

Download this manual

PROOFER OVEN

WITH TOUCH SCREEN

CONTROLS (TSC)

Models:

TSC-6/18M

IMPORTANT INFORMATION, READ BEFORE USE.

Reproduction without written permission is prohibited. Duke is a registered

MAINTENANCE MANUAL

TSC-3/9M

PLEASE SAVE THESE INSTRUCTIONS.

trademark of the Duke Manufacturing Company.

Duke Manufacturing Company

2305 N. Broadway

St. Louis, MO 63102

Phone: 314-231-1130

Toll Free: 1-800-735-3853

Fax: 314-231-5074

www.dukemfg.com

MAINTENANCE BY QUALIFIED,

TRAINED PERSONNEL ONLY

P/N 120086

REV E 6/8/2017

Table of Contents

Need help?

Do you have a question about the TSC-6/18M and is the answer not in the manual?

Questions and answers

Summary of Contents for Duke TSC-6/18M

Page 1 TSC-3/9M IMPORTANT INFORMATION, READ BEFORE USE. PLEASE SAVE THESE INSTRUCTIONS. This manual is Copyright © 2013 Duke Manufacturing Company. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered trademark of the Duke Manufacturing Company. Duke Manufacturing Company 2305 N.
Page 2 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls...
Page 3: Table Of Contents
Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................4 OVEN/PROOFER START-UP .....................6 PROGRAMMING CONTROLS ....................7 CARE AND CLEANING .......................10 DOOR ADJUSTMENTS AND GASKET MAINTENANCE ...........14 TROUBLESHOOTING .......................21 PARTS LIST AND ILLUSTRATIONS ...................22...
Page 4: Important Safety Instructions
Do not use corrosive chemicals, water jet equipment, or other pressurized liquid spraying equipment to clean this unit. • This equipment should be serviced by qualified personnel only. Contact the nearest Duke authorized service facility for adjustment or repair. •...
Page 5 INSTALLATION OF WATER FILTER Install new filter by removing sanitary cap from top The two main components of the Duke backflow of cartridge, insure two black O-rings are in place, then lift up into filter head and rotate cartridge...
Page 6: Oven/Proofer Start-Up
3. Have a qualified service technician or sound (3 short chirps) when the oven and/ electrician connect the oven to the power or proofer reach the ready state. Your Duke supply. Proofer Oven is now ready to operate. 4. Turn power on to the unit with the power If there are any problems refer to the Trouble switch on the left side of the unit.
Page 7: Programming Controls
Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls PROGRAMMING CONTROLS To access the SPECIAL FUNCTIONS, touch 2. Touch the button for the recipe you want to edit (i.e. BREAD button on the Main Tool Bar. NOTE: The 6 oven recipes are listed in...
Page 8 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls 5. Touch the button to save the 4. To edit the recipe name, touch the changes and return to the RECIPE EDIT button for the EDIT RECIPE NAME screen.
Page 9 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls CONFIG (CONFIGURATION S) FILES (FILE MANAGEMENT) 1. Touch the button and then enter pin 1. Touch the button and then enter pin code 2 3 4 5 and Touch the...
Page 10: Care And Cleaning
Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls CARE AND CLEANING WEEKLY CLEANING INSTRUCTIONS WARNING 1. Clean Proofer. Turn the proofer off and PROOFER OVEN INTERIOR AND allow elements to cool. Remove the bottom RACKS ARE VERY HOT AND COOL panel (remove screw).
Page 11 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls Annual Cleaning Instructions 3. The Cool-Touch door has two window panes. The inner window can be easily separated CAUTION from the outer window for cleaning. This is achieved by unlatching two clips and rotating the inner window on its hinges.
Page 12 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls D. Remove old filter by rotating cartridge to G. Remove and flush strainer screen with the left (facing back of cabinet) slowly until warm water. pressure starts to release, stop and let pressure and excess water drain through pressure release hose.
Page 13 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls 2. Clean Opti-Mist proofer nozzle screen. Proofer Oven With Proofer Oven Optional Backflow Without Optional A. Remove nozzle assembly by depressing Backflow Preventer latch on quick-connect fitting and pull Preventer nozzle out toward fan blade.
Page 14: Door Adjustments And Gasket Maintenance
Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls DOOR ADJUSTMENTS & GASKET MAINTENANCE 5. Use the six screws to fill the unused hinge WARNING screw holes on the front of the oven. 6. Remove the latch strike plate from the front REVERSING OVEN DOOR SWING of the oven and move it to the other side.
Page 15 When the door swing is reversed this drip channel must be replaced with a new channel that has the slope in the proper direction. Contact Duke Manufacturing Service for a new drip channel before changing door swing direction.
Page 16 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls PROOFER DRIP CHANNEL REVERSAL: 1. Follow the directions for removing the door from the Reversing Oven Door section. When the door is off you can then replace the drip channel.
Page 17 If the door gasket is damaged or compressed permanently, it should be replaced. Call Duke Manufacturing Co. at 800-735-3853 to order a new gasket before making adjustments.
Page 18 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls 3. Adjust the door position by moving the door 4. To check the adjustment, close the door frame in or out to seal any gaps between with a currency bill between the gasket and the gasket and the oven.
Page 19 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls 2. Clean the groove with a screwdriver or COOL-TOUCH DOOR INFORMATION AND CLEANING INSTRUCTIONS other flat-bladed tool to remove any dirt or gasket pieces. The Cool-Touch door has two window panes.
Page 20 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls 2. Unlatch the bottom clip. BULB MOUNTING DETAILS Turn counter-clockwise. Lamp Holder Remove bulb cover. Assy. G4 12V 10W (Max.) Lamp Flat Lens Gasket - 12V Halogen Figure: Unlatch Bottom Clip...
Page 21: Troubleshooting
Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls TROUBLESHOOTING PROBLEM 1. Oven does not heat with oven switch in the ON position and Oven Temperature not set at 0°. a. Are oven indicator lights on? Observe Oven Fan. Go to “b”.
Page 22: Parts List And Illustrations
Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls PARTS LIST AND ILLUSTRATIONS Duke TSC Proofer Oven Exploded View...
Page 23 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls ITEM # PART # DESCRIPTION 512836 Caster, swivel 512835 Caster, locking w/brake 600374 Kit, Drip pan 155977 Housing, drip edge – left hinged door 155979 Housing, drip edge – right hinged door...
Page 24 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls Control Panel Exploded View ITEM # PART # DESCRIPTION 120007 Panel Mount USB 512568 Buzzer 120011 Power Supply Board 120030 TSC Input/Output Board 600309 TSC Proofer Oven Controller Replacement Kit...
Page 25: Wiring Diagram
Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls WIRING DIAGRAM BLK 1 TSC–6/18M WIRE DIAGRAM Baking Center BLK 13 ORN 4 120087 Rev. B RED 1 BLK “C” HEAT OVEN RED 2 YEL 3 BLK “B” OPTION...
Page 26 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls...
Page 27 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls...
Page 28 Maintenance Manual for DUKE TSC Proofer Oven with Touch Screen Controls Duke Manufacturing Co. 2305 N. Broadway St. Louis, MO 63102 Phone: 314-231-1130 Toll Free: 1-800-735-3853 Fax: 314-231-5074 www.dukemfg.com...
