Summary of Contents for DMP Electronics XTLN-WIFI

  • Page 1 INST ALLA TION GUIDE XTLN-WIFI PANEL...
  • Page 2: Fcc Notice

    MODEL XTLN-WiFi INSTALLATION GUIDE FCC NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Wireless Key Fobs and Outputs 14.1 Description ..........6 Flash Load Button 15.1 Description ..........7 Listed Compliance Specifications 16.1 Introduction ...........7 16.2 Use Marking ...........7 16.3 NFPA 72 ..........7 16.4 Types Of Service ........7 16.5 Bypass Reports ........7 16.6 Battery Standby ........7 Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 4 ANSI/UL 985 NFPA 72 Specifications 19.1 Bell Output Definition ......8 19.2 Household System ........8 19.3 Wireless External Contact ......8 19.4 Wireless Supervision Time .......8 19.5 Test Frequency ........8 19.6 Wired Modules ........8 Listings and Approvals ......10 Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 5: Panel Specifica Tions

    Failing to follow the caution note can cause damage to the equipment or improper operation of one or more components in the system. Compliance Instructions For applications that must conform to a local authorities installation standard or a National Recognized Testing Laboratory certificated system, please see the Listed Compliance Specifications section near the end of this guide for additional instructions. Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 6: System Components

    Fixed temperature and rate-of-rise heat detector *1184 Carbon Monoxide Detector Carbon Monoxide detector. Interface Module *738Z Z-Wave Interface Module Provides connection for Z-Wave modules. Keypads 7800 Series LCD keypads Allows you to control the panel from various remote locations. Connect up to four 7872 or 7873 keypads to the keypad bus using terminals 7, 8. 9, and 10. 9000 Series LCD keypads Allows you to control the panel from various remote locations using 9000 Series Wireless Keypads. * These devices have not been investigated and shall not be used in listed installations Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 7: Installation

    OBSERVE POLARITY 1. Using 22 AWG wire, connect the panel PWR (J2) first terminal (+) to the positive terminal on the power supply. 2. Connect the panel PWR (J2) second terminal (-) to the negative terminal on the power supply. 3. Plug the power supply into a 120 Volt AC, 60Hz dedicated outlet not controlled by a switch. Model 372-500 DC Plug-in Power Supply Use 22 AWG for Wire Exits for DC Power Supply connection Power Supply Figure 2: DC Power Supply Connection Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 8: Standby Battery

    3. Loosen the top PCB snaps. 4. Lean the panel PCB forward and lift out from the bottom PCB snaps. 5. Remove and properly dispose of the used battery. Caution: Risk of fire, explosion, and burns. Do not disassemble, heat above 212°F (100°C), or incinerate. Properly dispose of used batteries. 6. Place the new battery into the XTLN-WiFi housing base with the battery wires directed toward the bottom right corner. See Figure 4. 7. Set the XTLN-WiFi PCB into the bottom snaps and press into the top snaps to secure in place. 8. Plug the battery into the panel connector (J7). Battery Supervision The panel tests the battery once every hour when DC power is present. This test occurs 15 minutes past each hour and lasts for five seconds. A load is placed on the battery and if the battery voltage is low, a low battery is detected. If DC power has failed, a low battery is detected any time the battery voltage falls below 3.7V. Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 9: Programming Connection

    A locking 4-pin header (PROG) is provided to connect a keypad when using a DMP Model 330 Programming Cable. This provides a quick and easy connection for programming the XTLN-WiFi panel. After programming is complete, remove the keypad. On-Board 1100 Series Wireless 11.1 Wireless Antenna The XTLN-WiFi Wireless Antenna is integrated into the circuit board. The XTLN-WiFi built-in wireless receiver operates with DMP 1100 Series transmitters. See section 3.1 for a list of accessory devices. 11.2 Wireless LED Operation Green (TX): The green LED flashes every time the receiver transmits (32 times per second). If the panel is reset, or the panel is powered off, the green LED is off. Under normal operation, the green LED flashes constantly with no interruption or change. Yellow (RX): The yellow LED flashes every time the XTLN-WiFi receives a message from a programmed wireless transmitter. When a message is sent by a transmitter, typically by pressing or releasing the tamper switch, the yellow LED should flash indicating that the XTLN-WiFi received a message from the transmitter. If the LED never flashes, the transmitter is not getting through to the XTLN-WiFi. This could be because of a misprogrammed serial number or the transmitter is too far away. Under normal operation, the yellow LED flashes at every trip of every wireless transmitter and when the transmitters perform their periodic check-in. It is not unusual for this LED to stay off for many minutes at a time when no transmitters are communicating. Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 10: Wireless Zones

    Information programming as needed. The defaults are provided as a programming convenience to help reduce installation time. Wireless Key Fobs and Outputs 14.1 Description XTLN-WiFi panels provide 8 wireless key fob or output addresses numbered 31 to 34 and 41 to 44. A default name is provided as a programming convenience to help reduce installation time. The default names are described in the XTLN-WiFi Programming Guide (LT-1237) and can be changed in Output Information or Zone Information programming as needed. Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 11: Flash Load Button

    ANSI/UL 1023 17.1 Bell Cutoff The bell cutoff time cannot be less than 4 minutes. 17.2 Entry Delay The maximum entry delay used must not be more than 45 seconds. 17.3 Exit Delay The maximum exit delay used must not be more than 60 seconds. 17.4 Wireless External Contact When used, the External Contact of 1101, 1102, or 1105 transmitters must be programmed Normally Closed. 17.5 Wireless Supervision Time The Zone Information Supervision Time cannot be set to 0 (zero). Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 12 An alarm sounding device must be installed indoors so that it is clearly heard in all sleeping areas. 19.3 Wireless External Contact When used, the External Contact of 1101, 1102, or 1105 must be programmed Normally Closed. See the XTLN-WiFi Programming Guide. 19.4 Wireless Supervision Time The Zone Information Supervision Time must be 3 minutes for fire devices. See the XTLN-WiFi Programming Guide. 19.5 Test Frequency The Test Frequency option must be programmed to send a report at least once every 30 days. 19.6 Wired Modules Modules that connect to the PROG header, such as the 738Z, must not be used since the battery standby time will be reduced below the 24 hour minimum. Digital Monitoring Products XTLN-WiFi Installation Guide...
  • Page 13 This page intentionally left blank...
  • Page 14: Listings And Approvals

    Listings and Approvals ANSI/SIA CP-2010 False Alarm Reduction FCC WiFi Module Approvals FCC ID: XM5-SM2144SMT Industry Canada: 8516A-SM2144SMT FCC Wireless Approvals FCC Part 15 ID: CCKPC0117 Industry Canada: 5251A-PC0117 Underwriters Laboratories (UL) Listed ANSI/UL 985 Household Fire Warning ANSI/UL 1023 Household Burglar ANSI/UL 1610 Central Station Burglar 800-641-4282 IN TRU SIO N • F IRE • AC C ESS • NET WOR KS www.dmp.com 2500 North Partnership Boulevard Designed, Engineered and Springfield, Missouri 65803-8877 Assembled in the USA...
