- Page 1 Inst alla tIon GuIde Xt lIte™ Panel...
-
Page 2: Installation Guide
MODEL XTL INSTALLATION GUIDE FCC NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 3 t able of Contents Panel Specifications Power Supply .........1 Communication ........1 Keypads ..........1 Number of Zones ........1 1.5 Enclosure Specifications ......1 Introduction 2.1 System Configurations ......2 Caution Notes .........2 Compliance Instructions ......2 System Components Accessory Devices ........3 Installation 4.1 Mounting the Enclosure ......4 Primary Power Supply DC Input ..........4 Secondary Power Supply Standby Battery ........5...
- Page 4 t able of Contents Household Burglar-Alarm System Units ANSI/UL 1023 15.1 Bell Cutoff ..........9 15.2 Entry Delay ..........9 15.3 Exit Delay ..........9 15.4 Wireless External Contact ......9 15.5 Wireless Supervision Time .......9 15.6 Wireless Audible Annunciation ....9 15.7 Panel location .........9 15.8 Test Frequency ........9 Central Station Burglar Alarm Units...
-
Page 5: Power Supply
Panel sPeCIfICa tIons Panel Specifications Power Supply Input: 12 VDC Standby Battery: 3.7 VDC Lithium All circuits inherent power limited Communication Built-in Cellular communication to DMP Model SCS-1R Receivers. Cellular Service is required before using the XTL for signal transmission. The XTL panel comes with a SIM card ready for activation with SecureCom Wireless, LLC. More information is available at www.securecomwireless.com. Keypads You can connect up to 4 alphanumeric 9000 Series wireless keypads. Number of Zones • XTL has 28 wireless initiating zones numbered 1-28 • Zone numbers 31 to 34 and 41 to 44 can support 1100 Series Key Fobs or DMP wireless output modules Enclosure Specifications The XTL panel ships in a plastic enclosure with a user’s guide and programming sheet. Size Color 5.58” W x 3.75” H x 1” D White (W) Digital Monitoring Products XTL Installation Guide... -
Page 6: System Configurations
IntroduCtIon Introduction System Configurations The panel can be programmed to operate as any of the following system types: • All/Perimeter system that provides one perimeter area and one interior area • Home/Sleep/Away system that provides one perimeter, one interior, and one bedroom area. The bedroom area provides for any protection devices the user wants disarmed during their sleeping hours and armed in the Away mode. • Six area system that provides areas of protection that can be independently armed or disarmed. -
Page 7: Accessory Devices
system ComPonents System Components Accessory Devices DMP Two-Way Wireless Devices 1100R Repeater Provides additional range for wireless devices. 1101 Universal Transmitter Provides both internal and external contacts that may be used at the same time to yield two individual reporting zones from one wireless transmitter. 1102 Universal Transmitter Provides one external contact. 1103 Universal Transmitter Provides both and internal and external contacts that may be used at the same time to yield two individual reporting zones from one wireless transmitter. Requires EOL resistor for... -
Page 8: Mounting The Enclosure
Inst alla tIon Installation Mounting the Enclosure The enclosure for the XTL panel must be mounted using the provided #6 screws in the four mounting holes shown in Figure 2. Mount the enclosure in a secure, dry place to protect the panel from damage due to tampering or the elements. It is not necessary to remove the PCB when installing the enclosure. Mounting Hole Locations TX RF RX 65555 RESET LOAD MODEL XTL PROG Figure 2: Mounting Hole Locations Primary Power Supply DC Input Mount the XTL panel near a wall outlet for the Model 372-500 plug-in DC power supply. In addition to... -
Page 9: Standby Battery
Inst alla tIon Secondary Power Supply Standby Battery The XTL rechargeable battery is used to provide 24 hours of backup battery power when DC power is not available. The battery is intended for backup power only and not to operate the XTL panel on a daily basis. If the battery is low, or not plugged into the J1 battery connector, a low battery condition is indicated by the XTL panel. Note: If removing the XTL panel from service, disconnect the backup battery from the XTL connector. Replacement Use the following steps to replace the XTL standby battery. DMP recommends replacing the battery every 3 years under normal use. Top PCB Snaps 3.7V Rechargeable Battery Bottom PCB Snaps Battery connector Figure 4: Standby Battery Replacement 1. Unplug the battery connector (J1) from the XTL panel. 2. Loosen the top PCB snaps. 3. Lean the panel PCB forward and lift out from the bottom PCB snaps. 4. Remove and properly dispose of the used battery. -
Page 10: Backlit Logo
Inst alla tIon LED Operation Backlit Logo The backlit logo indicates the Power and Armed status of the panel. Depending on the operation, the LED displays in Red or Green as listed in the table. Color and Activity Operation Green Steady Panel Disarmed, AC Power OK, Battery OK Green Blinking Panel Disarmed, AC Power OK, Battery Fault No Light Panel Disarmed, AC Power Fault, Battery OK Red Steady Panel Armed, AC Power OK, Battery OK Red/Green Alternate Panel Armed, AC Power OK, Battery Fault Red Blinking Panel Armed, AC Power Fault, Battery OK Reset Button Description The reset button (S1) is located on the right side of the circuit board and is used to reset the XTL microprocessor. To reset the panel when first installing the system, press the reset button after applying power to the panel. To reset the panel while the system is operational, for example, prior to reprogramming, press the reset button for 1-2 seconds without powering down the system. After resetting the panel, begin programming within 30 minutes. If you wait longer than 30 minutes, you must reset the panel again. -
Page 11: Mounting Keypads
Inst alla tIon Wireless Keypads 11.1 Mounting Keypads DMP keypads have removable covers that allow the base to be mounted on a wall or other flat surface using the screw holes provided on each corner. 11.2 Wireless Keypad Association Pressing the reset button 3 times within 5 seconds enables the keypad association mode. For one minute the panel listens for wireless keypads. Any keypads not already associated with another panel are accepted. The first keypad detected is assigned to the first open keypad address. Keypads are automatically assigned addresses based upon the order in which they are detected. A maximum of 4 keypads may be associated with a panel. 11.3 Existing Keypad Confirmation During the one minute time period, the panel also confirms that programmed keypads are still functioning. Wireless Zones 12.1 Description XTL panels provide 28 wireless zones numbered 1 to 28. The default zone names are described below. Zone Number Zone Name Zone Type Area Assignment FRONT DOOR... -
Page 12: Description
Inst alla tIon Flash Load Button 13.1 Description The XTL panel software can be updated via the panel’s programming (PROG) header. To update the panel with a new software version, complete the following steps at the protected premise: 1. Connect a DMP 399 Cable from the Programming Header to the serial port of your PC operating Remote Link and containing the XTL RU file. 3. Start Remote Link and create or open the XTL control panel account that matches the panel to be updated. 4. Set the Connection Information Type to Direct with a baud rate of 38400 and choose the appropriate COM port. 5. Select Panel>Remote Update, then select the correct RU file for the XT panel model. 6. Press and hold the LOAD button (S2), then press and release the RESET button. 7. Release the LOAD button and click <Update> in Remote Link. 8. After the software update is completed, remove the 399 cable and press the RESET button to resume normal panel operation. Digital Monitoring Products XTL Installation Guide... -
Page 13: Introduction
Inst alla tIon Listed Compliance Specifications 14.1 Introduction The programming and installation specifications contained in this section must be completed when installing the XTL in accordance with any of the ANSI/UL burglary standards. Additional specifications may be required by a particular standard. 14.2 Use Marking Commercial Central Station; Household Fire and Burglar Warning System Control Unit (Cellular) 14.3 NFPA 72 This equipment should be installed in accordance with Chapter 11 of the National Fire Alarm Code, ANSI/ NFPA 72-2002, (National Fire Protection Association, Batterymarch Park, Quincy, MA 02269). Printed information describing proper installation, operation, testing, maintenance, evacuation planning, and repair service is to be provided with this equipment. Warning: Owner’s instruction notice, not to be removed by anyone except occupant. 14.4 Types Of Service Suitable for Central Station Standard Line Security. Suitable for Household Fire and Household Burglary. Test weekly. -
Page 14: Ansi/Ul
ComPlIanCe Central Station Burglar Alarm Units ANSI/UL 1610 16.1 Standard Line Security Standard Line Security is provided when the Check-in time is set to 3 minutes. When programmed for Standard Line Security, Exit Time Restart is disabled. Note: The SecureCom Wireless text plan selected for the panel should match or exceed the programmed Monthly Limit or additional cellular charges may apply. 16.2 Remote Disarm REMOTE DISARM must be programmed as NO. 16.3 Central Station MESSAGE TO TRANSMIT programming for zones must not be set to LOCAL (L). Household Fire Warning System ANSI/UL 985 NFPA 72 Specifications 17.1 Bell Output Definition The bell output of the XTL panel must be programmed to operate steady on burglary alarms and temporal on fire alarms. See the XTL Programming Guide. 17.2 Household System An alarm sounding device must be installed indoors so that it is clearly heard in all sleeping areas. -
Page 15: Shipping Defaults And Recommended Programming
ComPlIanCe False Alarm Reduction Programmable Options ANSI/SIA CP-01-2007 18.1 Shipping Defaults and Recommended Programming SIA CP-01 FEATURE DMP PROGRAMMING SHIPPING RECOMMENDED PARAGRAPH # AND GUIDE LT-1108 REQUIREMENT RANGE DEFAULT PROGRAMMING* DESCRIPTION SECTION # Required 4.2.2.1 Exit Time 8.6 Exit Delay 45 sec. - 250 sec. 60 Seconds (Programmable) Seconds Individual keypads 4.2.2.2 Progress 13.14 Prewarn... -
Page 16: Entry Delay
ComPlIanCe False Alarm Reduction Programmable Options ANSI/SIA CP-01-2007 (continued) 18.2 Entry Delay Only use Entry Delay 1. Do not use Entry Delay 2. See the XTL Programming Guide. 18.3 Local Bell All non-fire zones such as Night, Day, Exit, Aux1 and Aux 2 must be programmed for local bell enabled with a bell cutoff time set to a minimum of 6 minutes to provide a cancel window of 5 minutes or greater. This does not apply to manually operated zone types such as Panic and Emergency. The requirements are superceded by any requirements for Commercial Burglar, Household Fire Warning, or Household Burglar applications. -
Page 17: Revisions To This Document
revIsIons Revisions to This Document This section explains the changes that were made to this document during this revision. This section lists the version, section number with heading, and a quick summary of the change. Ver. Section Number and Heading Summary of Changes Digital Monitoring Products XTL Installation Guide... -
Page 18: Listings And Approvals
Listings and Approvals FCC Part 15 ID: CCKPC0117 Industry Canada ID: 5251A-PC0117 Underwriters Laboratories (UL) Listed ANSI/UL 1023 Household Burglar ANSI/UL 985 Household Fire Warning ANSI/UL 1610 Central Station Burglar 800-641-4282 IN TRU SIO N • F IRE • AC C ESS • NET WOR KS www.dmp.com 2500 North Partnership Boulevard Made in the USA Springfield, Missouri 65803-8877...
