- Page 1 PTB 14 ATEX 2023 X, IECEx PTB 14.0049X Solenoid coil Type AC10 Magnetspule Typ AC10 Bobine magnétique Type AC10 Device with II 2G/D Ex m approval Geräte mit II 2G/D Ex m Zulassung Appareils avec mode de protection II 2G/D Ex m...
- Page 2 We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Sous réserve de modifications techniques. © 2014-2015 Bürkert Werke GmbH Operating Instructions 1505/01_EU-ML_00810392 / Original DE...
-
Page 3: Table Of Contents
PTB 14 ATEX 2023 X Contents 1 OPERATING INSTRUCTION ..............4 8 INSTALLATION AND REMOVAL ............13 1.1 Definition of terms / abbreviation ........... 4 8.1 Safety instructions ..............13 1.2 Symbols ..................4 8.2 Installation .................14 8.3 Electrical connection ..............14 2 AUTHORISED USE ..................5 8.4 Removal ..................15 2.1 Restrictions ................. 5 9 START-UP . -
Page 4: Operating Instruction
PTB 14 ATEX 2023 X Operating Instruction OPERATING INSTRUCTION Symbols The operating instructions describe the entire life cycle of the device. DANGER! Keep these instructions in a location which is easily accessible to every user and make these instructions available to every new owner Warns of an immediate danger. of the device. ▶ Failure to observe the warning may result in a fatal or serious injury. Operating instruction contain important information. WARNING! ▶ Read the operating instructions carefully and follow the safety Warns of a potentially dangerous situation. instructions in particular. ▶ Failure to observe the warning may result in serious injuries or ▶... -
Page 5: Authorised Use
PTB 14 ATEX 2023 X Authorised use AUTHORISED USE Restrictions If exporting the system/device, observe any existing restrictions. Unauthorized use of the solenoid coil AC10 may be dangerous to people, nearby equipment and the environment. Explosion protection approval ▶ A valve controlled by the solenoid coil AC10 may be used solely for the media specified in the data sheet and for use in explosion The explosion protection approval is only valid if you use the modules group IIC category 2G and/or explosion group IIIC category 2G, and components authorized by Bürkert, as described in these oper- and temperature class T4, T5 or T6 (refer to the specifications on ating instructions. the type label for explosion-risk areas). ▶ The solenoid coil may be used only for the applications designated The solenoid coil AC10 may be used only in combination with the valve types released by Bürkert, otherwise the explosion protection in chapter “6 Application conditions of the devices” and in con-... -
Page 6: Basic Safety Instructions
PTB 14 ATEX 2023 X Basic safety instructions BASIC SAFETY INSTRUCTIONS Risk of explosion! These safety instructions do not make allowance for any The solenoid coil and valve body form a closed system after installation. • Contingencies and events which may arise during the installation, When used in explosion-risk areas, there is a risk of explosion if the operation and maintenance of the devices. system is opened in the operating state. ▶ The system must not be disassembled during operation. • Local safety regulations – the operator is responsible for observing these regulations, also with reference to the installation personnel. Risk of explosion due to electrostatic discharge! In the event of a sudden discharge from electrostatically charged devices or individuals, there is a risk of an explosion in the explosion-risk area. Danger – high pressure! ▶ Take suitable measures to ensure that no electrostatic discharges ▶ Before loosening the lines and valves, turn off the pressure and can build up in the explosion-risk area. vent the lines. ▶ Clean the device surface by gently wiping it with a damp or anti- Risk of electric shock! static cloth only. ▶ Before reaching into the device, switch off the power supply and... -
Page 7: General Information
PTB 14 ATEX 2023 X General information GENERAL INFORMATION General hazardous situations. To prevent injury, ensure: ▶ Secure system/equipment against unintentional activation. Contact addresses ▶ Observe the direction of flow during installation. Germany ▶ After an interruption in the power supply or pneumatic supply, Bürkert Fluid Control Systems ensure that the process is restarted in a defined or controlled Sales Center manner. -
Page 8: Product Description
PTB 14 ATEX 2023 X Product description PRODUCT DESCRIPTION The solenoid coil consists of: • coil winding, Design • coil housing (made from epoxy), • electrical connection cable, Components of the Components of • bridge rectifier. solenoid coil AC10: the valve: Alternating current or direct current control is possible. Bracket The solenoid coil type AC10 is available in a range of ratings distributed across 2 frame sizes. The interface between the coil and valve is iden- tical for both frame sizes. Connection cable The coil is placed over the core guide tube of the valve and attached with a nut. It is positively locked to prevent turning relative to the valve. Union nut The electrical connection cable exits perpendicular to the coil axis. -
Page 9: Application Conditions Of The Devices
PTB 14 ATEX 2023 X Application conditions of the devices APPLICATION CONDITIONS OF • The rated fuse voltage has to be the same as or higher than the specified nominal voltage of the solenoid. The rated fuse value is THE DEVICES specified on the type label (see chapter “7.4”). • The interruption rating of the fuse link must be the same as or higher Special conditions than the maximum short-circuit current to be accepted at the instal- lation site (usually 1500 A). 6.1.1 Avoiding build-up of electrostatic 6.1.3... -
Page 10: Operating Temperature Range
PTB 14 ATEX 2023 X Technical data TECHNICAL DATA The solenoid coils designed for individual installation may not be used for block assembly. The solenoid coils designed for block assembly are suitable for both Safety instructions block assembly and for individual installation. DANGER! Operating temperature range Risk of explosion! Observe the operating temperature range specified in the electrical Dangerous situations can result if the technical safety data and data for all types. values specified on the type label aren’t observed or cannot be met. ▶ The degree of protection and temperature class for use of the device must be observed. Exceeding the voltage specified on the type label creates a safety hazard since it can lead to overheating of the device! ▶ Don’t connect the device to a higher voltage than that specified on the type label. -
Page 11: Type Label For Explosions-Risk Areas
PTB 14 ATEX 2023 X Technical data Type label for explosions-risk Legend: areas Position Description ATEX, Certificate issuer and certificate number Solenoid coil AC10 with sample valve and the positions of the type label: ATEX, Explosion protection labelling IECEx, Certificate issuer and certificate number IECEx, Explosion protection labelling Type label with Type label Type label with Ex-code (last 4 digits) solenoid coil AC10 with valve Nominal voltage, nominal power, nominal fuse value specifications specifications Ambient temperature range Serial number Date of manufacture Identification number Fig. 2: Location and description of the explosion type label... -
Page 12: Electrical Data
PTB 14 ATEX 2023 X Technical data Electrical data Universal current, available nominal voltages from 12 V to 240 V, frequency 0 to 60 Hz Code Overall Tempera- Ambient tem- Nominal 7.5.1 Coils for individual installation width in ture perature range power Universal current, available nominal voltages from 12 V to 240 V, class in °C in W frequency 0 to 60 Hz PX24 -40 to +40 Code Overall Tempera- Ambient tem- Nominal PX28 -40 to +40 2.25... -
Page 13: Installation And Removal
PTB 14 ATEX 2023 X Installation and removal Wire assignment: INSTALLATION AND REMOVAL Wire color Assignment Safety instructions green-yellow Protective conductor DANGER! brown Coil connection 1 blue Coil connection 2 Danger – high pressure! ▶ Before loosening the lines and valves, turn off the pressure and vent the lines. Risk of electric shock! ▶ Before reaching into the device, switch off the power supply and secure to prevent reactivation! ▶ Observe applicable accident prevention and safety regulations for electrical equipment! -
Page 14: Installation
PTB 14 ATEX 2023 X Installation and removal Electrical connection DANGER! DANGER! Risk of explosion due to electrostatic discharge! In the event of a sudden discharge from electrostatically charged devices Risk of electric shock! or individuals, there is a risk of an explosion in the explosion-risk area. ▶ Before reaching into the device, switch off the power supply and ▶ Take suitable measures to ensure that no electrostatic discharges secure to prevent reactivation! can build up in the explosion-risk area. ▶ Observe applicable accident prevention and safety regulations ▶ Clean the device surface by gently wiping it with a damp or anti- for electrical equipment! static cloth only. There is a risk of electric shock if there is no electrical contact between the metal parts of the valve and the protective conductor WARNING! of the coil. ▶ Always connect the protective conductor. -
Page 15: Removal
PTB 14 ATEX 2023 X Start-up Removal START-UP DANGER! WARNING! Danger – high pressure! Risk of injury from improper operation! ▶ Before loosening the lines and valves, turn off the pressure and Improper operation may result in injuries as well as damage to the vent the lines. device and the area around it. Risk of electric shock! ▶ Before start-up, ensure that the operating personnel are familiar ▶ Before reaching into the device, switch off the power supply and with and completely understand the contents of the operating instructions. secure to prevent reactivation! ▶ Observe the safety instructions and intended use. ▶ Observe applicable accident prevention and safety regulations for electrical equipment! ▶ Only adequately trained personnel may start up the equipment/ the device. WARNING! -
Page 16: Maintenance, Repair, Troubleshooting
PTB 14 ATEX 2023 X Maintenance, Repair, Troubleshooting MAINTENANCE, REPAIR, TRANSPORTATION, STORAGE, TROUBLESHOOTING DISPOSAL NOTE! 10.1 Maintenance work Transport damages! The solenoid coil AC10 are maintenance-free when operated under Inadequately protected equipment may be damaged during the conditions described in this manual. transport. • During transportation protect the device against wet and dirt in 10.2 Repair shock-resistant packaging. • Avoid exceeding or dropping below the allowable storage DANGER! temperature. Incorrect storage may damage the device. Danger due to improper repairs! The safety and functionality of the AC10 coil and corresponding • Store the device in a dry and dust-free location! - Page 17 PTB 14 ATEX 2023 X Inhaltsverzeichnis 1 BEDIENUNGSANLEITUNG ..............18 8 MONTAGE UND DEMONTAGE ............27 1.1 Begriffsdefinition / Abkürzung ..........18 8.1 Sicherheitshinweise ..............27 1.2 Darstellungsmittel ..............18 8.2 Montage..................28 8.3 Elektrischer Anschluss ............28 2 BESTIMMUNGSGEMÄSSE VERWENDUNG........ 19 8.4 Demontage ................29 2.1 Beschränkungen ..............19 9 INBETRIEBNAHME .
- Page 18 PTB 14 ATEX 2023 X Bedienungsanleitung BEDIENUNGSANLEITUNG Darstellungsmittel In dieser Anleitung werden folgende Darstellungsmittel verwendet. Die Bedienungsanleitung beschreibt den gesamten Lebenszyklus des Geräts. Bewahren Sie diese Anleitung so auf, dass sie für jeden GEFAHR! Benutzer gut zugänglich ist und jedem neuen Eigentümer des Geräts wieder zur Verfügung steht. Warnt vor einer unmittelbaren Gefahr! ▶ Bei Nichtbeachtung sind Tod oder schwere Verletzungen die Folge. Wichtige Informationen zur Sicherheit! ▶ Bedienungsanleitung sorgfältig lesen und Hinweise zur Sicherheit WARNUNG! beachten. Warnt vor einer möglicherweise gefährlichen Situation! ▶ Bedienungsanleitung muss jedem Benutzer zur Verfügung stehen. ▶ Bei Nichtbeachtung drohen schwere Verletzungen oder Tod. ▶ Haftung und Gewährleistung entfällt, wenn die Anweisungen der Bedienungsanleitung nicht beachtet werden. VORSICHT! Warnt vor einer möglichen Gefährdung! Begriffsdefinition / Abkürzung ▶...
- Page 19 PTB 14 ATEX 2023 X Bestimmungsgemäße Verwendung BESTIMMUNGSGEMÄSSE Beschränkungen VERWENDUNG Bei der Ausfuhr des Systems/Geräts gegebenenfalls bestehende Beschränkungen beachten. Bei nicht bestimmungsgemäßem Einsatz der Magnetspule AC10 können Gefahren für Personen, Anlagen in der Umgebung und Ex-Zulassung die Umwelt entstehen. ▶ Ein Ventil, das mit Magnetspule AC10 gesteuert wird, dient aus- Die Ex-Zulassung ist nur gültig, wenn die von Bürkert zugelassenen schließlich für die laut Datenblatt zulässigen Medien und für den Module und Komponenten so verwendet werden, wie es in dieser Einsatz in Explosionsgruppe IIC, Kategorie 2G bzw. Explosions- Bedienungsanleitung beschrieben ist. gruppe IIIC, Kategorie 2D und Temperaturklasse T4, T5 oder T6 Die Magnetspule AC10 darf nur in Kombination mit den von Bürkert (siehe Angaben auf dem Typschild für Ex-Bereich).
- Page 20 PTB 14 ATEX 2023 X Allgemeine Sicherheitshinweise ALLGEMEINE SICHERHEITSHINWEISE Explosionsgefahr! Diese Sicherheitshinweise berücksichtigen keine Magnetspule und Ventilkörper bilden nach der Montage ein geschlos- • Zufälligkeiten und Ereignisse, die bei Montage, Betrieb und Wartung senes System. Bei Einsatz im Ex-Bereich besteht bei der Öffnung des der Geräte auftreten können. Systems im Betriebszustand Explosionsgefahr. ▶ Das System darf nicht während des Betriebs demontiert werden. • ortsbezogenen Sicherheitsbestimmungen, für deren Einhaltung, auch in Bezug auf das Montagepersonal, der Betreiber verantwortlich ist. Explosionsgefahr durch elektrostatische Entladung! Bei plötzlicher Entladung elektrostatisch aufgeladener Geräte oder Personen besteht im Ex-Bereich Explosionsgefahr. Verletzungsgefahr durch hohen Druck in Anlage/Gerät! ▶ Durch geeignete Maßnahmen sicherstellen, dass es im Ex-Bereich ▶ Vor Arbeiten an Anlage oder Gerät den Druck abschalten und zu keinen elektrostatischen Aufladungen kommen kann.
