VERA20
Operation manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERA20 and is the answer not in the manual?

Questions and answers

Summary of Contents for TW Audio VERA20

  • Page 1 VERA20 Operation manual...
  • Page 2 The VERA20 loudspeaker is equipped with two 10” chassis for the low-mid frequencies and a waveguide with a 1.4” mid-high compression driver. Compared with typical double 8” sys- tems, the VERA20‘s two 10” drivers are capable of reproducing up to 6 dB more output in the low-mid frequency range with lower distortion.
  • Page 3 NOTE This symbol in combination with the signal word “Tip” identifies additional information or notes that will simplify working with TW AUDiO products on the basis of practical experience. Notes on the products Before using the device, carefully read the operating manual and keep it with the Read manual VERA20 loudspeaker.
  • Page 4: Table Of Contents

    Content 1. Safety | Intended Use ..................... 5 2. Overview ........................7 Components ......................7 VERA20 rear rigging ....................8 Variants - Horn flanges horizontal coverage 80° / 120° ..........8 3. Technical specifications ....................9 Data Sheet ......................9 Connection Diagram ....................
  • Page 5: Safety | Intended Use

    1. Safety | Intended Use Please adhere to the following safety instructions to avoid risks when operating loudspeakers. The VERA20 loudspeaker was developed for professional use in sound systems. The loudspe- aker may only be used by trained and qualified personnel.
  • Page 6 Operation manual VERA20 Ensure that the loudspeaker is not exposed to permanent thermal overloads. Thermal over- loads may cause a fire and result in serious personal injury and property damage. WARNING Note that TWAMBO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
  • Page 7: Overview

    Locking pins (2 pieces) Carrying handles (left and right) 10“ cone driver Horn flanges (2 pieces) Waveguide with 1,4“ compression driver 10. Type label 11. VERA20 rear rigging (see chapter 2.2) 12. Connection panel with one SpeakON socket each, top and bottom ®...
  • Page 8: Vera20 Rear Rigging

    Quick-locking pin Variants - Horn flanges horizontal coverage 80° / 120° The VERA20 loudspeaker can optionally be equipped with 80° or 120° horn flanges. The angle specification refers to horizontal coverage. Check the rear rigging to identify the VERA20 vari- ant.
  • Page 9: Technical Specifications

    Operation manual VERA20 3. Technical specifications Data Sheet Variant VERA20-80 VERA20-120 Drivers 2x 10“ LF / 1x 1,4“ HF Frequency response 67 - 18000 Hz Power handling (program/Peak) 1000 / 2000 W Impedance 8 Ω Coverage (h x v) 80° x 12°...
  • Page 10: Commissioning

    Please refer to the VERA RF600, SFV20 and GSP20 manuals for operating modes and set-up options. NOTE EASE Focus simulation software can be used to plan VERA20 line arrays. EASE Focus is avai- lable as a free download from the TW AUDiO website at www.twaudio.com.
  • Page 11: Exchanging The Horn Flanges

    Before connecting the loudspeaker to the amplifier, ensure that the right preset has been loaded. NOTE Using a wrong, out dated or a preset not provided by TW AUDiO can lead to destruction of the speaker. Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that doesn’t meet the specifications can destroy the loudspeaker.
  • Page 12: Connecting Cables

    (1/2) are correct. Incorrect connection can lead to a significant change in the loudspeaker’s sound characteristics and may damage the driver. The pin connections of the VERA20 loudspeaker can be found in section 3.2 (“Connection dia- gram”) on page 9.
  • Page 13: Transport And Storage

    Operation manual VERA20 5. Transport and Storage Due to the VERA20 loudspeaker weighing over 20 kg [44 lbs.], two persons are required to handle and transport the unit. To enable a single person to transport up to six VERA20 loudspeakers, TW AUDiO recom- mends using the VERA DLV20.
  • Page 14: Ce Conformity Declaration

    Operation manual VERA20 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives.
  • Page 15: Disposal

    Operation manual VERA20 7. Disposal It is prohibited to dispose of used electrical equipment with household refuse. All TWAMBO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TWAMBO products that bear the trash can symbol shown here may only be disposed of by TWAMBO.
  • Page 16 Operation manual VERA20 TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
