- Page 1 T24N Operating Manual...
- Page 2 Thank you for choosing a high quality product "MADE IN GERMANY" from TW AUDiO. The T24 was the first TW AUDiO loudspeaker and a benchmark for almost ten years for numerous users in the live and installations market. The innovative 2 × 12"/1.4" horn in horn construction enables an outstanding dynamic and 143 db top acoustic pressure with an enclosure front surface of just 70 ×...
- Page 3 TW AUDiO also shall not assume liability for any secondary damage (property damage and/or personal injury) nor for the failure to comply with this operating manual. TW AUDiO reserves the right to make changes that take into account the latest engi- neering advancements.
-
Page 4: Table Of Contents
Operating Manual T24N Content Safety | Intended use .....................1 Overview .........................3 Components ....................... 3 Variants ........................4 Operating modes......................4 Technical data ......................5 Data sheet ........................5 Wiring diagram ......................5 Setting up the loudspeaker...................6 Setup .......................... 6 Rotating the horn and exchanging the horn cone ............6 Connecting cables...................... -
Page 5: Safety | Intended Use
Please adhere to the following safety instructions to avoid risks when operating the loud- speakers. The T24N loudspeaker was developed for professional use in sound systems. The loud- speaker may only be used by trained and qualified personnel. Note the operating modes described in this operating manual. - Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
-
Page 7: Overview
2.1 Components (Integrate graphics) Figure 2.1 - Overview Dolly latch base to attach the TW AUDiO T24N front dolly Milling for rubberfeet for safely stacking loudspeakers 15 mm multiplex housing – Warnex texture paint surface finish Rigging plate for attaching accessory parts... -
Page 8: Variants
Operating Manual T24N 2.2 Variants The T24N loudspeaker is available in a 60° × 40° variant and in a 90° × 50° variant. The specified degree values refer to the horizontal and vertical radiation characteristics of the horn. Different interchangeable horn cones can be installed for this purpose. The variant of the T24N loudspeaker can be identified on the outside of the horn cone (see figure 2.2). -
Page 9: Technical Data
Operating Manual T24N 3. Technical data 3.1 Data sheet Operating mode Biamp Passive Components 2 × 12" LF/1 × 1.4" HF Frequency response 65 – 18,000 Hz Power handling, program/ 1400/2800 W LF 1400/2800 W peak 220/440 W HF Impedance 4Ω... -
Page 10: Setting Up The Loudspeaker
Horizontal operation is not an intended use. 4.2 Rotating the horn and exchanging the horn cone The horn of the T24N loudspeaker is positioned such that the horizontal coverage is 60° and the vertical coverage is 40°. In some situations, it may be advantageous to change the output characteristics of the high-frequency range. -
Page 11: Connecting Cables
Operating Manual T24N 4.2.2 Exchanging the horn cone Place the T24N loudspeaker on the back side with front grill facing up. Ensure that you work on a clean and non-slip surface. To remove the front grill of the loudspeaker, use a 3-mm hex key. -
Page 12: Transport And Storage
Because the T24N loudspeaker weighs over 20 kg, two people are needed to move and transport the unit. The FDB30 front dolly and the Twin Case can be used to transport the T24N loud- speaker by a single person. NOTE When transporting and storing the unit, it is important to ensure that the surface and front grill of the loudspeaker are not damaged. -
Page 13: Ce Conformity Declaration
Operating Manual T24N 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. -
Page 14: Disposal
TW AUDiO products that bear the trash can symbol shown here are only permitted to be disposed of by TW AUDiO. The loudspeaker owner is legally responsible for the disposal of used devices that do not bear this symbol. - Page 15 TWAUDiO GmbH Osterholzallee 140-2 71636 Ludwigsburg Germany P: + 49 (0) 71 41-48 89 89 0 F: + 49 (0) 71 41-48 89 89 99 E: info@twaudio.de W: www.twaudio.de...
