- Page 1 ELLA6 Operation manual...
- Page 2 ELLA has a cardioid directivity pattern over the entire frequency range. ELLA6 has a nominal impedance of 24 Ohms – so it is possible to connect multiple speakers in parallel, there is no additional amp channel required for the cardioid effect.
- Page 3 This symbol in combination with the signal word “Tip” identifies additional information or notes that will simplify working with TW AUDiO products on the basis of practical experience. Notes on the products Before using the device, carefully read the operating manual and keep it with the ELLA6 loudspe- Read manual aker.
-
Page 4: Table Of Contents
Operation manual ELLA6 Content 1. Safety | Intended use ...................... 5 2. Overview ........................7 Components ......................7 Rear rigging ELLA6 ....................8 HF-Array ........................9 3. Technical specifications ....................10 Data sheet ......................10 Connection diagram ....................10 4. Commissioning ......................11 Setup ........................ -
Page 5: Safety | Intended Use
1. Safety | Intended use Please adhere to the following safety instructions to avoid risks when operating loudspeakers. The ELLA6 loudspeaker was developed for use in professional sound systems. The loudspe- aker may only be used by trained and qualified personnel. - Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
-
Page 7: Overview
15 mm Multiplex enclosure - Warnex surface finish Carrying handle (2 pieces) HF-array with five 1,0“ dome tweeters 6,5“ cone driver Rigging track (2 pieces) Front lock (left and right) Cardio grill (2 pieces) Rear rigging ELLA6 with type labeling and splay angles... -
Page 8: Rear Rigging Ella6
Operation manual ELLA6 Rear rigging ELLA6 Figure 2.2.1 - Rear rigging SpeakON® socket (2 pieces) Latch Rear rigging profile Figure 2.2.2 - Rear rigging with logo, product data and splay angles Please note that the rear rigging profile is only available in the color black and the latch only in the color silver. -
Page 9: Hf-Array
Operation manual ELLA6 HF-Array The ELLA6 loudspeaker is equipped with an HF-array with a nominal horizontal coverage of 120° and nominal vertical coverage of 10°. Figure 2.3 - HF-array The HF-array can only be replaced completely in case of damage. In this case please contact our service. -
Page 10: Technical Specifications
Operation manual ELLA6 3. Technical specifications Data sheet Drivers 1x 6,5“ LF / 5x 1,0“ HF Frequency response 90-20000 Hz Power handling (program/Peak) 400 W / 800 W Impedance 24 Ω Coverage (h x v) 120° x 10° Max. SPL / 1m... -
Page 11: Commissioning
This may affect the proper operation of the speakers. NOTE Ensure that the ELLA6 speakers can dry out after each use in damp conditions in a dry, well-ventilated place. When doing so, the speakers must be removed from the case to pro-... -
Page 12: Rigging Ella6
Please refer to the ELLA6-system rigging manual for operating modes and set-up options. NOTE EASE Focus simulation software can be used to plan ELLA6 line arrays. EASE Focus is availa- ble as a free download from the TW AUDiO website at www.twaudio.com. -
Page 13: Operation
Before connecting the loudspeaker to the amplifier, ensure that the right preset has been loaded. NOTE Using a wrong, out dated or a preset not provided by TW AUDiO can lead to destruction of the speaker. Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that doesn’t meet the specifications can destroy the loudspeaker. -
Page 14: Connecting The Cable
(1/2) are correct. Incorrect connection can lead to a significant change in the loudspeaker’s sound characteristics and may damage the driver. The pin connections of the ELLA6 loudspeaker can be found in section 3.2 (“Connection dia- gram”) on page 10. -
Page 15: Transport And Storage
Operation manual ELLA6 5. Transport and Storage To enable a single person to transport up to twelve ELLA6 loudspeakers, TW AUDiO recom- mends using the CaseELLA6. NOTE When transporting and storing the unit, it is important to ensure that the surface and front grill of the loudspeaker are not damaged. -
Page 16: Ce Conformity Declaration
Operation manual ELLA6 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. -
Page 17: Disposal
It is prohibited to dispose of used electrical equipment with household refuse. All TW AUDiO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TW AUDiO products that bear the trash can symbol shown here may only be disposed of by TW AUDiO. - Page 18 Operation manual ELLA6 TW AUDiO GmbH Osterholzallee 140 71636 Ludwigsburg Germany Phone : + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
