VERA10
Operating Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERA10 and is the answer not in the manual?

Questions and answers

Related Manuals for TW Audio VERA10

Summary of Contents for TW Audio VERA10

  • Page 1 VERA10 Operating Manual...
  • Page 2 Its other top priority, as put to us by many customers, is flexibility. We are very proud of the result: VERA10 is capable of covering events with an audience of 10 to 10.000 people with only a single loudspeaker model.
  • Page 3 TW AUDiO also shall not assume liability for any secondary damage (property damage and/or personal injury) nor for the failure to comply with this operating manual. TW AUDiO reserves the right to make changes that take into account the latest engi- neering advancements.

  • Page 4: Table Of Contents

    Operating Manual VERA10 Contents Safety | Intended use .....................1 Overview ........................3 Components ........................3 Variants ..........................4 Operating modes ........................ 5 Technical data ........................7 Data sheet .......................... 7 Wiring diagram ........................7 Setting up the loudspeaker ..................9 Setup ..........................9 Exchanging the horn ......................

  • Page 5: Safety | Intended Use

    Note the operating modes described in this operating manual. Other uses are not permissible. TW AUDiO GmbH shall not be held liable for any damage that ensues from unintended use. Loudspeakers generate an electromagnetic field. Persons with pacemakers are not per- mitted to remain in the immediate vicinity of loudspeakers as the electromagnetic fields can cause pacemakers to malfunction.
  • Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.

  • Page 7: Overview

    VERA10 Active VERA10 Passive Figure 2.1 - Overview Front eyelet 15 mm multiplex enclosure – polyurea finish VERA10 "rear" rigging plate Splay link Locking pin 8 × 30 Ergonomic carrying handles (left and right) Locking pin 8 × 20 VERA10 "front" rigging plate Phase plug 10.

  • Page 8: Variants

    AMP model) and VERA10P (PASSIVE model). 2.2.1. Horn – horizontal coverage 80°/120° The VERA10 loudspeaker can be equipped with either an 80° × 10° horn or a 120° × 10° horn. The degrees refer to the horizontal and vertical radiation angles. The VERA10 horn variant can be identified by the legend printed on the horn (see figure 2.2).

  • Page 9: Operating Modes

    VERA10 Operating Manual 2.3 Operating modes The passive version (VERA10P) features two selector switches on the rear (figure 2.3.1) for switching between two different operating modes and for attenuating the high frequency range (see figure 2.1, no. 16). 2.3.1. Horizontal selector switch In the "PASSIVE"...
  • Page 10 VERA10 Operating Manual 2.3.2. Vertical selector switch The "High shelf attenuation" vertical selector switch lowers the frequency range above 2 kHz independent of the VERA10P operating mode. In the "0dB normal operation" mode, the frequency response is not attenuated above 2 kHz.

  • Page 11: Technical Data

    VERA10 Operating Manual 3. Technical data 3.1 Data sheet Model VERA10A VERA10P 1 × 10" LF/ 2 × 1" HF Component 60 – 16000 Hz Frequency response BIAMP mode PASSIVE mode Power handling, program/ 500/1000 W LF peak 500/1000 W LF...
  • Page 12 VERA10 Operating Manual Version: VERA10P PASSIVE MODE 0 dB HF SHELF -6 dB -6 dB HF ATT. SWITCHER -3 dB HF ATT. MODE SWITCHER PWVERA10 HF 1" PASSIVE ON PASSIVE X-OVER 12 OHM 16 OHM PIN 1+ HF 1" FIG 2.3.2 PIN 1–...

  • Page 13: Setting Up The Loudspeaker

    The VERA10 loudspeaker is designed for horizontal operation in a suspended or stand- ing position. A variety of accessories is available from TW AUDiO to securely attach the loudspeaker, e.g. on stands or suspended from trusses and chain/motor hoists. Vertical operation is not intended.

  • Page 14: Connecting Cables

    (1/2) are correct. Incorrect connection results in a significant change in the loudspeaker sound characteristics and may damage the compression driver. The pin connections of the VERA10 loudspeaker can be found in section 3.2 “Wiring di- agram” on page 7.

  • Page 15: Transport And Storage

    VERA10 Operating Manual 5. Transport and storage To enable a single person to transport multiple VERA10 loudspeakers, TW AUDiO rec- ommends using the FDB30 front dolly. Alternatively, the VERA10 can also be trans- ported in a CaseVERA10 flight case. NOTE When transporting and storing the unit, it is important to ensure that the surface and front grill of the loudspeaker are not damaged.

  • Page 16: Ce Conformity Declaration

    VERA10 Operating Manual 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives.

  • Page 17: Disposal

    TW AUDiO products that bear the trash can symbol shown here are only permitted to be disposed of by TW AUDiO. The loudspeaker owner is legally responsible for the disposal of used devices that do not bear this symbol.
  • Page 18 TW AUDiO GmbH Osterholzallee 140-2 71636 Ludwigsburg Germany P: + 49 (0) 71 41-48 89 89 0 F: + 49 (0) 71 41-48 89 89 99 E: info@twaudio.de W: www.twaudio.de...
