Summary of Contents for TW Audio VERA36 Series

  • Page 1 VERA36 Operation manual...
  • Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
  • Page 3 NOTE This symbol in combination with the signal word “Tip” identifies additional information or notes that will simplify working with TW AUDiO products on the basis of practical experience. Notes on the products Before using the device, carefully read the operating manual and keep it with the Read manual VERA36 loudspeaker.
  • Page 4: Table Of Contents

    Operation manual VERA36 Content 1. Safety | Intended use ...................... 5 2. Overview ........................7 Components ......................7 Rear rigging VERA36 ....................8 Variants - high frequency unit horizontal coverage 80° / 120° ........9 3. Technical specifications ....................10 Data sheet ......................
  • Page 5: Safety | Intended Use

    When using and assembling TW AUDiO loudspeakers, only use materials specified by TW AUDiO. These tasks must be performed by qualified personnel. Adhere to the applicable safety regulations. When setting up loudspeakers, ensure that they are not exposed to the following ambient...
  • Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.
  • Page 7: Overview

    Operation manual VERA36 2. Overview Components Figure 2.1 - Overview 15 mm Multiplex enclosure - Polyurea surface finish Front grill Ergonomic handle (2 pieces) 10“ cone driver (2 pieces) Horn wall (2 pieces) High frequency unit with waveformer, horn and 1,4“ compression driver Rigging track (2 pieces) Locking pin (2 pieces) Type label...
  • Page 8: Rear Rigging Vera36

    Operation manual VERA36 Rear rigging VERA36 Figure 2.2 - rear rigging Mounting plate with rails Angle display with checkbox Main carrier with bracket Right slider with locking pin Checkbox for position of the VERA36 loudspeaker in the array Checkbox for the installed high frequency unit Left slider with locking pin Locking pin...
  • Page 9: Variants - High Frequency Unit Horizontal Coverage 80° / 120

    Operation manual VERA36 Variants - high frequency unit horizontal coverage 80° / 120° The VERA36 loudspeaker can be optionally equipped with a 80° × 10° high frequency unit or a 120° × 10° high frequency unit. The specified degrees refer to the horizontal and vertical coverage.
  • Page 10: Technical Specifications

    Operation manual VERA36 3. Technical specifications Data sheet Variant VERA36-80 VERA36-120 Drivers 2x 10“ LF / 2x 8“ MF / 2x 1,4“ HF Frequency response 60 - 16000 Hz 1000 / 2000 W LF Power handling (program/Peak) 800 / 1600 W MF Impedance 8 Ω...
  • Page 11: Commissioning

    Setup The VERA36 loudspeaker has been designed for horizontal operation in stacked and flown vertical arrays. TW AUDiO provides a wide range of accessories to securely attach the loudspe- aker. Make sure that all system structures are located on a firm, level surface and that the surface...
  • Page 12: Changing The High Frequency Unit

    Operation manual VERA36 Changing the high frequency unit Depending on the variant, the 80° or 120° high frequency unit (see capter 2.3 - page 9) is installed in the loudspeaker. For some applications, it may be advantageous to exchange the high frequency unit for the other variant in order to change the horizontal coverage.
  • Page 13: Operation

    NOTE Using the wrong preset or a preset not provided by TW AUDiO preset can destroy the speaker. Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that doesn’t meet the specifications can destroy the loudspeaker.
  • Page 14: Connecting The Cable

    Operation manual VERA36 Connecting the cable To create a cable connection with an amplifier rack from TW AUDiO, proceed as follows. Ensure that the cable cross sectional area is sufficient (at least 1.5 mm²) to avoid power losses. TW AUDiO recommends using the loudspeaker cables available from TW AUDiO.
  • Page 15: Transport And Storage

    Due to the VERA36 loudspeaker weighing over 20 kg [44 lbs.], two persons are required to handle and transport the unit. To enable a single person to transport up to six VERA36 loudspeakers, TW AUDiO recom- mends using the VERA DLV36.
  • Page 16: Ce Conformity Declaration

    Operation manual VERA36 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and construction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives.
  • Page 17: Disposal

    It is prohibited to dispose of used electrical equipment with household refuse. All TW AUDiO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TW AUDiO products that bear the trash can symbol shown here may only be disposed of by TW AUDiO.
  • Page 18 Operation manual VERA36 TW AUDiO GmbH Osterholzallee 140 71636 Ludwigsburg Germany Phone : + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...

This manual is also suitable for:

Vera36-120Vera36-80
