  • Page 1 T24N Operation manual...
  • Page 2 „perfect loudspeaker construction at all levels“. The story of the T24N goes back to the beginning of TW AUDiO itself and the original T24 - the first TW AUDiO loudspeaker. Widely considered a benchmark product in the live sound market and beyond, the T24 was compact yet strikingly powerful with an innovative 2×...
  • Page 3 This symbol in combination with the signal word “Tip” identifies additional information or notes that will simplify working with TW AUDiO products on the basis of practical experience. Notes on the products Before using the device, carefully read the operating manual and keep it with the T24N loudspe- Read manual aker.

  • Page 4: Table Of Contents

    Operation manual T24N Content 1. Safety | Intended use ...................... 5 2. Overview ........................7 Components ......................7 Variants ........................8 Operating modes ..................... 9 3. Technical specifications ....................10 Data sheet ......................10 Connection diagram ....................10 4. Commissioning ......................11 Setup ........................

  • Page 5: Safety | Intended Use

    1. Safety | Intended use Please adhere to the following safety instructions to avoid risks when operating loudspeakers. The T24N loudspeaker was developed for use in professional sound systems. The loudspe- aker may only be used by trained and qualified personnel.
  • Page 6 WARNING Note that TW AUDiO does not provide a warranty for damage that can be attributed to this type of overload and therefore cannot be held liable for any secondary damage.

  • Page 7: Overview

    2. Overview Components Figure 2.1 - Overview Dolly latch base to attach the TW AUDiO T24N front dolly Milling for rubberfeet for safely stacking loudspeakers 15 mm multiplex housing – Warnex texture paint surface finish Rigging plate for attaching accessory parts...

  • Page 8: Variants

    Operation manual T24N Variants The T24N loudspeaker is available in a 60° × 40° variant and in a 90° × 50° variant. The specified degree values refer to the horizontal and vertical radiation characteristics of the horn. Different interchangeable horn cones can be installed for this purpose. The variant of the T24N loudspeaker can be identified on the outside of the horn cone (see figure 2.2.1).

  • Page 9: Operating Modes

    Operation manual T24N Operating modes The T24N loudspeaker has a switch (see figure 2.3) on the back for switching between two different operating modes (see figure 2.1, no. 10). In the „PASSIVE“ mode, the loudspeaker is operated on a passive audio crossover with a single amplifier channel.

  • Page 10: Technical Specifications

    Operation manual T24N 3. Technical specifications Data sheet Operating mode Biamp Passive Drivers 2x 12“ LF / 1x 1,4“ HF Frequency response 65 - 18000 Hz 1400 / 2800 W LF Power handling (program/Peak) 1400 / 2800 W 220 / 440 W HF 4 Ω...

  • Page 11: Commissioning

    TW AUDiO recommends using only the accessories specified by TW AUDiO for securing and mounting loudspeakers. NOTE Please note that when operating the T24N loudspeaker without front grill, the HF horn must additionally be secured against falling out! (Sticking) WARNING...

  • Page 12: Rotating And Changing The Hf Horn

    Rotating and changing the HF horn By default, the HF horn of the T24N loudspeaker is oriented so that the horizontal beam angle is 60° and the vertical beam angle is 40°. In some situations it may be advantageous to change the emission characteristics in the HF range.

  • Page 13: Changing The Hf Horn

    4.2.2 Changing the HF horn 1. Place the T24N loudspeaker on its back, with the speaker grill facing up. Make sure to place the speaker on a clean, non-slippery surface. 2. To remove the front grill, a hexalobular key with the size of TX25 is required. Remove all front grill mounting screws from the top and bottom of the loudspeaker (4 pieces).

  • Page 14: Operation

    NOTE Using the wrong preset or a preset not provided by TW AUDiO preset can destroy the speaker. Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that doesn’t meet the specifications can destroy the loudspeaker.

  • Page 15: Transport And Storage

    Operation manual T24N 5. Transport and Storage Due to the T24N loudspeaker weighing over 20 kg [44 lbs.], two persons are required to handle and transport the unit. The FDB30 front dolly and the CaseT24 can be used to transport the T24N loudspeaker by a single person.

  • Page 16: Ce Conformity Declaration

    Operation manual T24N 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives.

  • Page 17: Disposal

    It is prohibited to dispose of used electrical equipment with household refuse. All TW AUDiO GmbH products are so-called B2B-products. This means that they are sold by a commercial business to a commercial business. TW AUDiO products that bear the trash can symbol shown here may only be disposed of by TW AUDiO.
  • Page 18 Operation manual T24N TW AUDiO GmbH Osterholzallee 140 71636 Ludwigsburg Germany Phone : + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
