INSTALLATION INSTRUCTIONS
The use of templates and/or accessories not produced or supplied by
MONO Equipment will invalidate the machine's warranty
MONO EQUIPMENT
Queensway
Swansea West Industrial Estate
Swansea. SA5 4EB UK
COMPLETE OPERATION AND MAINTENANCE INSTRUCTIONS
ARE AVAILABLE AT www.monoequip.com
Enter Serial No. here._____________________________________
In the event of an enquiry please quote this serial number.
OMEGA TOUCH
IMPORTANT INFORMATION
and
Tel. +44(0)1792 561234
email: spares@monoequip.com
Spares Tel.+44(0)1792 564039
FILE 35
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mono OMEGA TOUCH
Summary of Contents for Mono OMEGA TOUCH
- Page 1 In the event of an enquiry please quote this serial number. MonoEquip.com OMEGA TOUCH IMPORTANT INFORMATION INSTALLATION INSTRUCTIONS The use of templates and/or accessories not produced or supplied by MONO Equipment will invalidate the machine’s warranty MONO EQUIPMENT Tel. +44(0)1792 561234 Queensway email: spares@monoequip.com Swansea West Industrial Estate Spares Tel.+44(0)1792 564039...
-
Page 2: Safety Symbols
You must immediately report any damage or defect arising with the appliance. Unsafe equipment is dangerous. Do not use the appliance. Isolate the power supply and contact MONO or your appointed service agent. FG078 OMEGA Touch QUICKSTART RevA22 (August 2022) - Page 3 FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
- Page 4 Regulations 419.2 and 544.2. The supply to this machine must be protected by a 30mA RCD FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
- Page 5 12 Due to the essential requirement for handling heavy components during cleaning, it is recommended that protective footwear be worn when carrying out such procedures. ALL CLEANING AND MAINTENANCE OPERATIONS MUST BE MADE WITH MACHINE DISCONNECTED FROM THE POWER SUPPLY. FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
-
Page 6: Installation
3. Position the machine in the correct position for working and lock the two locking wheels to stop movement. ISOLATION IN AN EMERGENCY, SWITCH OFF AT THE ELECTRICAL MAINS WALL ISOLATOR, OR PUSH THE EMERGENCY STOP BUTTON. To release the emergency stop button, turn clockwise. STOP BUTTON FG078 OMEGA Touch QUICKSTART RevA22 (August 2022) -
Page 7: Preparing For Operation
Make sure stop button is in released position (turn clockwise if required). Select an existing program or create a new program through the on-screen menus. see section 10 operation ( cd manual pages) The machine is now ready for operation. FG078 OMEGA Touch QUICKSTART RevA22 (August 2022) - Page 8 “O” RING PART NUMBER = A900-12-010 (SUPPLIED IN BAGS OF 20) LOOP FIRST RING OVER END SLIDE RING DOWN TO GROOVE FIRST RING IN CORRECT POSITION LOOP SECOND RING OVER END SLIDE RING DOWN TO SECOND GROOVE, PASSING OVER FIRST RING FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
-
Page 9: Operating Screen
PROGRESS TO THESE BUTTONS NEXT SCREEN CONTROL CHANGES TO THE MACHINE CHOOSE LANGUAGE MACHINE SETUP PRODUCT EDITING COPYING DELETING PASSWORDS ARE REQUIRED FOR THESE FUNCTIONS. SEE PART CD manual BACK TO SELECT PRODUCT SCREEN FG078 OMEGA Touch QUICKSTART RevA22 (August 2022) -
Page 10: Cleaning Instructions
1. Open top safety guard and remove excess mixture remaining in the feed hopper. 2. Lift off front see-through safety cover and locking-ring. LOCKING RING SAFETY COVER FG078 OMEGA Touch QUICKSTART RevA22 (August 2022) - Page 11 To gain access to the inner wingnut, slide the complete hopper away from the machine body slightly (keep on support bars) - this will also disengage the pump assembly from the drive shaft. HOPPER WINGNUTS Ensure that the nuts are placed where they will not be lost. FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
- Page 12 ‘O’ RING IN GROOVE END CAP PUMP GEARS REMOVE WITH END CAP (NOT SHOWN) 3. Remove remainder of pump assembly from the machine and remove remaining end-cap to fully dismantle pump assembly components for cleaning. FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
- Page 13 Use only warm soapy water to clean these parts that should be rinsed and thoroughly dried before re-assembly. The greatest care must be taken not to drop the hopper. Do not leave any components in the hopper. FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
- Page 14 (Blank Page) FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
- Page 15 (Blank Page) FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
- Page 16 (Blank Page) FG078 OMEGA Touch QUICKSTART RevA22 (August 2022)
