3 Function

The IO-Link DISPLAY can display freely definable process values, texts and QR
codes�
Process value display (cyclic operation)
Up to four texts or numbers can be displayed simul-
taneously with the unit and a short description text�
The number of decimal places is adjustable�
Information pages
Messages such as "Coolant level low, please refill"
or "System ready to start, press 'on' button" can be
displayed in any colour, e�g� red for alarm or yellow
for warnings�
QR code
A QR code can be scanned via smartphone or
tablet and link to information online (e�g�: descrip-
tions or data sheets)� The QR code may include any
short info text (e�g� "Recipe #5") as well�
4
Thermal store
26.4
Outside
°C
64.8
Inside
°C
Thermal store
Inside
64,82
°C
Rinsing system
System ready
to start.
Press 'on' button.
Rinsing system
