Step 6: Install the front reflector
1. Remove the screw on the front reflector bracket.
2. Attach the reflector on the left side of the handlebar and secure it in place using
the screw.
Step 7: Adjusting the headlight
1. To adjust the headlight angle, use the 5mm Allen Key to loosen the adjustment
bolt (Figure 7), adjust the headlight to the desired angle.
2. Tighten the adjustment bolt to secure light in place.
Note: Before starting up the electrical system, ensure the battery is fully charged and
the battery switch is in the on position.
Figure 7
