Danfoss OF7S1 Installation Manual page 16

Sine-wave Filter OF7S1
Installation Guide
4.8
U1, V1, W1
S1x06
2 Nm (18 in-lb)
S1x07–S1x08
4 Nm (35 in-lb)
4.10
6 Nm (53 in-lb)
Fx06–Fx08
L1 U
L2 V
L3 W
Illustration 10:
16 | Danfoss A/S © 2022.05
U2, V2, W2
S1x06–S1x08
U1 U2
V1 V2
W1 W2
15 m (49 ft)
U1, V1, W1
S1x06 U2, V2, W2
U1, V1, W1
S1x07 U2, V2, W2
U1, V1, W1
S1x08 U2, V2, W2
S1x06–S1x07
SL1, SL2, PZ3, T30
S1x08
SL2, PZ3, T30, T50
4.9
U
V
W
AN405139032638en-000201 / 136R0277
Instructions
14 Nm (124 in-lb)
14 Nm (124 in-lb)
6 Nm (53 in-lb)
14 Nm (124 in-lb)
14 Nm (124 in-lb)
6 Nm (53 in-lb)
20 Nm (177 in-lb)
20 Nm (177 in-lb)
14.5 Nm (128 in-lb)
10 13
mm mm
