Danfoss OF7S1 Installation Manual page 11

Sine-wave Filter OF7S1
Installation Guide
S1x02–S1x04
2
2.1
X
A
X
Illustration 5:
Danfoss A/S © 2022.05
mm (in)
A
B
C1
C2
X
2x
X
0 mm
(0.0 in)
S1x02 S1x03
257 (10.1) 257 (10.1)
70 (2.8) 94 (3.7)
107 (4.2)
107 (4.2)
107 (4.2) 107 (4.2)
4 x M5 4 x M5
2.2
C1
C2
AN405139032638en-000201 / 136R0277 | 11
Instructions
S1x04
380 (15.0)
105 (4.1)
107 (4.2)
161 (6.3)
4 x M6
