HARDWARE DESCRIPTION
Front Panel
1) HDMI Inputs 1-8 Status LEDs
2) Power Status LED
3) LAN Status LED
Back Panel
❶
1) Reset Button (Factory Default Settings – Press & hold the reset button for 10 seconds
until the Power and LAN Status LEDs turn off)
2) HDMI Input Ports 1 – 4
3) LAN Port (Default IP: 192.168.1.168)
4) DC12V Power Adapter Port
❷
❷
❶
❸
❹
❸
5 |
P a g e
