OM13489 16-bit GPIO Daughter Card User Manual
Rev. 2.0 — 09 January 2014
Document information
Info
Content
Keywords
Fm+ Development Kit, OM13320, GPIO, OM13303
Abstract
Installation guide and User Manual for the OM13489 16-bit GPIO
Daughter Card that connects to OM13320 Fm+ Development Kit. This
board permits easy and simple evaluation of most of NXP's 16-bit I
GPIO portfolio of products.
User manual
2
C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NXP Semiconductors OM13489
Summary of Contents for NXP Semiconductors OM13489
- Page 1 Keywords Fm+ Development Kit, OM13320, GPIO, OM13303 Abstract Installation guide and User Manual for the OM13489 16-bit GPIO Daughter Card that connects to OM13320 Fm+ Development Kit. This board permits easy and simple evaluation of most of NXP’s 16-bit I GPIO portfolio of products.
- Page 2 UM10752 NXP Semiconductors OM13489 16-bit GPIO User Manual Revision history Date Description 20140109 Added A0 jumper hardware fix and CN5 schematic – changed from 14-pin to 18-pin with 4 pins not connected for correct connector seating on the Fm+ board. Active pins remain the same.
-
Page 3: Introduction
2 of JP1 and the via directly below to make connection to pin 21 on the device under test IC1. See Section 3.2 for additional details. Table 1. Devices Supported by OM13489 16-bit I C GPIO Daughter Card Device... -
Page 4: Fig 1. Pin Configuration 16-Bit Gpio Devices
OM13489 16-bit GPIO User Manual The pin configuration of these devices varies only a bit and the different pin selections are made via jumpers. 2. Features of the OM13489 16-bit GPIO Daughter Card Direct connection to OM13320 Fm+ Development kit ... -
Page 5: Fig 2. Fix Needed For Correct Operation Of A0 Jumper Jp1
4. Board Jumper Set Up 4.1 Power Supply Jumpers The power supply selections for the OM13489 is very flexible and allows for detailed analysis and evaluation of all the NXP 16-bit GPIO devices. JP3 labeled PWR selects between 5V supplied from the tester connector CN4 (jumper between pin 2 and 3 labeled TSTR) and the Fm+ board connector CN5 (jumper between pin 1 and 2). -
Page 6: Fig 3. Power Jumpers And External Power Test Points6
UM10752 NXP Semiconductors OM13489 16-bit GPIO User Manual CN3 selects between 5V and 3.3V for a second power supply needed for PCA(L)6408A. If the device under test is not PCA(L)6408A, leave this jumper open. JP4 selects between 5V and 3.3V for the main power supply on pin 16 of the device under test. -
Page 7: Fig 6. Jumper Configuration For Pca9671
UM10752 NXP Semiconductors OM13489 16-bit GPIO User Manual To configure the function pins, apply jumpers between pins 1 & 2 on JP10 and JP11 to configure device pin 2 and pin 3 as addresses. Apply a jumper between pins 2 & 3 on JP9 to configure device pin 1 as INT . -
Page 8: Fig 7. Jumper Configuration For Pca9673, Pcal9539A, Pca9539A, Pca9539R, Pca9539
UM10752 NXP Semiconductors OM13489 16-bit GPIO User Manual 4.5 PCA9673, PCAL9539A, PCA9539A, PCA9539R, PCA9539 The PCA9673 and PCA9539 series implement two address pins, RST and INT . This configuration ignores the power supply setup, but normally, only JP4 with a jumper between pins 2 &... -
Page 9: Fig 8. Jumper Configuration For Pca(L)6416
U1 pin 11 U1 pin 12 5.2 CN5 Fm+ Development Board Connector The OM13489 can connect directly to the OM13320 Fm+ Development kit via CN5. This connector provides power, I C signals and other ancillary signals. Note: The connector on the Fm+ board is a male, shrouded 14 pin type, while the connector on the GPIO board is female, 18 pin.. -
Page 10: Cn4 Tester Connector
UM10752 NXP Semiconductors OM13489 16-bit GPIO User Manual Table 3. CN5 Fm+ Board Connector CN5 Pin Number Function Board Connection — No connect — No connect SCL Bus 1 to U1 pin 14 SDA Bus 2 not used SDA2 Interrupt to INT LED and JP9 pin 3... - Page 11 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
- Page 12 Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from...
-
Page 13: Legal Information
NXP Semiconductors does not give any representations or In no event shall NXP Semiconductors, its affiliates or their suppliers be liable warranties as to the accuracy or completeness of information included herein to customer for any special, indirect, consequential, punitive or incidental and shall have no liability for the consequences of use of such information. -
Page 14: Table Of Contents
UM10752 NXP Semiconductors OM13489 16-bit GPIO User Manual 7. List of figures Fig 1. Pin Configuration 16-bit GPIO Devices ..... 4 Fig 2. Fix needed for correct operation of A0 jumper JP1 ................5 Fig 3. Power Jumpers and External Power Test Points6 Fig 4. -
Page 15: List Of Tables
UM10752 NXP Semiconductors OM13489 16-bit GPIO User Manual 8. List of tables Table 1. Devices Supported by OM13489 16-bit I C GPIO Daughter Card ..........3 Table 2. CN1 GPIO Target Board Connector Pinout ..9 Table 3. CN5 Fm+ Board Connector ......10 Table 4. -
Page 16: Contents
NXP Semiconductors OM13489 16-bit GPIO User Manual 9. Contents Introduction ............3 Features of the OM13489 16-bit GPIO Daughter Card ..............4 Pin Configuration of 16-bit GPIO Devices ..4 Power Supply Setup ........... 5 Reset, Interrupt, and Address pins selection ..5 Board Jumper Set Up ..........
