UM10751
OM13488 8-bit GPIO Daughter Card User Manual
Rev. 1.0 — 11 October 2013
Document information
Info
Content
Keywords
Fm+ Development Kit, OM13320, GPIO, OM13303
Abstract
Installation guide and User Manual for the OM13488 8-bit GPIO Daughter
Card that connects to OM13320 Fm+ Development Kit. This board
permits easy and simple evaluation of most of NXP's 8-bit I
portfolio of products.
User manual
2
C GPIO
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NXP Semiconductors OM13488
Summary of Contents for NXP Semiconductors OM13488
- Page 1 Keywords Fm+ Development Kit, OM13320, GPIO, OM13303 Abstract Installation guide and User Manual for the OM13488 8-bit GPIO Daughter Card that connects to OM13320 Fm+ Development Kit. This board permits easy and simple evaluation of most of NXP’s 8-bit I C GPIO portfolio of products.
- Page 2 UM10751 NXP Semiconductors OM13488 8-bit GPIO User Manual Revision history Date Description 20131011 Initial Release Contact information For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com UM10751 All information provided in this document is subject to legal disclaimers.
-
Page 3: Introduction
(the ordering part number suffix should be “PW” and the package designation should be SOT403-1). These leaded packages should be relatively easy to solder to the board with a low wattage, fine tipped soldering iron. Table 1. Devices Supported by OM13488 8-bit I C GPIO Daughter Card Device Description Orderable Part Number Low-voltage, 8-bit I²C-bus and SMBus I/O... -
Page 4: Features Of The Om13488 8-Bit Gpio Daughter Card
PCF8574APW interrupt The pin configuration of these devices varies only a bit and the different pin selections are made via jumpers. 2. Features of the OM13488 8-bit GPIO Daughter Card Direct connection to OM13320 Fm+ Development kit Footprint for a TSSOP16 package, user solderable ... -
Page 5: Fig 1. Pin Configuration 8-Bit Gpio Devices
UM10751 NXP Semiconductors OM13488 8-bit GPIO User Manual VCC(P) VCC(I2C-bus ) ADDR RESET P0_0 RESET P0_1 P0_7 P0_2 P0_6 P0_3 P0_5 P0_4 Fig 1. Pin Configuration 8-bit GPIO Devices 3.1 Power Supply Setup Power supply voltages may be selected from the tester connector CN4 or the Fm+ board CN2. -
Page 6: Board Jumper Set Up
4. Board Jumper Set Up 4.1 Power Supply Jumpers The power supply selections for the OM13488 is very flexible and allows for detailed analysis and evaluation of all the NXP 8-bit GPIO devices. JP3 labeled PWR selects between 5V supplied from the tester connector CN4 (jumper between pin 2 and 3 labeled TSTR) and the Fm+ board connector CN2 (jumper between pin 1 and 2). -
Page 7: Pca9534, Pca9554A, Pca9554B, Pca9554C, Pca9554, Pca9674A, Pca9674, Pcal9554B, Pcal9554C, Pcf8574, Pcf8574A
UM10751 NXP Semiconductors OM13488 8-bit GPIO User Manual Fig 3. Jumper configuration for PCA8574, PCA8574A, PCA9534, PCA9554A, PCA9554B, PCA9554C, PCA9554, PCA9674A, PCA9674, PCAL9554B, PCAL9554C, PCF8574, PCF8574A 4.3 PCA9670 The PCA9670 implements three address pins and RST . This configuration ignores the power supply setup, but normally, only JP4 with a jumper between pins 2 &... -
Page 8: Fig 5. Jumper Configuration For Pca9672, Pcal9538A, Pca9538A, Pca9538
UM10751 NXP Semiconductors OM13488 8-bit GPIO User Manual To configure the function pins, apply jumpers between pins 2 & 3 on JP9 and JP11 to configure device pin 3 as RST and pin 13 as INT . Apply a jumper between pins 1 & 2 on JP10 to configure device pin 2 as an address. -
Page 9: Fig 6. Jumper Configuration For Pca(L)6408
U1 pin 11 U1 pin 12 5.2 CN2 Fm+ Development Board Connector The OM13488 can connect directly to the OM13320 Fm+ Development kit via CN2. This connector provides power, I C signals and other ancillary signals. Note: The connector on the Fm+ board is a male, shrouded 14 pin type, while the connector on the GPIO board is female, 18 pin.. -
Page 10: Cn4 Tester Connector
UM10751 NXP Semiconductors OM13488 8-bit GPIO User Manual Table 3. CN2 Fm+ Board Connector CN2 Pin Number Function Board Connection — No connect — No connect SCL Bus 1 to U1 pin 14 SDA2 SDA Bus 2 not used Interrupt to INT LED and JP9 pin 3... -
Page 13: Legal Information
NXP Semiconductors does not give any representations or In no event shall NXP Semiconductors, its affiliates or their suppliers be liable warranties as to the accuracy or completeness of information included herein to customer for any special, indirect, consequential, punitive or incidental and shall have no liability for the consequences of use of such information. -
Page 14: Table Of Contents
UM10751 NXP Semiconductors OM13488 8-bit GPIO User Manual 7. List of figures Fig 1. Pin Configuration 8-bit GPIO Devices ....5 Fig 2. Power Jumpers and External Power Test Points6 Fig 3. Jumper configuration for PCA8574, PCA8574A, PCA9534, PCA9554A, PCA9554B, PCA9554C, PCA9554, PCA9674A, PCA9674, PCAL9554B, PCAL9554C, PCF8574, PCF8574A .... -
Page 15: List Of Tables
UM10751 NXP Semiconductors OM13488 8-bit GPIO User Manual 8. List of tables Table 1. Devices Supported by OM13488 8-bit I C GPIO Daughter Card ..........3 Table 2. CN1 GPIO Target Board Connector Pinout ..9 Table 3. CN2 Fm+ Board Connector ......10 Table 4. -
Page 16: Contents
NXP Semiconductors OM13488 8-bit GPIO User Manual 9. Contents Introduction ............3 Features of the OM13488 8-bit GPIO Daughter Card ..............4 Pin Configuration of 8-bit GPIO Devices ... 4 Power Supply Setup ........... 5 Reset, Interrupt, and Address pins selection ..5 Board Jumper Set Up .......... - Page 17 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: OM13488UL...
