- Page 1 Quick Start Guide OM15080-JN5189 USB DONGLE JN5189 DONGLE...
- Page 2 Quick Start Guide GET TO KNOW THE OM15080-JN5189 Power and Power and USB2UART USB2UART QSPI QSPI Application Application JN5189 JN5189 Converter Converter Connector Connector Flash Flash Reset Reset 2.4G 2.4G Button Button Antenna Antenna Figure 1: OM15080-JN5189 Board Components...
- Page 3 HOW TO GET STARTED Plug in the OM15080-JN5189 board into a PC. A green power LED and a red application LED will illuminate. The OM15080-JN5189 comes preprogrammed with a Zigbee Smart® sniffer application. Explore more out-of-box demos and download software and tools on www.nxp.com/OM15080-JN5189.
- Page 4 The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. ® and any use of such marks by NXP Semiconductors is under license.© 2020 NXP B.V. Document Number: JN5189DONQSG REV 0 Agile Number: 926-45629 Rev A...
