DEMO MANUAL DC2235A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C2
2 5 C3, C6, C10, C12, C14
3 1 C4
4 1 C13
5 2 R3, R9
6 2 R11, R12
7 1 U1
Additional Demo Board Circuit Components
8 1 C1
9 0 C5, C7, C9 (OPT)
10 2 C8, C11
11 2 C15, C16
12 3 R1, R6, R13
13 2 R2, R8
14 2 R4, R10
15 3 R5, R7, R14
16 1 R15
17 1 R16
Hardware
18 3 JP1, JP2, JP3
19 1 JP4
20 2 JP5, JP6
21 6 JP1-JP6
22 10 E1, E2, E7-E14
23 4 E3-E6
24 4 MH1-MH4
25 1 SW1
6
PART DESCRIPTION
CAP, CHIP, X7R,10µF, ±10%, 25V, 1206
CAP, CHIP, X7S, 10µF, ±10%, 50V, 1210
CAP, CHIP, X7R, 1µF, ±10%, 25V, 0805
CAP, CHIP, X7R, 1µF, ±10%, 50V, 1206
RES 604kΩ 1/16W 1% 0402 SMD
RES 52.3kΩ 1/16W 1% 0402 SMD
LOW NOISE DUAL SUPPLY WITH BOOST AND
INVERTING CHARGE PUMPS
CAP, CHIP, X7R,10µF, ±10%, 25V, 1206
CAP, CHIP, 25V, 0603
CAP, CHIP, X7R, .1µF, ±10%, 16V, 0402
CAP, CHIP, NPO, 10pF, ±5%, 50V, 0402
RES 1.0MΩ 1/16W 5% 0402 SMD
RES 1.0MΩ 1/16W 1% 0402 SMD
RES 165kΩ 1/16W 1% 0402 SMD
RES 4.7kΩ 1/16W 5% 0402 SMD
RES 909kΩ 1/16W 1% 0402 SMD
RES 200kΩ 1/16W 1% 0402 SMD
HEADER, 3-PIN 1 ROW 0.079CC
HEADER, 4-PIN 1 ROW 0.079CC
HEADER, 2 × 3 PINS, 2mm
SHUNT, 2mm
TP, TURRET, 0.094", PBF
TURRET, 0.061" DIA
STAND-OFF, NYLON 0.375" TALL
10mm × 2.5mm, SLIDE SWITCH, THT
MANUFACTURER/PART NUMBER
WURTH ELEKTRONIK, 885012208069
TDK, C3225X7S1H106K250AB
TDK, C2012X7R1E105K125AB
TDK, C3216X7R1H105K160AB
VISHAY, CRCW0402604KFKED
VISHAY, CRCW040252K3FKED
LINEAR TECH., LTC3265EDHC#PBF
WURTH, 885012208069
MURATA, GRM155R71C104KA88D
AVX, 04025A100JAT2A
VISHAY, CRCW04021M00JNED
VISHAY, CRCW04021M00FKED
VISHAY, CRCW0402165KFKED
VISHAY, CRCW04024K70JNED
VISHAY, CRCW0402909KFKED
VISHAY, CRCW0402200KFKED
SULLIN, NRPN031PAEN-RC
SULLIN, NRPN041PAEN-RC
SULLIN, NRPN032PAEN-RC
SAMTEC, 2SN-BK-G
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
KEYSTONE, 8832 (SNAP ON)
WURTH ELEKTRONIK, 450301014042
dc2235af
