- Page 1 Dresser 1/35 Version:08/23/2022...
- Page 2 2/35...
- Page 3 D x 4 8+2 A x 3 6+1 B x 5 6+1 C x 5 6+1 E x 1 6 3 x 12 mm 6 x 35 mm 15 x 10 mm 5 x 40 mm G x 7 F x 7 H x 1 6 J x 1 K x 4 0+1...
- Page 4 4/35...
- Page 5 5/35...
- Page 6 6/35...
- Page 7 D x 8 3x12mm 3 x 12 mm 4 x 25mm Fix slide rail(CL) to No.1 plate with screw(D) as shown. 7/35...
- Page 8 D x 10 B x 3 3x12mm 6x35mm 3 x 12 mm 4 x 25mm Fix slide rail(CR) to No.2 plate with screw(D). Flip the plate, and fix slide rail(CL) with screw(D), insert quickfit screw(B) into corresponding holes with a screwdriver as shown.
- Page 9 J x 1 E x 4 A x 4 5 x 40 mm Attach No.3 plate to No.1 and No.2 with wooden dowel(A) and then fix with screw(E) as shown. 9/35...
- Page 10 E x 4 A x 4 5 x 40 mm Fix No.4 legs to No.3 plate with wooden dowel(A) and then fix with screw(E) as shown. 10/35...
- Page 11 Slide No.6 plate into available slots as shown. 11/35...
- Page 12 B x 3 D x 2 6x35mm 3x12mm Insert quickfit screw(B) into corresponding holes in No.7 plate 3 x 12 mm 4 x 25mm with a screwdriver as shown. Fix slide rail(CR) with screw(D) as shown. 12/35...
- Page 13 C x 6 A x 2 15x10mm Connect No.2 and No.7 plate with No.8 plate, turn cam lock(C) clockwise to tighten. 180° 180° Connect No.2 and No.7 plate with No.9 plate with wooden dowel(A), turn cam lock(C) clockwise to tighten as shown. 13/35...
- Page 14 B x 8 D x 8 6x35mm 3x12mm 3 x 12 mm 4 x 25mm Insert quickfit screw(B) into corresponding holes in No.10 plate with a screwdriver as shown. Attach No.13 plate to No.11 and No.12 respectively with screw(D) as shown. 14/35...
- Page 15 C x 8 A x 8 15x10mm 180° Attach No.11 and No.12 plate to No.10 plate with wooden dowel(A), turn cam lock(C) clockwise to tighten as shown. 15/35...
- Page 16 B x 8 6x35mm Insert quickfit screw(B) into corresponding holes in No.14 plate with a screwdriver as shown. 16/35...
- Page 17 E x 8 A x8 5 x 40 mm Cover No.14 plate to No.11 and No.12 plate with wooden dowel(A)and then fix with screw(E) as shown. 17/35...
- Page 18 C x 8 A x 6 15x10mm Connect two assembled components with wooden dowel(A), turn cam lock(C) clockwise to tighten as shown. 180° 18/35...
- Page 19 K x 12 4x30mm Attach No.15 back plate to No.10,11,12 plate with screw(K) as shown. 19/35...
- Page 20 B x 16 F x 4 G x 4 6x35mm 4x16mm Insert quickfit screw(B) into No.16 plate with a screwdriver as shown. Fix knob(G) with screw(F) as shown. 20/35...
- Page 21 K x 16 4x30mm 5 x 40 mm 4 x 30mm 4 x 35mm Attach No.17 and No.19 plate to No.18 with screw(K) as shown. Slide No.20 plate into available slots as shown. 21/35...
- Page 22 C x 16 15x10mm Attach No.16 to No.17 and No.19 plate and turn cam lock(C) clockwise to tighten as shown. 180° 22/35...
- Page 23 Dx 16 DL x 4 DR x 4 3 x 12mm 3 x 12 mm 4 x 25mm Fix runner(DL) and (DR) to No.17 and No.19 plate respectively with screw(D) as shown. 23/35...
- Page 24 B x 4 F x 1 G x 1 6x35mm 4x16mm Insert quickfit screw(B) into No.21 plate with a screwdriver as shown. Fix knob(G) with screw(F) as shown. 24/35...
- Page 25 K x 4 4x30mm 5 x 40 mm 4 x 30mm 4 x 35mm Attach No.22 and No.24 plate to No.23 with screw(K) as shown. Slide No.25 plate into available slots as shown. 25/35...
- Page 26 C x 4 15x10mm Attach No.21 to No.22 and No.24 plate and turn cam lock(C) clockwise to tighten as shown. 180° 26/35...
- Page 27 Dx 4 DL x 1 DR x 1 3 x 12mm 3 x 12 mm 4 x 25mm Fix runner(DL) and (DR) to No.22 and No.24 with screw(D) as shown. 27/35...
- Page 28 B x 8 F x 2 G x 2 6x35mm 4x16mm Insert quickfit screw(B) into No.26 plate with a screwdriver as shown. Fix knob(G) with screw(F) as shown. 28/35...
- Page 29 K x 8 4x30mm 5 x 40 mm 4 x 30mm 4 x 35mm Attach No.27 and No.29 plate to No.28 with screw(K) as shown. Slide No.30 plate into available slots as shown. 29/35...
- Page 30 C x 8 15x10mm Attach No.26 to No.27 and No.29 plate and turn cam lock(C) clockwise to tighten as shown. 180° 30/35...
- Page 31 Align rails, slide all drawers. 31/35...
- Page 32 H x 16 4 x 25 mm 3 x 12 mm 4 x 25mm Connect No.31 and No.32 plate with No.33 using screw(H) as shown. 32/35...
- Page 33 L x 8 6x40mm Fix No.34 leg to No.33 with screw(L) as shown. 33/35...
- Page 34 B x 6 6 x 35mm Insert quickfit screw(B) into corresponding holes in No.5 plate with a screwdriver as shown. 34/35...
- Page 35 A x 4 C x 6 15x10mm Cover No.5 plate to the component with wooden dowel(A), turn cam lock(C) clockwise to tighten as shown. 180° 35/35...
- Page 36 WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
- Page 37 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
