THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT
SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
‐ Unit can tip over causing severe injury or death.
‐ Anchor unit to stud in wall (if instructed to).
‐ Do Not allow children to climb on unit.
Easy
Tough
‐ Put heavy items on lower shelves or drawers.
Assembly Di culty Meter
Advertisement
Related Manuals for FUFU & GAGA WFKF210095
Summary of Contents for FUFU & GAGA WFKF210095
- Page 1 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. ‐ Unit can tip over causing severe injury or death. ‐ Anchor unit to stud in wall (if instructed to). ‐ Do Not allow children to climb on unit. Easy Tough ‐...
-
Page 2: Helpful Hints
Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1 - 2 ESTIMATED ASSEMBLY TIME: 1 HOUR ‐ Open your item in the area you plan to keep it to avoid excessive heavy lifting. ‐ Identify, sort and count the parts before attempting assembly. ‐... -
Page 3: Before You Start
Before You Start ‐ Read through each step carefully and follow the proper order ‐ Separate and count all your parts and hardware ‐ Give yourself enough room for the assembly process ‐ Have the following tools: Hammer ‐ Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. - Page 4 Parts assembly diagram...
- Page 5 installation drawing 1 The installation steps of other drawers are the same 1.Screw A into the corresponding 2.Screw A into the corresponding hole of No. 3 plate, then insert hole of No. 2 plate, then insert No. 1 plate into A, and finally No.
- Page 6 installation drawing 2 First install the drawer . Screw in the eccentric screw on the 2 and 3 plates first The sheet needs to be aligned with the slot Screw in the eccentric screw on the 5 and 6 plates first...
- Page 7 installation drawing 3 Screw in the eccentric First install the drawer . screw on the 4 and 6 plates first Screw in the eccentric screw on the 7 and 8 plates first...
- Page 8 installation drawing 4 When placing D, it should be noted that the round hole should be aligned with the direction of screw in C Second install the cabinet. 1.Place B in the corresponding position of plate 13 and plate 14 ...
- Page 9 installation drawing 5 Install Nos. 12 13,14,15 and 16 using A and B as shown in the picture. Note that the screws are hidden below and on the back Tighten all B's as shown Install using C and D between No.
- Page 10 installation drawing 6 Insert the sheet along the grooves as shown...
- Page 11 installation drawing 7 Screw A into the corresponding hole of Table top plate Align the slide rail of the drawer with the slide rail of the cabinet and push it forward As shown in the figure, align the holes to link the table top using B to install and tighten...
- Page 12 installation drawing 8 Use A and B to install No. 20 on the mirror. Install No. 21 and No. 22 using An and B and tighten the screws as instructed in the picture.
- Page 13 installation drawing 9 Use A and B to complete the installation according to the picture instructions. Note that the screws are hidden below Lock A with B, place D in plate 23, and screw C...
- Page 14 installation drawing 10 Screw in A on the panel Align the upper part with A and connect it with the lower part, then lock and fix it with B...
- Page 15 installation drawing 11 Put D into the corresponding hole of plate 27, and then screw C into plate 28 Fix H on the inside of two 28 plates with G Fix H under the soft bag with G...
-
Page 16: Star Rating
If you have any questions about the product, please do not hesitate to contact customer service. 5 Star Rating Visit your local retailer’s website,rate your purcha sed product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this FAFA&GAGA product, and to give us your valuable feedback.
