8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-841-1350 HAMPTONBAY.COM THANK YOU continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
Frame Lower leg assembly Steel table Small top Large top Knob Stake Setting Up the Canopy LOCKING THE FRAME ATTACHING THE CANOPY OPENING THE CANOPY FRAME With a partner, start on a short side. Place With a partner, stand across from each other. Unfold the small top (D) and place it over the one hand on the upper corner, and use the Grab one leg of the frame (A) in each hand as...
Setting Up the Canopy (continued) SECURING THE CANOPY IN PLACE Insert two stakes (G) into the foot of each canopy leg if possible. IMPORTANT: Always secure your product with stakes. Taking Down the Canopy REMOVING THE STAKES Pull up all stakes (G) from the ground. TAKING DOWN THE TABLE With one person holding the table (C), the another person removing the knob (F) to detach the table from the leg.
Spare Parts To access spare parts, please call toll free 1-888-502-9589, Monday - Friday, 9:00 AM - 4:00 PM PST; or visit www.crown-shades.com; or email care@OutdoorDesignz.com. Part Description Reference No. Part Description Reference No. SCAN ME FOR MORE Central cap Short Eave Assembly UNEA08BK00 UNCP00BK01...
