SPACEMAKER PS53 Owner's Manual & Assembly Manual page 6

HARDWARE LIST
For missing or damaged parts contact Customer Service. Do not return to store.
1-800-851-1085 or assist@arrowsheds.com
Part
Key Part
No. No. Description
1 65103
Hex Nut (#8-32)
2 65923
Small Bolt (#8-32 x 3/8) (10 mm)
3 65004
Small Screw (#8AB x 5/16) (8 mm)
4 66783
Flat Head Bolt (#8-32 X 1/2) (13 mm)
5 66692
Tapping Screw (#10ABx1) (25 mm)
6 66609
Hinge
7 66183L
Left Roof Trim Cap
8 66183R
Right Roof Trim Cap
9 67236
Adhesive Pads (2 per sheet)
10 66684
Top Latch Spring
11 66808
Bottom Latch Spring
12 66646
Washer Sheet
13 30000
Locking Handle Right
14 30001
Left Handle
The fasteners used in each step are shown actual size at the top
of each page. If you are unsure which fastener to use, hold it up
to the picture and use the one that matches.
Hardware Views by Key No.
Qty.
1
List
48
24
11/32 Hex.
174
4
24
2
4
#2 Phillips
2
6
2
1
1
1
9
4
1
1
12
6
2 3
#2 Phillips
#2 Phillips
5
#2 Phillips
7 8
10 11
13 14
