USER GUIDE
ePMP (802.11ac/ax)
System Release 4.7

Advertisement

Table of Contents
loading

Related Manuals for Cambium Networks ePMP Series

Summary of Contents for Cambium Networks ePMP Series

  • Page 1 USER GUIDE ePMP (802.11ac/ax) System Release 4.7...
  • Page 2 Cambium recommends reviewing the Cambium Networks website for the latest changes and updates to products. Cambium does not assume any liability arising out of the application or use of any product, software, or circuit described herein;...

  • Page 3: Table Of Contents

    Contents Contents About This User Guide Problems and warranty Reporting problems Repair and service Warranty Security advice Precautionary statements Warning Federal Communication Commission Interference Statement IC Interference Statement Attention Note Caring for the environment In EU countries In non-EU countries Chapter 1: Product Description Overview of ePMP Purpose –...
  • Page 4 Force 300-19 Force 300-19R Force 300-16 Force 300-13 Force 300-13L Force 300 CSM Force 300 CSML Force 425 Force 400C Force 4600C Force 5/6GHz 2 x 2 dish antenna Force 4525 Force 4525L Force 4625 Typical installation equipment Wireless operation MU-MIMO MIMO Smart beamforming (ePMP 2000/3000 series)

  • Page 5: Contents

    SNMP Network Time Protocol (NTP) Software upgrade Further reading on system management Chapter 2: System Hardware Site Planning Site installation Grounding and lightning protection Lightning protection zones ePMP 3000 Access Point ePMP 3000 Access Point description ePMP 3000 Access Point part numbers ePMP 3000 Access Point mounting bracket ePMP 3000 Access Point interfaces ePMP 3000 Access Point specifications...
  • Page 6 ePMP 4500C Access Point mounting bracket ePMP 4500C Access Point interfaces ePMP 4500C Access Point specifications ePMP 4500C Access Point heater ePMP 4500C Access Point wind loading ePMP 4500C Access Point mounting instructions ePMP 4500C Access Point software packages ePMP 4500 Access Point ePMP 4500 Access Point description ePMP 4500 Access Point part numbers ePMP 4500 Access Point mounting bracket...
  • Page 7 ePMP 4500L Access Point interfaces ePMP 4500L Access Point specifications ePMP 4500L Access Point heater ePMP 4500L Access Point wind loading Mounting instructions ePMP 4500L Access Point software packages ePMP 5/6GHz 4 x 4 sector antenna Force 300-25 Force 300-25 integrated description Force 300-25 part numbers Force 300-25 mounting bracket Force 300-25 interfaces...
  • Page 8 Force 300-19 heater Force 300-19 wind loading Force 300-19 software packages Force 300-19R Force 300-19R integrated description Force 300-19R part numbers Force 300-19R mounting bracket Force 300-19R interfaces Force 300-19R specifications Force 300-19R heater Force 300-19R wind loading Force 300-19R software packages Force 300-16 Force 300-16 integrated description Force 300-16 part numbers...
  • Page 9 Force 300-13L part numbers Force 300-13L interfaces Force 300-13L specifications Force 300-13L wind loading Force 300-13L LEDs Force 300-13L software packages Force 300 CSM Force 300 CSM description Force 300 CSM part numbers Force 300 CSM interfaces Force 300 CSM specifications Force 300 CSM heater Force 300 CSM wind loading Force 300 CSM software packages...
  • Page 10 ePMP MP 3000 software packages Force 425 Force 425 integrated description Force 425 part numbers Force 425 mounting bracket with Range Extender Force 425 interfaces Force 425 specifications Force 425 heater Force 425 wind loading Force 425 software packages Force 400C Force 400C integrated description Force 400C part numbers Force 400C interfaces...
  • Page 11 Force 4525 interfaces Force 4525 specifications Force 4525 heater Force 4525 wind loading Force 4525 mounting instructions Force 4525 software packages Force 4525L Force 4525L integrated description Force 4525L part numbers Force 4525L interfaces Force 4525L specifications Force 4525L heater Force 4525L wind loading Force 4525L mounting instructions Force 4525L software packages...
  • Page 12 Ethernet standards and cable lengths Outdoor Cat5e cable Surge suppression unit Gigabit Ethernet Surge Suppressor cnPulse sync generator Chapter 3: System Planning Radio spectrum planning General wireless specifications Regulatory limits Conforming to the limits Available spectrum Channel bandwidth Link planning Range and obstacles Path loss Adaptive modulation...
  • Page 13 Troubleshooting the radio link The module has lost or does not establish radio connectivity Module exhibiting frequent boots or disconnects Link is unreliable or does not achieve the data rates required Resetting ePMP to factory defaults by power cycling Glossary Cambium Networks Contents...

  • Page 14: Problems And Warranty

    Problems and warranty Reporting problems At Cambium Networks, we know what it takes to keep a growing network running optimally. We provide multiple layers of support including training, online documentation, technical support, information- sharing with an experienced community of users, software downloads, warranty services, and repair.

  • Page 15: Security Advice

    For warranty assistance, contact the reseller or distributor. Security advice Cambium Networks’ systems and equipment provide security parameters that can be configured by the operator based on their particular operating environment. Cambium recommends setting and using these parameters following industry-recognized security practices. Security aspects to be considered are protecting the confidentiality, integrity, and availability of information and assets.

  • Page 16: About This User Guide

    Reorient or relocate the receiving antenna. ⚫ Increase the separation between the equipment and receiver. ⚫ Connect the equipment into an outlet on a circuit different from that to which the receiver is ⚫ connected. Consult the dealer or an experienced radio/TV technician for help. ⚫...
  • Page 17 sont strictement interdits pour une utilisation avec cet appareil. The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point operation as appropriate. le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5725-5850 MHz) doit se conformer à...
  • Page 18 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 19: Attention

    IC MPE distance: 20 cm Attention Precautionary statements with the Attention tag precede instructions that are used when there is a possibility of damage to systems, software, or individual items of equipment within a system. However, this damage presents no danger to personnel. An attention statement has the following format: Note Precautionary statements with the Note tag indicate the possibility of an undesirable situation or provide additional information to help the reader understand a topic or concept.

  • Page 20: In Non-Eu Countries

    Disposal of surplus packaging Do not dispose of surplus packaging in landfill sites. In the EU, it is the individual recipient’s responsibility to ensure that packaging materials are collected and recycled according to the requirements of EU environmental law. In non-EU countries In non-EU countries, dispose of Cambium equipment and all surplus packaging in accordance with national and regional regulations.

  • Page 21: Chapter 1: Product Description

    5 GHz and 6 GHz bands. The ePMP Series acts as a transparent bridge between two segments of the operator and customers’ networks. In this sense, it can be treated as a virtual wired connection between the Access Point (AP) and the Subscriber Module (SM).
  • Page 22 ePMP 3000 supports backward and forward compatibility with ePMP 802.11n devices to provide an ⚫ immediate sector upgrade to 802.11ac Wave 2 performance, and also to support future upgrades of networks operating ePMP 1000/2000 APs. ePMP 3000 is based on highly integrated wireless semiconductor components designed to meet the ⚫...

  • Page 23: Epmp 3000L

    * The 10 MHz Channel Bandwidth is only supported with Force 300-19R SM. ePMP 3000L The ePMP 3000L is the third-generation Access Point (AP) that carries on the interference tolerance mechanisms with an emphasis on high-performance in low-density point to multipoint sectors. The ePMP 3000L is a 2x 2 MIMO connectorized AP that can support a wide variety of deployments including 90/120-degree sectors, narrow-sector horns, or even 360-degree Omni coverage.

  • Page 24: Epmp Mp 3000 Micropop

    Characteristic Value Wireless link condition LoS, near LoS Scheduler Connectivity Ethernet Operating frequencies Unlicensed bands, 5 GHz Channel Bandwidth 20 MHz, 40 MHz, 80 MHz Data rate Up to 1+ Gbps Sector Throughput ePMP MP 3000 MicroPoP The ePMP MP 3000 MicroPoP is an integrated AP designed to serve short-range, low-density applications.

  • Page 25: Epmp 4500

    Figure 4: ePMP 4500C A summary of the main ePMP 4500C characteristics are listed under Table Table 2 Main characteristics of theePMP 4500C Series Characteristic Value Topology Wireless link condition LoS, near LoS Scheduler WLR, TDD Connectivity Ethernet Operating frequencies Unlicensed bands, 5 GHz Channel Bandwidth 20 MHz, 40 MHz, 80 MHz...

  • Page 26: Epmp 4600

    Figure 5: ePMP 4500 A summary of the main ePMP 4500 characteristics are listed under Table Table 2 Main characteristics of the ePMP 4500 Series Characteristic Value Topology Wireless link condition LoS, near LoS Scheduler WLR, TDD Connectivity Ethernet Operating frequencies Unlicensed bands, 5 GHz Channel Bandwidth 20 MHz, 40 MHz, 80 MHz...

  • Page 27: Epmp 4500L

    Figure 6: ePMP 4600 A summary of the main ePMP 4600 characteristics are listed under Table Table 2 Main characteristics of theePMP 4600 Series Characteristic Value Topology Wireless link condition LoS, near LoS Scheduler WLR, TDD Connectivity Ethernet Operating frequencies Unlicensed bands, 6 GHz Channel Bandwidth 20 MHz, 40 MHz, 80 MHz, 160 MHz...
  • Page 28 Figure 7: ePMP 4500L A summary of the main ePMP 4500L characteristics are listed under Table Table 2 Main characteristics of theePMP 4500L Series Characteristic Value Topology PMP or PTP Wireless link condition LoS, near LoS Scheduler WLR, TDD Connectivity Ethernet Operating frequencies Unlicensed bands, 5 GHz...

  • Page 29: Epmp 5/6Ghz 4 X 4 Sector Antenna

    ePMP 5/6GHz 4 x 4 sector antenna Figure 8: ePMP 5/6 GHz 4 x 4 sector antenna Force 300-25 The Force 300-25 is a rugged high-capacity outdoor point-to-multipoint or point-to-point link wireless device in the unlicensed 5 GHz frequency bands with a maximum UDP throughput of 500+ Mbps (when operating with 80 MHz channel bandwidth).

  • Page 30: Force

    Figure 9: Force 300-25 A summary of the main Force 300-25 characteristics are listed under Table Table 3 Main characteristics of the Force 300-25 Series Characteristic Value Topology PMP, PTP Wireless link condition LoS, near LoS Scheduler Connectivity Ethernet Operating frequencies Unlicensed bands, 5 GHz Channel Bandwidth 20 MHz, 40 MHz, 80 MHz...

  • Page 31: Force 300-19R

    Figure 10: Force 300-19 A summary of the main Force 300-19 characteristics are listed under Table 4. Table 4 Main characteristics of the Force 300-19 Series Characteristic Value Topology PMP, PTP Wireless link condition LoS, near LoS Scheduler Connectivity Ethernet Operating frequencies Unlicensed bands, 5 GHz Channel Bandwidth...
  • Page 32 Figure 11: Force 300-19R A summary of the main Force 300-19R characteristics is listed under Table Table 5 Main characteristics of the Force 300-19R Series Characteristic Value Topology PMP, PTP Wireless link condition LoS, near LoS Scheduler Connectivity Ethernet Operating frequencies Unlicensed bands, 5 GHz Channel Bandwidth 10/20/40/80 MHz...

  • Page 33: Force

    Force 300-16 The Force 300-16 is a rugged high-capacity outdoor point-to-multipoint or point-to-point link wireless device in the unlicensed 5 GHz frequency bands with a maximum UDP throughput of 500+ Mbps (when operating with 80 MHz channel bandwidth). It is capable of operating in line-of-sight (LoS) and near-LoS conditions.
  • Page 34 Force 300-13 The Force 300-13 is a rugged high-capacity outdoor Point-to-Multipoint or Point-to-Point link wireless device in the unlicensed 5 GHz frequency bands with a maximum UDP throughput of 500+ Mbps (when operating with 80 MHz channel bandwidth). It can operate in line-of-sight (LoS). Force 300-13 is available as an integrated unit with a dual-polarized 13 dBi flat-panel antenna.

  • Page 35: Force 300-13L

    Force 300-13L The Force 300-13L is an affordable subscriber module in the ePMP Force 300 series. The Force 300-13L uses 802.11ac technology and supports MU-MIMO and other features offered by the ePMP 3000 and ePMP 3000L APs. It is also backward compatible with the ePMP 2000 using backward compatibility features.
  • Page 36 a Connectorized device with support for RF Element Twistport™ adaptors. The Force 300 CSM device is based on highly integrated wireless semiconductor components designed to meet the IEEE 802.11ac standard. Management of the unit is conducted via the same interface as the bridged traffic (in-band Management). An over view of Force 300 CSM is shown in Figure Force 300 CSM...

  • Page 37: Force 300 Csml

    Force 300 CSML The Force 300CSML is an affordable subscriber module in the ePMP Force 300 series. The Force 300 CSML uses 802.11ac technology and supports MU-MIMO and other features offered by the ePMP 3000 and ePMP 3000L APs. It is also backward compatible with the ePMP 2000 using backward compatibility features.

  • Page 38: Force 400C

    Figure 17: Force 425 integrated Force 400C The Force 400C device is a self-contained transceiver unit that houses both radio and networking electronics. An overview of Force 400C is shown in Figure Figure 18: Force 400C integrated Force 4600C The Force 4600C device is a self-contained transceiver unit that houses both radio and networking electronics.

  • Page 39: Force 5/6Ghz 2 X 2 Dish Antenna

    Figure 19: Force 4600C integrated Force 5/6GHz 2 x 2 dish antenna Figure 20: Force 5/6 GHz 2 x 2 dish antenna Force 4525 The Force 4525 device is a self-contained transceiver unit that houses both radio and networking electronics. The Force 4525 uses 802.11ac technology and supports MU-MIMO. It is also backward compatible with the ePMP XXXX using backward compatibility features.

  • Page 40: Force 4525L

    Force 4525 integrated Figure 21: Force 4525L The Force 4525L device is a self-contained transceiver unit that houses both radio and networking electronics. The Force 4525L uses 802.11ac technology and supports MU-MIMO. It is also backward compatible with the ePMP XXXX using backward compatibility features. The Force 4525L is powered by standard power-over-Ethernet to a 1000BASE-T port.

  • Page 41: Typical Installation Equipment

    Figure 23: Force 4625 integrated Typical installation equipment The ePMP is a solution consisting of integrated outdoor units, indoor power supply units / LAN injectors, cabling, and surge suppression equipment. The main hardware components of an ePMP installation are as follows: ePMP 3000 Access Point: A connectorized outdoor transceiver unit containing all the radio, ⚫...

  • Page 42: Wireless Operation

    Smart beamforming (ePMP 2000/3000 series) Powered by Hypure™ technology, ePMP series APs feature Smart Beamforming. This powerful addition to your network creates narrow, targeted beams to each subscriber, rather than relying on a traditional wide beam, blocking out multiple sources of interference to keep performance high.

  • Page 43: Smart Antenna Key Advantages

    Figure 24: Smart beamforming Smart antenna key advantages Eliminate Uplink Interference: Smart Beamforming delivers dramatic performance improvements ⚫ when dealing with strong co-channel uplink interference, maximizing network performance. Consistent Performance in High Interference: By mitigating significant sources of interference, ⚫ packet loss and retransmissions are kept to a minimum, keeping your network applications working at their best.

  • Page 44: Adaptive Modulation

    Adaptive modulation ePMP 3000 can transport data over the wireless link using several different modulation modes ranging from 256-QAM to QPSK. For a given channel bandwidth and TDD frame structure, each modulation mode transports data at a fixed rate. Also, the receiver requires a given signal-to-noise ratio to successfully demodulate a given modulation mode.

  • Page 45: Further Reading On The Wireless Operation

    Maximum transmit power ⚫ Radar avoidance (future release) ⚫ Frequency range ⚫ Further reading on the wireless operation For information on planning wireless operation, see: The regulatory restrictions that affect radio spectrum usages, such as frequency range and radar ⚫ avoidance are described under Radio spectrum planning.

  • Page 46: Webserver

    The management agent supports fault and performance management utilizing an SNMP interface. The management agent is compatible with SNMP v2c using one Management Information Base (MIB) file which is available for download from the Cambium Networks support site: https://support.cambiumnetworks.com/files/epmp. Network Time Protocol (NTP) The clock supplies accurate date and time information to the system.

  • Page 47: Further Reading On System Management

    Further reading on system management For more information on system management, see Operation and Troubleshooting. Chapter 1: Product Description...

  • Page 48: Chapter 2: System Hardware

    Chapter 2: System Hardware This chapter describes the site planning and hardware components of an ePMP link. The following topics are described in this chapter: Factors to be considered when planning the proposed network is described under Site planning. ⚫ The ePMP 3000 Access Point hardware, part numbers, mounting equipment, and specifications ⚫...

  • Page 49: Site Planning

    The ePMP MP 3000 MicroPOP module hardware, part numbers, mounting equipment, and ⚫ specifications are described under ePMP MP3000 MicroPoP. The Force 425 module hardware, integrated description, part numbers, mounting equipment, and ⚫ specifications are described under Force 425. The Force 400C module hardware, integrated description, part numbers, mounting equipment, ⚫...
  • Page 50 Details of lightning protection methods and requirements can be found in the international standards IEC 61024-1 and IEC 61312-1, the U.S. National Electric Code ANSI/NFPA No. 70-1984, or section 54 of the Canadian Electric Code. Figure 25: Access Point installation diagram Chapter 2: System Hardware...

  • Page 51: Lightning Protection Zones

    Figure 26: Subscriber / Point-to-Point installation diagram Lightning protection zones Use the rolling sphere method (Figure 27) to determine where it is safe to mount equipment. An imaginary sphere, typically 50 meters in radius, is rolled over the structure. Where the sphere rests against the ground and a strike termination device (such as a finial or ground bar), all the space under the sphere is considered to be in the zone of protection (Zone B).

  • Page 52: Epmp 3000 Access Point

    Figure 27: Rolling sphere method to determine the lightning protection zones Assess locations on masts, towers, and buildings to determine if the location is in Zone A or Zone B: Zone A: In this zone a direct lightning strike is possible. Do not mount equipment in this zone. ⚫...

  • Page 53: Epmp 3000 Access Point Description

    ePMP 3000 Access Point description The ePMP 3000 AP is a self-contained transceiver unit that houses both radio and networking electronics. It is available as a connectorized unit for use with a separate 4x4 MU-MIMO Sector/Dual-Horn/Omni antenna and an optional Smart Antenna (for uplink beam steering). An overview of ePMP 3000 is shown in Figure Figure 28:...

  • Page 54: Epmp 3000 Access Point Mounting Bracket

    Cambium description Cambium part number ePMP 3000 5GHz Access Point Radio (India) (India Cord) C050910A402A ePMP 3000 5 GHz Access Point Radio (ROW) (China cord) C050910A501A ePMP 3000 5 GHz Access Point Radio (ROW) (Brazil cord) C050910A601A ePMP 3000 5 GHz Access Point Radio (ROW) (Argentina cord) C050910A701A ePMP 3000 5 GHz Access Point Radio (ROW) (ANZ cord) C050910A801A...

  • Page 55: Epmp 3000 Access Point Interfaces

    Figure 29: ePMP 3000 Access Point module mounting bracket ePMP 3000 Access Point interfaces The Ethernet port is located at the bottom of the unit. This interface is described in Table 14. Table 14 ePMP 3000 Series – rear interfaces Connector Interface Description...

  • Page 56: Epmp 3000 Access Point Heater

    Table 15 ePMP 3000 Access Point physical specifications Category Specification Dimensions (Length x Width x 22.2 cm x 12.4 cm x 4.5 cm (8.75 in x 4.9 in x 1.75 in) without Height) brackets Weight 0.7 kg (1.5 lbs) without brackets Table 16 ePMP 3000 Access Point environmental specifications Category Specification...

  • Page 57: Epmp 3000 Access Point Software Packages

    Wind blowing on the device will subject the mounting structure to significant lateral force. The magnitude of the force depends on both wind strength and the surface area of the device. Wind loading is estimated using the following formulae: Force (in kilograms) = 0.1045aV Where: the surface area in square meters wind speed in meters per second...

  • Page 58: Epmp 3000L Access Point Description

    ePMP 3000L Access Point interfaces ⚫ ePMP 3000L Access Point specifications ⚫ ePMP 3000L Access Point heater ⚫ ePMP 3000L Access Point wind loading ⚫ ePMP 3000L Access Point software packages ⚫ ePMP 3000L Access Point description The ePMP 3000L device is a self-contained transceiver unit that houses both radio and networking electronics.

  • Page 59: Epmp 3000L Access Point Mounting Bracket

    Cambium description Cambium part number ePMP 3000L 5 GHz Access Point Radio (EU) (EU cord) C050910A223A ePMP 3000L 5 GHz Access Point Radio (EU) (UK cord) C050910A323A ePMP 3000L 5 GHz Access Point Radio (ROW) (no cord) C050910A021A ePMP 3000L 5 GHz Access Point Radio (ROW) (US cord) C050910A121A ePMP 3000L 5 GHz Access Point Radio (ROW) (EU cord) C050910A221A...

  • Page 60: Epmp 3000L Access Point Interfaces

    Figure 31: ePMP 3000L Access Point module mounting bracket ePMP 3000L Access Point interfaces The Ethernet port is located at the bottom of the unit. This interface is described in Table 22. Table 22 ePMP 3000 Series – rear interfaces Port Connector Interface...

  • Page 61: Epmp 3000L Access Point Heater

    Table 23 ePMP 3000L Access Point physical specifications Category Specification Dimensions (Length x Width x 22.2 cm x 12.4 cm x 4.5 cm (8.75 in x 4.9 in x 1.75 in) without Height) brackets Weight 0.7 kg (1.5 lbs) without brackets Table 24 ePMP 3000L Access Point environmental specifications Category Specification...

  • Page 62: Epmp 3000L Access Point Software Packages

    Wind blowing on the device will subject the mounting structure to significant lateral force. The magnitude of the force depends on both wind strength and the surface area of the device. Wind loading is estimated using the following formulae: Force (in kilograms) = 0.1045aV Where: the surface area in square meters wind speed in meters per second...

  • Page 63: Epmp 4500C Access Point

    ePMP 4500C Access Point For details of the ePMP 4500C Access Point hardware, see: ePMP 4500C Access Point description ⚫ ePMP 4500C Access Point part numbers ⚫ ePMP 4500C Access Point mounting bracket ⚫ ePMP 4500C Access Point interfaces ⚫ ePMP 4500C Access Point specifications ⚫...
  • Page 64 Table 20 ePMP 4500C Access Point part numbers Cambium description Cambium part number ePMP 4500C 5 GHz Access Point Radio (FCC) (US cord) C058910A122A ePMP 4500C 5 GHz Access Point Radio (IC) (Canada/US cord) C050910A124A ePMP 4500C 5 GHz Access Point Radio (EU) (EU cord) C050910A223A ePMP 4500C 5 GHz Access Point Radio (EU) (UK cord) C050910A323A...

  • Page 65: Epmp 4500C Access Point Mounting Bracket

    ePMP 4500C Access Point mounting bracket The ePMP 4500C AP module is designed to be mounted with a external antenna or pole-mounted using the mounting bracket provided in the box with the radio. An overview of ePMP 4500C AP mounting bracket is shown in Figure 33 Figure 33: ePMP 4500C Access Point module mounting bracket...

  • Page 66: Epmp 4500C Access Point Specifications

    ePMP 4500C Access Point specifications The ePMP 4500C connectorized module conforms to the specifications listed in Table 23 Table The connectorized module meets the low-level static discharge specifications identified in Electromagnetic compatibility (EMC) compliance and provides internal surge suppression but does not provide lightning suppression.

  • Page 67: Epmp 4500C Access Point Wind Loading

    ePMP 4500C Access Point wind loading Ensure that the device and the structure on which it is mounted are capable of withstanding the prevalent wind speeds at a proposed ePMP site. Wind speed statistics are available from national meteorological offices. The device and its mounting bracket are capable of withstanding wind speeds of up to 200 kph (124 mph).

  • Page 68: Epmp 4500C Access Point Mounting Instructions

    ePMP 4500C Access Point mounting instructions ePMP 4500C Access Point software packages ePMP 4500C AP devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP connectorized radios are named: ePMP-AX-v5.x.x.img (or higher version number) ⚫...

  • Page 69: Epmp 4500 Access Point Part Numbers

    Figure 34: ePMP 4500 Access Point ePMP 4500 Access Point part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed in Table 20 Table 21 includes the following items: One connectorized unit ⚫...
  • Page 70 Cambium description Cambium part number ePMP 4500 5 GHz Access Point Radio (ROW) (Brazil cord) C050910A621A ePMP 4500 5 GHz Access Point Radio (ROW) (Argentina cord) C050910A721A ePMP 4500 5 GHz Access Point Radio (ROW) (ANZ cord) C050910A821A ePMP 4500 5 GHz Access Point Radio (ROW) (South Africa cord) C050910A921A ePMP 4500 5 GHz Access Point Radio (ROW) (No PSU) C050910AZ21A Table 21 ePMP 4500 accessory part numbers...

  • Page 71: Epmp 4500 Access Point Mounting Bracket

    ePMP 4500 Access Point mounting bracket The ePMP 4500 AP module is designed to be mounted with a sector antenna or pole-mounted using the mounting bracket provided in the box with the radio. An overview of ePMP 4500 AP mounting bracket is shown in Figure 35 Figure 35: ePMP 4500 Access Point module mounting bracket...

  • Page 72: Epmp 4500 Access Point Heater

    The connectorized module meets the low-level static discharge specifications identified in Electromagnetic compatibility (EMC) compliance and provides internal surge suppression but does not provide lightning suppression. Table 23 ePMP 4500 Access Point physical specifications Category Specification Dimensions (Length x Width x 22.2 cm x 12.4 cm x 4.5 cm (8.75 in x 4.9 in x 1.75 in) without Height) brackets...

  • Page 73: Epmp 4500 Access Point Wind Loading

    ePMP 4500 Access Point wind loading Ensure that the device and the structure on which it is mounted are capable of withstanding the prevalent wind speeds at a proposed ePMP site. Wind speed statistics are available from national meteorological offices. The device and its mounting bracket are capable of withstanding wind speeds of up to 200 kph (124 mph).

  • Page 74: Epmp 4500 Access Point Mounting Instructions

    ePMP 4500 Access Point mounting instructions Scan QR code for ePMP 4500 Access Point installation guide and management. ePMP 4500 Access Point software packages ePMP 4500 AP devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro.

  • Page 75: Epmp 4600 Access Point Description

    ePMP 4600 Access Point wind loading ⚫ ePMP 4600 Access Point software packages ⚫ ePMP 4600 Access Point description The ePMP 4600 device is a self-contained transceiver unit that houses both radio and networking electronics. It is available with 4 X 4 MU-MIMO connectorized antenna. An overview of ePMP 4600 is shown in Figure Figure 36:...

  • Page 76: Epmp 4600 Access Point Mounting Bracket

    Cambium description Cambium part number ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (UK cord) C060940A321A ePMP 4600 6 GHz 4x4 Access Point Radio (EU) (UK cord) C060940A323A ePMP 4600 6 GHz 4x4 Access Point Radio (ROW) (India cord) C060940A421A ePMP 4600 6 GHz 4x4 Access Point Radio (India) (India Cord) C060940A425A...

  • Page 77: Epmp 4600 Access Point Specifications

    Table 22 ePMP 4600 Series – rear interfaces Port Connector Interface Description name RJ45 PoE input Power over Ethernet (PoE). Note All RJ45 Ethernet LAN cables used for providing power or are connected to power ports (PoE) must be UL certified with VW-1 markings.

  • Page 78: Epmp 4600 Access Point Heater

    ePMP 4600 Access Point heater At startup, if the ePMP 4600 AP module temperature is at or below 32°F (0°C), an internal heater is activated to ensure that the device can successfully begin operation. The unit’s heater is only activated when the unit is powered on and will not apply heat to the device once the startup is complete.

  • Page 79: Epmp 4600 Access Point Software Packages

    Table 26 ePMP 4600 Access Point wind loading (Kg) Type of ePMP device Largest Wind speed (meters per surface area (square second) meters) ePMP 4500 Access Point with Sector 0.13 21.74 Kg 33.96 48.91 Kg Antenna Table 27 ePMP 4600 Access Point wind loading (lb) Type of ePMP device Largest surface area (square Wind speed (miles per...

  • Page 80: Epmp 4500L Access Point Part Numbers

    Figure 38: ePMP 4500L Access Point ePMP 4500L Access Point part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed in Table 20 Table 21 includes the following items: One connectorized unit ⚫...

  • Page 81: Epmp 4500L Access Point Mounting Bracket

    Cambium description Cambium part number ePMP 4500L 6 GHz 2x2 Access Point Radio (ROW) (South Africa cord) C060940A951A ePMP 4500L 6 GHz 2x2 Access Point Radio (ROW) (No PSU) C060940AZ51A ePMP 4500L 6 GHz 2x2 Access Point Radio (FCC) (US cord) C068940A152A ePMP 4500L 6 GHz 2x2 Access Point Radio (Indonesia) (EU Cord) C060940A256A...

  • Page 82: Epmp 4500L Access Point Interfaces

    Figure 39: ePMP 4500L Access Point module mounting bracket ePMP 4500L Access Point interfaces The Ethernet port is located at the bottom of the unit. This interface is described in Table 22. Table 22 ePMP 4500L Series– rear interfaces Port Connector Interface Description...

  • Page 83: Epmp 4500L Access Point Heater

    Table 23 ePMP 4500L Access Point physical specifications Category Specification Dimensions (Length x Width x 22.2 cm x 12.4 cm x 4.5 cm (8.75 in x 4.9 in x 1.75 in) without Height) brackets Weight 12.5 kg (27.56 lbs) without brackets 14.66 kg (32.32 lbs) with brackets Table 24 ePMP 4500L Access Point environmental specifications Category...
  • Page 84 Wind blowing on the device will subject the mounting structure to significant lateral force. The magnitude of the force depends on both wind strength and the surface area of the device. Wind loading is estimated using the following formulae: Force (in kilograms) = 0.1045aV Where: the surface area in square meters wind speed in meters per second...

  • Page 85: Mounting Instructions

    Mounting instructions Scan QR code for ePMP 4500L Access Point installation guide and management. ePMP 4500L Access Point software packages ePMP 4500L AP devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named: ePMP-AX-v5.x.x.img (or higher version number) ⚫...

  • Page 86: Epmp 5/6Ghz 4 X 4 Sector Antenna

    ePMP 5/6GHz 4 x 4 sector antenna ePMP 5/6GHz 4 x 4 sector antenna Figure 40: Force 300-25 For details of the Force 300-25 hardware, see: Force 300-25 integrated description ⚫ Force 300-25 part numbers ⚫ Force 300-25 mounting bracket ⚫...

  • Page 87: Force 300-25 Part Numbers

    Figure 41: Force 300-25 integrated Force 300-25 part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed in Table 28 Table 29 includes the following items: One integrated unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫...

  • Page 88: Force 300-25 Mounting Bracket

    Cambium description Cambium part number ePMP Force 300-25-25 5 GHz High Gain Radio (RoW) (ANZ Cord) C050910C801A ePMP Force 300-25-25 5 GHz High Gain Radio (RoW) (South Africa Cord) C050910C901A ePMP Force 300-25-25 5 GHz High Gain Radio (RoW) (No PSU) C050910CZ01A Table 29 Force 300-25 accessory part numbers Cambium description...

  • Page 89: Force 300-25 Specifications

    Table 30 Force 300-25 Series – rear interfaces Port Connector Interface Description name RJ45 PoE input Power over Ethernet (PoE). Note All RJ45 Ethernet LAN cables used for providing power or are connected to power ports (PoE) must be UL certified with VW-1 markings.

  • Page 90: Force 300-25 Wind Loading

    The effect on device startup time at various temperatures is defined in Table 33 Table 33 Force 300-25 startup times based on ambient temperature Initial Temperature Startup time (from power on to operational) -22°F (-30°C) H 20 minutes -4°F (-20°C) 6 minutes 14°F (-10°C) 2 minutes, 30 seconds...

  • Page 91: Force 300-25 Software Packages

    Force 300-25 software packages Force 300-25 devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named: ePMP-AC-v4.5-GA.img (or higher version number) ⚫ Force 300-25L For details of the Force 300-25L hardware, see: Force 300 CSM Connectorized Subscriber Module description...

  • Page 92: Force 300-25L Part Numbers

    Up to 26 dBm Tx Power ◼ Network management: HTTPS, SNMPv2c, SSH, cnMaestro ◼ Channel Size: 20 / 40 / 80 MHz ◼ Force 300-25L part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed in Table 36 Table 37 includes the following items:...

  • Page 93: Force 300-25L Interfaces

    Cambium description Cambium part number ePMP 5 GHz Force 300-25L SM Bulk Packaging (ROW) (No PSU) C050910MZ71A ePMP 5 GHz Force 300-25L SM Bulk Packaging (ROW) (no cord) C050910C071A ePMP 5 GHz Force 300-25L SM Bulk Packaging (ROW) (US cord) C050910C171A ePMP 5 GHz Force 300-25L SM Bulk Packaging (ROW) (EU cord) C050910C271A...

  • Page 94: Force 300-25L Specifications

    Table 38 Force 300-25L – rear interfaces Port name Connector Interface Description RJ45 PoE input Power over Ethernet (PoE). 100/1000BASE-T Ethernet Data Force 300-25L specifications The Force 300-25L integrated module conforms to the specifications listed in Table 39 Table 40. integrated module meets the low-level static discharge specifications identified in Electromagnetic compatibility (EMC) compliance...

  • Page 95: Force 300-25L Wind Loading

    Table 41 Force 300-25L startup times based on ambient temperature Initial Temperature Startup time (from power on to operational) -22°F (-30°C) H 20 minutes -4°F (-20°C) 6 minutes 14°F (-10°C) 2 minutes, 30 seconds Force 300-25L wind loading Ensure that the device and the structure on which it is mounted are capable of withstanding the prevalent wind speeds at a proposed ePMP site.

  • Page 96: Force 300-25L Software Packages

    Force 300-25L software packages Force 300-25L devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named: ePMP-AC-v4.5-GA.img (or higher version number) ⚫ Force 300-19 For details of the Force 300-19 hardware, see: Force 300-19 integrated description...

  • Page 97: Force 300-19 Mounting Bracket

    Table 44 Force 300-19 part numbers Cambium description Cambium part number ePMP 5 GHz Force 300-19 SM (FCC) (US cord) C058900C801A ePMP 5 GHz Force 300-19 SM (IC) (Canada/US cord) C050900C801A ePMP 5 GHz Force 300-19 SM (EU) (EU cord) C050900C802A ePMP 5 GHz Force 300-19 SM (EU) (UK cord) C050900C803A...

  • Page 98: Force 300-19 Interfaces

    An overview of Force 300-19 mounting bracket is shown in Figure 45 Figure 45: Force 300-19 module mounting bracket Force 300-19 interfaces The Ethernet port is located on the rear of the integrated unit. This interface is described in Table 46 Table 46 Force 300-19 Series –...

  • Page 99: Force 300-19 Heater

    Table 48 Force 300-19 environmental specifications Category Specification Temperature -30°C (-22°F) to +60°C (140°F) Wind loading 113 mph (180 kph) maximum. See Force 300-19 wind loading for a full description. Humidity 95% condensing Environmental IP55 Note This product meets the UL/cUL 62368 / IEC 62368 edition 2 specification, and the radio housings are designed to be rain-tight.

  • Page 100: Force 300-19 Software Packages

    Where: the surface area in square feet wind speed in miles per hour Applying these formulae to the ePMP device at different wind speeds, the resulting wind loadings are shown in Table 50and Table Table 50 Force 300-19 wind loading (Kg) Type of ePMP device Largest Wind speed (meters per second)

  • Page 101: Force 300-19R Part Numbers

    Force 300-19R part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed in Table 52 Table 53 include the following items: Force 300-19R Figure 46: One integrated unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫...

  • Page 102: Force 300-19R Mounting Bracket

    Cambium description Cambium part number ePMP 5 GHz Force 300-19R SM (ROW) (ANZ cord) C050900C913A ePMP 5 GHz Force 300-19R SM (ROW) (South Africa cord) C050900C914A ePMP 5 GHz Force 300-19R SM (ROW) (No PSU) C050900C915A Table 53 Force 300-19R accessory part numbers Cambium description Cambium part number PoE Gigabit DC Injector, 15W Output at 30V, Energy Level 6 Supply N000900L001...

  • Page 103: Force 300-19R Specifications

    Table 54 Force 300-19R Series – rear interfaces Port name Connector Interface Description RJ45 PoE input Power over Ethernet (PoE). 100/1000BASE-T Ethernet Data Force 300-19R specifications The Force 300-19R integrated module conforms to the specifications listed in Table 55 Table 56. The integrated module meets the low-level static discharge specifications identified in Electromagnetic compatibility (EMC) compliance...

  • Page 104: Force 300-19R Wind Loading

    Table 57 Force 300-19R startup times based on ambient temperature Initial Temperature Startup time (from power on to operational) -22°F (-30°C) H 20 minutes -4°F (-20°C) 6 minutes 14°F (-10°C) 2 minutes, 30 seconds Force 300-19R wind loading Ensure that the device and the structure on which it is mounted are capable of withstanding the prevalent wind speeds at a proposed ePMP site.

  • Page 105: Force 300-19R Software Packages

    Force 300-19R software packages Force 300-19R devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named: ePMP-AC-v4.5-GA.img (or higher version number) ⚫ Force 300-16 For details of the Force 300-16 hardware, see: Force 300-16 integrated description...
  • Page 106 One line cord ⚫ Table 60 Force 300-16 part numbers Cambium description Cambium part number ePMP 5 GHz Force 300-16 Radio (FCC) (US cord) C058910C112A ePMP 5 GHz Force 300-16 Radio (IC) (Canada/US cord) C050910C114A ePMP 5 GHz Force 300-16 Radio (EU) (EU cord) C050910C213A ePMP 5 GHz Force 300-16 Radio (EU) (UK cord) C050910C313A...

  • Page 107: Force 300-16 Interfaces

    Force 300-16 interfaces The Ethernet port is located on the rear of the integrated unit. Table 62 Force 300-16 Series – rear interfaces Port Connector Interface Description name RJ45 PoE input Power over Ethernet (PoE). Note All RJ45 Ethernet LAN cables used for providing power or are connected to power ports (PoE) must be UL certified with VW-1 markings.

  • Page 108: Force 300-16 Heater

    Force 300-16 heater At startup, if the Force 300-16 module temperature is at or below 32°F (0°C), an internal heater is activated to ensure that the device can successfully begin operation. The unit’s heater is only activated when the unit is powered on and will not apply heat to the device once the startup is complete. When the unit temperature is greater than 32°F (0°C), the heater is deactivated, and the unit continues its startup sequence.

  • Page 109: Force 300-16 Software Packages

    Table 66 Force 300-16 wind loading (Kg) Type of ePMP device Largest Wind speed (meters per second) surface area (square meters) Force 300-16 Integrated 0.03 2.8 Kg 5 Kg 7.8 Kg Table 67 Force 300-16 wind loading (lb) Type of ePMP device Largest surface area (square feet) Wind speed (miles per hour) Force 300-16 Integrated 0.34...

  • Page 110: Force 300-13 Part Numbers

    Figure 49: Force 300-13 integrated radio Force 300-13 part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed in Table 68 Table 69 include the following items: One integrated unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫...

  • Page 111: Force 300-13 Interfaces

    Cambium description Cambium part number ePMP 5GHz Force 300-13 SM (ROW) (South Africa cord) C050900C714A ePMP 5GHz Force 300-13 SM (ROW) (No PSU) C050900C715A Table 69 Force 300-13 accessory part numbers Cambium description Cambium part number PoE Gigabit DC Injector, 15W Output at 30V, Energy Level 6 Supply N000900L001 CABLE, UL POWER SUPPLY CORD SET, ARGENTINA N000900L013 CABLE, UL POWER SUPPLY CORD SET, AUS/NZ...

  • Page 112: Force 300-13 Heater

    Table 71 Force 300-13 physical specifications Category Specification Dimensions (Diameter x 12.4 cm x 25.1 cm x 11.9 cm (4.9 in x 9.9 in x 4.7 in) – with mounting Depth) bracket Weight 0.5 kg (1.1 lbs) – with mounting bracket Antenna Gain 13 dBi Table 72 Force 300-13 environmental specifications...

  • Page 113: Force 300-13 Software Packages

    Wind blowing on the device will subject the mounting structure to significant lateral force. The magnitude of the force depends on both wind strength and the surface area of the device. Wind loading is estimated using the following formulae: Force (in kilograms) = 0.1045aV Where: the surface area in square meters wind speed in meters per second...

  • Page 114: Force 300-13L Integrated Description

    Force 300-13L specifications ⚫ Force 300-13L wind loading ⚫ Force 300-13L LEDs ⚫ Force 300-13L software packages ⚫ Force 300-13L integrated description The Force 300-13L device is a self-contained transceiver unit that houses both radio and networking electronics. The Force 300-13L uses 802.11ac technology and supports MU-MIMO and other features offered by the ePMP 3000 and ePMP 3000L APs.

  • Page 115: Force 300-13L Interfaces

    Cambium description Cambium part number ePMP 5 GHz Force 300-13L SM (ROW) (US cord) C050910C131A ePMP 5 GHz Force 300-13L SM (ROW) (EU cord) C050910C231A ePMP 5 GHz Force 300-13L SM (EU) (EU cord) C050910C233A ePMP 5 GHz Force 300-13L SM (ROW) (UK cord) C050910C331A ePMP 5 GHz Force 300-13L SM (EU) (UK cord) C050910C333A...

  • Page 116: Force 300-13L Specifications

    Figure 51: Rear Interfaces Table 78 Force 300-13L Series – rear interfaces Port name Connector Interface Description Ethernet RJ45 24V PoE 10/100 BASE-T input 100 BASE- Management and data Ethernet Reset Physical For resetting the radio and for setting the radio back to its Button button factory default configuration.

  • Page 117: Force 300-13L Wind Loading

    Table 80 Force 300-13L environmental specifications Category Specification Temperature -30°C to +55°C (-22°F to +122°F) Wind loading 125 km/hour (78 mi/hour) Environmental IP55 Note This product meets the UL/cUL 62368 / IEC 62368 edition 2 specification, and the radio housings are designed to be raintight.

  • Page 118: Force 300-13L Software Packages

    Force 300-13L software packages Force 300-13L devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named: ePMP- NonGPS_Synced-[version].tar.gz (or higher version number) ⚫...
  • Page 119 One integrated unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫ One line cord ⚫ Table 82 Force 300 CSM part numbers Cambium description Cambium part number ePMP 5 GHz Force 300 CSM SM (FCC) (US cord) C058910C122A ePMP 5 GHz Force 300 CSM SM (IC) (Canada/US cord) C050910C124A ePMP 5 GHz Force 300 CSM SM (EU) (EU cord) C050910C223A...

  • Page 120: Force 300 Csm Interfaces

    Force 300 CSM interfaces The Ethernet port is located on the rear of the unit. Table 84 Force 300 CSM Series – rear interfaces Port Connector Interface Description name RJ45 PoE input Power over Ethernet (PoE). Note All RJ45 Ethernet LAN cables used for providing power or are connected to power ports (PoE) must be UL certified with VW-1 markings.

  • Page 121: Force 300 Csm Heater

    Force 300 CSM heater At startup, if the Force 300 CSM module temperature is at or below 32°F (0°C), an internal heater is activated to ensure that the device can successfully begin operation. The unit’s heater is only activated when the unit is powered on and will not apply heat to the device once the startup is complete. When the unit temperature is greater than 32°F (0°C), the heater is deactivated, and the unit continues its startup sequence.

  • Page 122: Force 300 Csm Software Packages

    16.93 lb Force 300 CSM software packages The Force 300 CSM devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named: ePMP-AC-v4.5-GA.img (or higher version number) ⚫...

  • Page 123: Force 300 Csml Part Numbers

    Figure 53: Force 300 CSML Force 300 CSML part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed in Table 90 Table 91 include the following items: One connectorized unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫...

  • Page 124: Force 300 Csml Interfaces

    Force 300 CSML interfaces The Ethernet port is located on the rear of the connectorized unit. Rear interfaces Figure 54: Table 92 Force 300 CSML Series – Rear interfaces Port name Connector Interface Description Ethernet RJ45 24V PoE input 10/100BASE-T 100 BASE-TX Management and data Ethernet...

  • Page 125: Force 300 Csml Specifications

    Figure 55: Force 300 CSML module mounting bracket Force 300 CSML specifications The Force 300 CSML module conforms to the specifications listed in Table 93 Table 94. The connectorized module meets the low-level static discharge specifications identified in Electromagnetic compatibility (EMC) compliance and provides internal surge suppression but does not provide lightning suppression.

  • Page 126: Force 300 Csml Leds

    Force 300 CSML LEDs Table 95 Force 300 CSML LED functions Function POWER Green: Power is applied to the device Unlit: No power is applied to the device or improper power source WiFi Radio scanning: LEDs light in an ascending sequence to indicate that the radio is scanning Radio registered: LEDs light to indicate the RSSI level at the...

  • Page 127: Epmp Mp 3000 Integrated Description

    ePMP MP 3000 wind loading ⚫ ePMP MP 3000 software packages ⚫ ePMP MP 3000 integrated description The ePMP MP 3000 MicroPoP is an integrated AP designed to serve short-range, low-density applications. It uses 802.11ac 2x2 architecture and can interoperate with a Force 300 subscriber module. An overview of ePMP MP 3000 is shown in Figure Figure 56:...

  • Page 128: Epmp Mp 3000 Interfaces

    Cambium description Cambium part number ePMP 5 GHz MP 3000 MicroPOP Radio (EU) (UK cord) C050910A333A ePMP 5 GHz MP 3000 MicroPOP Radio (ROW) (India cord) C050910A431A ePMP 5 GHz MP 3000 MicroPOP Radio (India) (India Cord) C050910A432A ePMP 5 GHz MP 3000 MicroPOP Radio (ROW) (China cord) C050910A531A ePMP 5 GHz MP 3000 MicroPOP Radio (ROW) (Brazil cord) C050910A631A...

  • Page 129: Epmp Mp 3000 Specifications

    Port Connector Interface Description name All RJ45 Ethernet LAN cables used for providing power or are connected to power ports (PoE) must be UL certified with VW-1 markings. 100/1000BASE-T Data Ethernet ePMP MP 3000 specifications The ePMP MP 3000 integrated module conforms to the specifications listed in Table 99 Table 100.

  • Page 130: Epmp Mp 3000 Wind Loading

    Table 101 ePMP MP 3000 startup times based on ambient temperature Initial Temperature Startup time (from power on to operational) -22°F (-30°C) H 20 minutes -4°F (-20°C) 6 minutes 14°F (-10°C) 2 minutes, 30 seconds ePMP MP 3000 wind loading Ensure that the device and the structure on which it is mounted are capable of withstanding the prevalent wind speeds at a proposed ePMP site.

  • Page 131: Epmp Mp 3000 Software Packages

    ePMP MP 3000 software packages ePMP MP 3000 devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named: ePMP-AC-v4.5-GA.img (or higher version number) ⚫...
  • Page 132 One line cord ⚫ Table 102 ePMP Force 425 part numbers Cambium description Cambium part number ePMP 5 GHz Force 425 SM 2-pack packaging (ROW) (no cord) - Priced per radio C050940M001A ePMP 5 GHz Force 425 SM 2-pack packaging (ROW) (US cord) - Priced per radio C050940M101A ePMP 5 GHz Force 425 SM 2-pack packaging (IC) (Canada/US cord) - Priced per C058940M104A...

  • Page 133: Force 425 Mounting Bracket With Range Extender

    Force 425 mounting bracket with Range Extender The Force 425 module is designed to be pole-mounted using the mounting bracket provided in the box with the radio. An overview of Force 425 mounting bracket is shown in Figure 58 Force 425 module mounting bracket with Range Extender Figure 58: Force 425 interfaces The Ethernet port is located on the rear of the integrated unit.

  • Page 134: Force 425 Heater

    Table 106 Force 425 environmental specifications Category Specification Temperature -30°C to 65°C (-22°F to 149°F) Wind loading 200 km/hour (124 mph) Humidity 95% condensing Environmental IPx0 Force 425 heater At startup, if the Force 425 module temperature is at or below 32°F (0°C), an internal heater is activated to ensure that the device can successfully begin operation.

  • Page 135: Force 425 Software Packages

    the surface area in square feet wind speed in miles per hour Applying these formulae to the ePMP device at different wind speeds, the resulting wind loadings are shown in Table 108 Table 109. Table 108 Force 425 wind loading (Kg) TypeofePMPdevice Largest surfacearea(squaremeters) Wind speed (meters per second)

  • Page 136: Force 400C Part Numbers

    Figure 59: Force 400C integrated Force 400C part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed includes the following items: One integrated unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫...

  • Page 137: Force 400C Interfaces

    Cambium description Cambium partnumber ePMP 5 GHz Force 400C (ROW) (Brazil cord) C050940C621A ePMP 5 GHz Force 400C (ROW) (Argentina cord) C050940C721A ePMP 5 GHz Force 400C (ROW) (ANZ cord) C050940C821A ePMP 5 GHz Force 400C (ROW) (South Africa cord) C050940C921A ePMP 5 GHz Force 400C (ROW) (No PSU) C050940CZ21A ePMP 5 GHz Force 400C (FCC) (US Cord)

  • Page 138: Force 400C Heater

    Category Specification Wind loading 200 km/hour (124 mph) Environmental IPx0 Force 400C heater At startup, if the Force 400C module temperature is at or below 32°F (0°C), an internal heater is activated to ensure that the device can successfully begin operation. The unit’s heater is only activated when the unit is powered on and will not apply heat to the device once the startup is complete.

  • Page 139: Force 400C Software Packages

    Table 116 Force 400C wind loading (Kg) TypeofePMPdevice Largest surfacearea(squaremeters) Wind speed (meters per second) Force 400C Integrated 0.03 2.82 Kg 5.02 Kg 7.84 Kg Table 117 Force 400C wind loading (lb) TypeofePMPdevice Largest surfacearea(squarefeet) Wind speed (miles per hour) Force 400C Integrated 0.28 7.53 lb 11.76 lb...

  • Page 140: Force 4600C Part Numbers

    Figure 60: Force 4600C integrated Force 4600C part numbers Select the correct regional variant to adhere to local licensing restrictions. Each of the parts listed includes the following items: One integrated unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫...

  • Page 141: Force 4600C Interfaces

    Cambiumdescription Cambium partnumber ePMP 6 GHz Force 4600C SM Radio (ROW) (ANZ cord) C060940C821A ePMP 6 GHz Force 4600C SM Radio (ROW) (South Africa cord) C060940C921A ePMP 6 GHz Force 4600C SM Radio (ROW) (No PSU) C060940CZ21A ePMP 6 GHz Force 4600C SM Radio (FCC) (US Cord) C068940C122B ePMP 6 GHz Force 4600C SM Radio (Indonesia) (EU Cord) C060940C226A...

  • Page 142: Force 4600C Heater

    Table 114 Force 4600C environmental specifications Category Specification Temperature -30°C to 65°C (-22°F to 149°F) Wind loading 200 km/hour (124 mph) Environmental IPx0 Force 4600C heater At startup, if the Force 4600C module temperature is at or below 32°F (0°C), an internal heater is activated to ensure that the device can successfully begin operation.

  • Page 143: Force 4600C Software Packages

    Applying these formulae to the ePMP device at different wind speeds, the resulting wind loadings are shown in Table 116 Table 117. Table 116 Force 4600C wind loading (Kg) TypeofePMPdevice Largest surfacearea(squaremeters) Wind speed (meters per second) Force 4600C Integrated 0.03 2.82 Kg 5.02 Kg 7.84 Kg...

  • Page 144: Force 4525 Integrated Description

    Force 4525 heater ⚫ Force 4525 wind loading ⚫ Force 4525 mounting instructions ⚫ Force 4525 software packages ⚫ Force 4525 integrated description The Force 4525 device is a self-contained transceiver unit that houses both radio and networking electronics. The Force 4525 uses 802.11ac technology and supports MU-MIMO. It is also backward compatible with the ePMP XXXX using backward compatibility features.

  • Page 145: Force 4525 Interfaces

    Cambiumdescription Cambium partnumber ePMP 6 GHz Force 4600C SM Radio (ROW) (UK cord) C060940C321A ePMP 6 GHz Force 4600C SM Radio (EU) (UK cord) C060940C323A ePMP 6 GHz Force 4600C SM Radio (ROW) (India cord) C060940C421A ePMP 6 GHz Force 4600C SM Radio (India) (India Cord) C060940C425A ePMP 6 GHz Force 4600C SM Radio (ROW) (China cord) C060940C521A...

  • Page 146: Force 4525 Heater

    Table 113 Force 4525 physical specifications Category Specification Dimensions (Diameter x Depth) 256 mm x 125 mm x 46 mm (10.1 in x 4.9 in. x 1.8 in.) Weight 1.3 kg (2.9 lbs.) Table 114 Force 4525 environmental specifications Category Specification Temperature -30°C to 65°C (-22°F to 149°F)

  • Page 147: Force 4525 Mounting Instructions

    Force (in pounds) = 0.0042Av Where: the surface area in square feet wind speed in miles per hour Applying these formulae to the ePMP device at different wind speeds, the resulting wind loadings are shown in Table 116 Table 117. Table 116 Force 4525 wind loading (Kg) TypeofePMPdevice Largest surfacearea(squaremeters)

  • Page 148: Force 4525 Software Packages

    Force 4525 software packages Force 4525 devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named. ePMP-AX-v5.x.x.img (or higher version number) ⚫ Force 4525L For details of the Force 4525L hardware, see: Force 4525L integrated description...

  • Page 149: Force 4525L Interfaces

    One integrated unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫ One line cord ⚫ Table 110 Force 4525L part numbers Cambiumdescription Cambium partnumber ePMP 6 GHz Force 4525L Radio (ROW) (no cord) C060940C021A ePMP 6 GHz Force 4525L Radio (ROW) (US cord) C060940C121A ePMP 6 GHz Force 4525L Radio (IC) (Canada/US cord) C068940C124A...

  • Page 150: Force 4525L Heater

    The integrated module meets the low-level static discharge specifications identified in Electromagnetic compatibility (EMC) compliance and provides internal surge suppression but does not provide lightning suppression. Table 113 Force 4525L physical specifications Category Specification Dimensions (Diameter x Depth) 256 mm x 125 mm x 46 mm (10.1 in x 4.9 in. x 1.8 in.) Weight 1.3 kg (2.9 lbs.) Table 114 Force 4525L environmental specifications...

  • Page 151: Force 4525L Mounting Instructions

    Where: the surface area in square meters wind speed in meters per second Force (in pounds) = 0.0042Av Where: the surface area in square feet wind speed in miles per hour Applying these formulae to the ePMP device at different wind speeds, the resulting wind loadings are shown in Table 116 Table...

  • Page 152: Force 4525L Software Packages

    Force 4525L software packages Force 4525L devices may be upgraded by downloading new software packages from the Cambium Networks site or by using cnMaestro. The software packages applicable to ePMP integrated radios are named. ePMP-AX-v5.x.x.img (or higher version number) ⚫ Force 4625 For details of the Force 4625 hardware, see: Force 4625 integrated description...

  • Page 153: Force 4625 Interfaces

    One integrated unit ⚫ One power supply 1000/100 BASE-TX LAN injector ⚫ One line cord ⚫ Table 110 Force 4625 part numbers Cambiumdescription Cambium partnumber ePMP 6 GHz Force 4625 SM Bulk packaging (ROW) (no cord) C060940M041A ePMP 6 GHz Force 4625 SM Bulk packaging (ROW) (US cord) C060940M141A ePMP 6 GHz Force 4625 SM Bulk packaging (IC) (Canada/US cord) C068940M144A...

  • Page 154: Force 4625 Specifications

    Table 112 Force 4625 series – rear interfaces Portname Connector Interface Description RJ45 PoE input Power over Ethernet (PoE) 100/1000BASE-T Ethernet Data 10 Gigabit cage Optional 10 Gigabit SFP cage for SFP module Force 4625 specifications The Force 4625 integrated module conforms to the specifications listed in Table 113 Table 114.

  • Page 155: Force 4625 Wind Loading

    Force 4625 wind loading Ensure that the device and the structure on which it is mounted are capable of withstanding the prevalent wind speeds at a proposed ePMP site. Wind speed statistics are available from national meteorological offices. The device and its mounting bracket are capable of withstanding wind speeds of up to 180 kph (124 mph).

  • Page 156: Power Supply

    Power supply For details of the ePMP power supply units, see: Power supply description ⚫ Power supply part numbers ⚫ Power supply interfaces ⚫ Power supply specifications ⚫ Power supply location considerations ⚫ Power supply description The power supply unit that is connected to the ePMP modules is rated for indoor use. The ePMP modules are installed outdoors and terminated to network equipment using Cat5e cables with RJ45 connectors.

  • Page 157: Power Supply Specifications

    Figure 65: Power supply interfaces Table 119 Power supply interface functions - N000900L001 Interface Function Power input Mains power input. Power output Gigabit Data + Power RJ45 socket for connecting Cat5e cable to the radio. Note All RJ45 Ethernet LAN cables used for providing power or are connected to power ports (PoE) must be UL certified with VW-1 markings.

  • Page 158: Power Supply Location Considerations

    Table 122 Power supply physical specifications Category Specification Dimensions (H x W x D) 14 x 6.5 x 3.6 cm (5.5 x 2.55 x 1.42 in) Weight 0.26 lbs Table 123 Power supply environmental specifications Category Specification Ambient Operating Temperature 0°C to +40°C Humidity 20% - 90%...

  • Page 159: Ethernet Cabling

    50 micro-inch thick 24-carat gold, exceeding TIA-1096 specifications and ensuring the best possible connection and oxidation resistance. Cambium Networks’ industrial-grade cable is well suited for high-quality durable installations of subscriber modules, APs, and enterprise point-to-point links as well as in tactical non-permanent deployments of infrastructure.

  • Page 160: Surge Suppression Unit

    Table 126 Cambium Industrial Cable part numbers Cambium description Cambium part number Industrial Grade CAT 5 Cable 50 meter unterminated N000000L106A Industrial Grade CAT 5 Cable 100 meter unterminated N000000L106A Industrial Grade CAT 5 Cable 300 meter unterminated N000000L108A Industrial Grade RJ45 Connector 100 Pack C000000L109A Termination Tool for C000000L109A RJ45 connectors C000000L110A Surge suppression unit...

  • Page 161: Cnpulse Sync Generator

    3000 Access Point cnPulse sync generator cnPulse is the latest GPS synchronization generation device designed specifically for Cambium Networks PMP and PTP radios. The cnPulse module is *IP67 (weatherproof and supports a wide temperature range for rugged environments. The GPS receiver is highly reliable and supports both GPS and GNSS signals.
  • Page 162 Figure 67: cnPulse sync generator cnPulse receives its power from the CAT-5 drop cable in mode 2 so no external power supply is required. There are no configuration or software settings required. For ePMP 3000, cnPulse is deployed in-line with the radio’s CAT-5 drop cable.

  • Page 163: Chapter 3: System Planning

    Chapter 3: System Planning This chapter provides information to help the user to plan an ePMP link. The following topics are described in this chapter: How to plan ePMP links to conform to the regulatory restrictions that apply in the country of ⚫...

  • Page 164: Regulatory Limits

    Many countries impose EIRP limits (Allowed EIRP) on products operating in the bands used by the ePMP Series. For example, in the 5 GHz band, these limits are calculated as follows: In the 5.8 GHz band (5725 MHz to 5875 MHz), the EIRP must not exceed the lesser of 36 dBm or ⚫...

  • Page 165: Conforming To The Limits

    Conforming to the limits Ensure the link is configured to conform to local regulatory requirements by configuring the correct country code (located in the web management interface, under Configure > Radio). In the following situations, the country code does not automatically prevent operation outside the regulations: When operating in ETSI regions, it is required to enter a license key in the ePMP web management ⚫...

  • Page 166: Adaptive Modulation

    Loss), the attenuation caused by obstacles (Excess Path Loss), and a margin to allow for possible fading of the radio signal (Fade Margin). The following calculation needs to be performed to judge whether a particular link can be installed: Where: Free Space Path Loss (dB) Excess Path Loss (dB) Fade Margin Required (dB)

  • Page 167: Management Vlan

    Ethernet Bridging Specification Interface 10/100/1000BASE-T (RJ-45) Maximum Ethernet Frame Size 1700 bytes Service classes for bridged traffic 3 classes Management VLAN Decide if the IP interface of the device management agent will be connected in a VLAN. If so, decide if this is a standard (IEEE 802.1Q) VLAN or provider bridged (IEEE 802.1ad) VLAN, and select the VLAN ID for this VLAN.

  • Page 168: Chapter 4: Using The Device Management Interface

    Chapter 4: Using the Device Management Interface This chapter describes all configuration and alignment tasks that are performed when an ePMP system is deployed. Configure the units by performing the following tasks: Preparing for configuration ⚫ Connecting to the unit ⚫...

  • Page 169: Configuring The Management Pc

    Configuring the management PC Perform the following procedure to configure the local management PC to communicate with the ePMP module. Procedure Select Properties for the Ethernet port. In Windows 7 this is found in Control Panel > Network and Internet >...

  • Page 170: Using The Web Interface

    Using the web interface This section describes how to use the ePMP web interface. Logging into the web interface ⚫ Logging into the web interface Perform the following procedure to log into the web interface as a system administrator. Equipment and tools ePMP device connected to the power supply by Ethernet cable.

  • Page 171: Using The Installation Wizard - Access Point

    Using the installation wizard – Access Point The ePMP device provides a guided configuration mechanism for configuring key parameters for the link operation. This setup can be accessed from the Installation page by clicking the button. Click Finish Setup to commit the changes to the device. Step 1: Main system parameters Figure 69: Quick Start page...

This manual is also suitable for:

Epmp 3000Epmp 3000lEpmp mp3000 micropopEpmp 4500cEpmp 4500Epmp 4600 ... Show all

Table of Contents
