TMG-TCM5
PRODUCT MANUAL
v2022.10.27
3-POINT HITCH
5 CU-FT CEMENT MIXER
Please read and understand the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TMG TMG-TCM5
Summary of Contents for TMG TMG-TCM5
- Page 1 TMG-TCM5 PRODUCT MANUAL v2022.10.27 3-POINT HITCH 5 CU-FT CEMENT MIXER Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ......................3 OPERATING SAFETY .......................4 PRODUCTS SPECIFICATIONS....................5 PARTS DESCRIPTION AND FUCTION ..................6 PRODUCTS SAFETY DECALS....................7 UNPACKING & ASSEMBLY ......................8 CONNECTING TRACTOR .......................16 BEFORE EACH USE ........................19 OPERATING INSTRUCTIONS....................19 OPERATION FINISH ......................21 MAINTENANCE ........................22 TROUBLESHOOTING......................23 EXPLODED VIEW & PARTS LIST.....................24... -
Page 3: Safety Instructions
IMPORTANT SAFETY INFORMATION WARNING: Read and understand all instructions. Failure to follow all instructions may result in serious injury or property damage. ● The warnings, cautions, and instructions in this manual cannot cover all possible conditions or situations that could occur. ●... -
Page 4: Operating Safety
PRODUCT USE AND CARE Do not force the cement mixer. Products are safer and do a better job when used in the manner for which they are designed. ● Plan your work, and use the correct product for the job. Check for damaged parts before each use. -
Page 5: Products Specifications
PTO driveline. This damage could cause the driveline to come apart causing possible injury or death. When raising mixer with the 3 point hitch, check that the PTO driveline does not go into sharp angles (more than 15 ゜). ● PRODUCTS SPECIFICATIONS Model TMG-TCM5 Empty drum volume 5 CU-FT Drum opening 18”... -
Page 6: Parts Description And Fuction
PARTS DESCRIPTION AND FUNCTION 1. RACK COMPONENTS Connect tractor and cement mixer, it is also a cement mixer support mechanism. 2. Transmission components Mainly including active sprocket shaft, driven sprocket, chain, spindle, PTO driven shaft and so on. PTO for type 1 drive shaft, tractor PTO gear selection rod 540 RPM. Transmission ratio: 10/1.Driven sprocket drives the mixing barrel to rotate, so that the cement mixture meets the requirements of use. -
Page 7: Products Safety Decals
PRODUCTS SAFETY DECALS 0037 0021 0023 0038 0039 0040 0041... -
Page 8: Unpacking & Assembly
UNPACKING & ASSEMBLY 1. After unpacking, check the following components *. All numbers are not part numbers in the drawings. For correct part numbers, see explosive diagram. - Page 9 DESCRIPTION DESCRIPTION Main drum weldment Hexagon bolt M12X35 Cone drum weldment Cylinder pin Hydraulic components R pin Hexagon bolt M8x20 Bushing Spring washer Ø8 Safety pin Flat washer Ø8 Flat washer Ø10 Hex nut M8 Spring washer Ø10 Stirrer Welding Hex nut M10 Flat washer Ø12 Cylinder connecting plate...
- Page 10 2. Install cone drum weldment...
- Page 11 Installation steps: Align the CONE DRUM WELDMENT (D2) with the mounting holes on the MAIN DRUM WELDMENT (D1), place the SEAL PACKING (D14) between the two, insert the M8 BOLT (D7), and use the FLAT WASHER (D4), SPRING WASHER (D5) and HEXAGON NUT ( D6) Lock it.
- Page 12 D9/D10/D12/4-D8 D9/D10/D12/3-D8 D8/D9/D12...
- Page 13 4. Install hydraulic components...
- Page 14 Installation steps: First insert the CYLINDER PIN (B17) on the right into the position shown in the figure above, insert B19, B18,B19 in sequence, insert 2 R PINS (20) on the CYLINDER PIN(B17), then align the HYDRAULIC COMPONENTS(1) with the mounting hole on the CYLINDER CONNECTING PLATE(B19), and insert CYLINDER PINS(B17), and finally insert 2 more R PINS(B20).
- Page 15 C8/C9/C10/C11...
-
Page 16: Connecting Tractor
In the process of connection, when the tractor is the moving, if there is people between the tractor and working machine, it may cause injury accident. Be sure no people stand between the tractor and working machine during the tractor moving. LOWER LIFTING PIN TYPES TMG-TCM5 CAT1 2. Connection and adjustment... - Page 17 d. Adjust angle, to obtain the most appropriate cutting angle, adjust the upon 3-point linkage suspension to ensure the suitable cutting angle. Upon 3-point linkage Handle for tractor 3-point linkage 3.PTO Installation In some cases it will be necessary to shorten the PTO assembly to match your particular tractor. The following procedure should be used: 1.
- Page 18 2. Always couple the two end yokes of the driveline, check that they are locked in place. To achieve this condition, completely insert the latch pin into the groove in the PTO shaft on the tractor. Install the bolt through the yoke and input the shaft on the mixer.
-
Page 19: Before Each Use
BEFORE EACH USE PRE-OPERATION CHECKLIST Review and follow the safety rules and safety signs . Check that the mixer is properly and securely and attached to the tractor. _ __ _ Make sure the driveline spring-activated locking pin or locking balls operate freely and are seated firmly in the tractor’s PTO spline groove. - Page 20 After the concrete is poured, it is screeded or struck off with a straight edge, like a 2 x 4, and it should then be floated to smooth it. Further troweling or finishing should be delayed until the water sheen has disappeared from the surface. The concrete should be cured at least five days.
-
Page 21: Operation Finish
3. Dumping Disengage the PTO before dumping. Never attempt to dump the mixer with the mixer running – PTO damage will result. Always dump the mixer slowly to avoid splashing the mixture. Be careful not to let the mixer dump too far and bind the hydraulic cylinder. Use a shovel to remove the last of the mixture. -
Page 22: Maintenance
MAINTENANCE WARNING ! Before servicing the machine, disengage the PTO, engage the parking brake or place the transmission in park, shut off the tractor, and remove the key. Keep clear of rotating parts; stay on the tractor seat until all motion has stopped. Do not get under the machine to make adjustments without securely blocking the implement first. -
Page 23: Troubleshooting
TROUBLESHOOTING PROBLEM PROBABLE CAUSE SOLUTION Mixer dumps and won’t Hydraulic hose from cylinder not connected to --- Coupling hydraulic tubing come back to load tractor hydraulic remote outlet. position Hydraulic top link cylinder on mixer is single Add oil acting and is incompatible with tractor remote outlet valve-check manual and tractor dealer to see if different valve is Available. -
Page 24: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST 1. Main-frame assembly PARTS LIST PART NO. DESCRIPTION Hydraulic components Rack components Transmission components Mixing drum components... - Page 25 2. Hydraulic components PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION Hydraulic hose 3/4”x59” 1/2NPT Hydraulic cylinder fitting Transition joints Hollow bolt 1/2NPT...
- Page 26 3. Rack components...
- Page 27 PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION Frame welded Oil cyinder pin Deep groove ball bearing Bush 6209-2RZ Bearing cap Cylinder connecting plate Adjusting seat welding R Pin Din11024 Deep groove ball bearing Lock Pin Ø8 6206-2RZ Shield 2 Full-thread hexagon bolts M8×16 Articulated pin Plain washer Ø8...
- Page 28 4.Transmission components PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION Square and rectangular keys Driven sprocket welding C14×9×45 Main shaft welding Safety pin Retaining rings for shaft Ø30 Plain washer Ø10 Chain 08B-1×144 Spring washer Ø10 PTO transmission shaft T1-700 Hexagon Nuts M10 Spindle...
- Page 29 5.Mixing drum components PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION Main drum weldment Plain washer Ø12 Cone drum weldment Hexagon nuts M12 Paddle weldment Spring washer Ø12 Plain washer Ø8 Big washer Spring washer Ø8 Full-thread hexagon bolts M12×35 Hexagon Nuts M8 Full-thread hexagon bolts M12×25 Full-thread hexagon bolts M8×20...
