TMG -SP10X Product Manual

Snow plow pusher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PROFUCT MANUAL
Snow Plow Pusher
10 FT, U/V Angle Blade, with Q/C Lugging
MODEL: TMG-SP10X
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your requests
WWW.TMGINDUSTRIAL.COM
Toll Free:1-877-761-2819

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMG-SP10X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TMG TMG-SP10X

Summary of Contents for TMG TMG-SP10X

  • Page 1 PROFUCT MANUAL Snow Plow Pusher 10 FT, U/V Angle Blade, with Q/C Lugging MODEL: TMG-SP10X Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...

  • Page 2: Table Of Contents

    CONTENTS Safety operation warning ........................03 1. safety instructions Preparations before operation......................04 During operation..........................05 After operation.............................06 2. Machine introduce Product parts name and function......................Product specifications......................... 3. Assembly work instruction Check after unpacking..........................10 Installation of left shovel assembly and support adjustment assembly............12 Installation of right shovel assembly and support adjustment assembly..........
  • Page 3 Warning instructions for safe operation Meaning of warning labels NOTICE! Read the instruction manual carefully before using the machine. Failure to follow this warning may cause injury. WARNING ! Keep away from the cutting area of the running machine. If this warning is not followed, a personal injury accident may occur WARNING ! Keep a safe distance while driving the machine.

  • Page 4: Preparations Before Operation

    1.Precautions for safe operation Read the operating instructions of the machine carefully, and be familiar with the performance and how to operate all the control devices! Understand all the safety labels on the equipment, and keep the labels clean. Please do not paint or move any safety labels casually.

  • Page 5: During Operation

    Before operation DANGER ! ★ Make sure that the snow shovel and the car (other) connecting frame have been connected. ★ Operate in a safe area. ★ Ensure that the snow shovel is installed firmly. ★ Ensure that all hydraulic joints and hydraulic devices are firmly connected. ★...

  • Page 6: After Operation

    After operation NOTICE ! ★ After the machine is used, the shovel body and joints should Fe cleaned with a high-pressure water gun. ★ Grease the exposed cylinder rod ★ Thoroughly remove all dirt, dirt and grease on the clean surface. ★...

  • Page 7: Machine Introduce

    2.Machine introduce Products part names and functions Protect the rubber Right main shovel components assembly Left main shovel assembly Bracket assembly Hydraulic Hanging board Bracket Support adjustment components components components assembly WWW.TMGINDUSTRIAL.COM P07/31 Toll Free:1-877-761-2819...

  • Page 8: Product Specifications

    Products Specifications WWW.TMGINDUSTRIAL.COM P08/31 Toll Free:1-877-761-2819...
  • Page 9 Model No. TMG-SP10X Max Working Pressure 3050PSI Max Working Flow 8.0GPM Working Width 10ft(118”) Working Voltage DC 12V U blade up to 140 degree V blade up to 215 degree Blade Angle 22 degrees left or right Hydraulic Hose Diameter 3/8”(I.D)/1”(O.D)

  • Page 10: Assembly Work Instruction

    3.Assembly work instruction 1. After unpacking, check the following components All numbers are not part numbers in the drawings. For correct part numbers, see explosive diagram WWW.TMGINDUSTRIAL.COM P10/31 Toll Free:1-877-761-2819...
  • Page 11 REF# SPECIFICATION REF# SPECIFICATION Support adjustment Flat Washer Ø16 components Hexagon bolts with full thread, Protection eraser M8x35 Rubber splint Spring washer Ø8 Rubber splint two Flat washer Ø8 Hexagon bolts with full thread, Adjust the rod assembly M8x20 Shock absorber hydraulic Hexagon bolts with full thread, cylinder 50x28x100 M20x120...

  • Page 12: Installation Of Left Shovel Assembly And Support Adjustment Assembly

    2. Installation of left main shovel assembly and support adjustment assembly Installation steps: Fasten the support adjustment component to the left main shovel with M12*30 bolts (D15）according to the position in the above figure. Importance: All bolts are locked in place without shaking. WARNING: Once the assembly bolts are not fastened in place, there will be abnormal noises when the machine is working.

  • Page 13: Installation Of Right Shovel Assembly And Support Adjustment Assembly

    3. Installation of the right main shovel assembly and support adjustment assembly Installation steps: Fasten the support adjustment component to the right main shovel with M12*30 bolts (D15) according to the position in the above figure. Importance: All bolts are locked in place without shaking. WARNING: Once the assembly bolts are not fastened in place, there will be abnormal noises when the machine is working.

  • Page 14: Installation Of Bracket Component

    4. Installation of bracket component Installation steps: 1. Align the right main shovel (3), bracket(1), and left main shovel (2) in sequence and insert the main pin shaft weldment (A2), then adjust the hole position at the end of the main pin shaft to be perpendicular to the bracket.

  • Page 15: Installation Of Suspension Assembly

    Part name and specification REF No Specification Bracket assembly Main pin shaft weldment Hexagon head bolt M8x70 Hydraulic cylinder 50x32x255 Cylinder pin 2 Split pin 5x40 5. Installation of suspension assembly E8/E9/E10 G9/G9/G10/G11 G9/G10 E4/E4/E5/E6 E4/E4/E5/E6 H2/H3 WWW.TMGINDUSTRIAL.COM P15/31 Toll Free:1-877-761-2819...
  • Page 16 Installation steps: 1. The docking station of the male connector（E7) is tightened with M8*35 bolts (E8) and flat washers (E9) according to the position shown in the figure above. 2. Install the accumulator (G7) with the hoop (G8), M8*35 bolts (G10) and flat washers (G9) in the position shown in the figure.

  • Page 17: Installation Of Hanger Assembly

    6. Installation of the hanger assembly E4/E5/E6 G4/G5/G5/G6 G3/G4/G5/G5 E11/E12/E13 Installation steps: 1. Align the left and right bracket welded parts (E2,E3) with the holes at the bottom of the bracket, insert and padded the Ø22 plain washers (E11) with the cylinder pins (E12), and then knock in the spring-type straight pin (E13) Note: there are two places where the left and right bracket welded parts need to be installed with grease nipple (E15), and the positions are shown in the above figure.

  • Page 18: Installation Of Rubber As-Protection

    bolt (E5) with the washer (E4) and lock nut (E6) to tighten. The ring and lock nut are tightened. Importance: All bolts are locked in place without shaking. WARNING: Once the assembly bolts are not fastened in place, there will be abnormal noises when the machine is working.

  • Page 19: Cylinder And Oil Pipe Connection

    Installation steps: Assemble the eraser in the order of the style above. Importance: All bolts are locked in place without shaking. WARNING: Once the assembly bolts are not fastened in place, there will be abnormal noises when the machine is working. Inspection: Check whether each bolt is loose.
  • Page 20 Installation steps: 1. Installation connect the transition joint (G17) and the right-angle combined joint (G24) to the solenoid valve (G15) according to the position shown in the figure above. Noted:the accumulator oil port also has a transition joint. 2. The hydraulic hose(G22) is connected to the accumulator at one end and the T port on the solenoid valve (G15) at the other end.

  • Page 21: Electrical Circuit Connection

    9. Electrical circuit connection SOLENOID VALVE SWITCH CORTOL POWER INLET The solenoid valve head harness is fastened to the solenoid valve by inserting the phillips screws on the solenoid valve One end of the switch harness is connected to the conversion head of a section of the solenoid valve harness, and the other end is connected to the power supply.

  • Page 22: Lubricating Grease

    10. Lubricating grease WARNING Lubricate the bearing before each use, Otherwise, the service life of the machine will be affected OIL FILTER OIL FILTER OIL FILTER OIL FILTER OIL FILTER WWW.TMGINDUSTRIAL.COM P22/31 Toll Free:1-877-761-2819...

  • Page 23: Explosion Diagram And Product Parts

    4.Explosion diagram and Product Parts 1.Explosive diagram of major components PART# DESCRIPTION PART# DESCRIPTION Bracket assembly Bracket as hanging plate Shovel as-left main Rubber as-protection Shovel as-right main Hydraulic assembly Adjustment as- support Hanging plate assembly 2.Explosive diagram of Bracket Assembly PART# DESCRIPTION PART#...
  • Page 24 3.Explosive diagram of Shovel as-lest main PART# DESCRIPTION PART# DESCRIPTION Left main shovel plate weldment Plain washer Ø14 Left rubber pressing plate Full-thread hexagon bolt M14x65 weldment Backing plate Lock nut M14 Scraper Spring pin shaft weldment Full-thread hexagon bolt M12x40 Spring 50x15x230 Plain washer Ø12 Lock nut M18...
  • Page 25 4.Explosive diagram of Shovel as-right main PART# DESCRIPTION PART# DESCRIPTION Right main shovel plate weldment Plain washer Ø14 Right rubber pressing plate Full-thread hexagon bolt M14x65 weldment Backing plate Lock nut M14 Scraper Spring pin shaft weldment Full-thread hexagon bolt M12x40 Spring 50x15x230 Plain washer Ø12 Lock nut M18...
  • Page 26 5.Explosive diagram of Adjustment as-support D14 D15 PART# DESCRIPTION PART# DESCRIPTION Adjusting bracket Shim Support foot weldment Spring-type straight pin Lifting screw welding Plain washer Ø10 Threaded cover plate Plain washer Ø16 Welding of support plate Handle Full-thread hexagon bolts M10x40 Plain washer Ø12 Hexagon head bolt M16x90 Full-thread hexagon bolts M12x30...
  • Page 27 6.Explosive diagram of Bracket as hanging plate assembly PART# DESCRIPTION PART# DESCRIPTION Suspension frame Plain washer Ø8 Bracket weldment - left Spring washer Ø8 Bracket weldment - right Plain washer Ø22 Plain washer Ø20 Cylinder pin 1 Full-thread hexagon bolts M20x120 Spring-type straight pin Lock nut M20 Tie rod assembly...
  • Page 28 7.Explosive diagram of Rubber as-protection PART# DESCRIPTION PART# DESCRIPTION Rubber splint II Plain washer Ø10 Rubber splint Full-thread hexagon bolts M10x30 Rubber sheet Lock nut M10 WWW.TMGINDUSTRIAL.COM P28/31 Toll Free:1-877-761-2819...
  • Page 29 8.Explosive diagram of Hydraulic assembly G15 G16 G3/G5/G5/G4 PART# DESCRIPTION PART# DESCRIPTION Hydraulic cylinder 50x32x255 Split pin 5x40 Shock absorber hydraulic cylinder Connecting plate 50x28x100 Full-thread hexagon bolts M24x90 Solenoid Valve Lock nut M24 HSCS - countersunk Plain washer Ø24 Transition Joints Hexagon socket head cap screws Full-thread hexagon bolts M24x100...
  • Page 30 NPT 1/2 male end, M16x1.5 fitting Hydraulic Hose 7/8”x1000mm with Full-thread hexagon bolts M8x20 M16x1.5 fitting Hydraulic Hose 7/8”x750mm with Lock nut M8 M16x1.5 fitting Cylinder pin 2 Transition joints 9.Explosive diagram of Hanging plate assembly PART# DESCRIPTION PART# DESCRIPTION Hanging plate weldment Full-thread hexagon bolts M16x40 Plain washer Ø16...
  • Page 31 10.Explosive diagram of Electrical circuit Specification Material Seven-pin plug for tractor Engineering plastics Single hole button box Engineering plastics Green button A38-11 self-locking Engineering plastics Button label box Engineering plastics Hydraulic solenoid valve coil plug Engineering plastics 12AWG small fuse holder Engineering plastics RVC2*1 Copper...
