TMG -SJM36 Product Manual

High pressure sewer jetting machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT MANUAL
High Pressure Sewer Jetting Machine
3600PSI,4.0GPM, 14HP KOHLER Engine
MODEL: TMG-SJM36
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your requests
WWW. T M G IND US T R I A L .C O M
T ol l Fr e e: 1 - 8 7 7 - 7 6 1 - 2 8 1 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMG-SJM36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TMG TMG-SJM36

Summary of Contents for TMG TMG-SJM36

  • Page 1 PRODUCT MANUAL High Pressure Sewer Jetting Machine 3600PSI,4.0GPM, 14HP KOHLER Engine MODEL: TMG-SJM36 Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...

  • Page 2: Table Of Contents

    Contents 1. Introduction.....................................02 2. Products Identification..................................03 3. Safety Guidelines....................................03 4. Products Specifications..................................07 5. Parts Identification and Features..............................08 6. Unpacking & Assembly...................................11 7. Setting Up Before Use..................................14 8. Safe Working Environment................................15 9. Startup and Stop Procedure................................16 10. Operation.......................................17 11. Maintenance....................................19 12. Storage......................................21 13.

  • Page 3: Products Identification

    2. Products Identification RECORD IDENTIFICATION NUMBERS If you need to contact an Authorized Dealer for information on servicing, always provide the product model and identification numbers. You will need to locate the model, revision and serial number for the machine and record the information in the places provided below.
  • Page 4 3. Safety Guidelines (Continued) DANGER- RISK TO BREATHING • Running engine gives off carbon monoxide, an odorless, colorless, poison gas. • Breathing carbon monoxide can cause nausea, fainting or death. • Some chemicals or detergents may be harmful if inhaled or ingested, causing severe nausea, fainting or poisoning.
  • Page 5 3. Safety Guidelines (Continued) WARNING-RISK TO FLUID INJECTION • The high pressure stream of water that this equipment produces can cut through skin and its underlying tissues, leading to serious injury and possible amputation. Spray gun traps high water pressure, even when engine is stopped and water is disconnected, which can cause injury.
  • Page 6 3. Safety Guidelines (Continued) DANGER-- RISK OF HOT SURFACES • Contact with hot surfaces, such as engines exhaust components, could result in serious bum. During operation, touch only the control surfaces of the pressure washer. Keep children away from the pressure washer at all times. They may not be able to recognize the hazards of this product. DO NOT let hoses come in contact with very hot engine muffler during or immediately after use of your pressure washer.

  • Page 7: Products Specifications

    4. Products Specifications Model No. TMG-SJM36 3600PSI Max Pressure Max Flow 4.0GPM Pump Model TMG-PMP48,Triplex, Engine Direct Drive Power and Type KOHLER CH440, Electric Start Battery 12V, 20AH High Pressure Hose ID1/4" x 200FT Lightweight Flexible Sewer Jetting Hose Nozzle...

  • Page 8: Parts Identification And Features

    5. Parts Identification and Features W W W . T M G I N D U S T R I A L . C O M P 0 8 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 9 5. Parts Identification and Features (Continued) 5.1 High Pressure Water Pump 5.2 KOHLER Engine W W W . T M G I N D U S T R I A L . C O M P 0 9 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 10 5. Parts Identification and Features (Continued) 5.3 General Technology PSI: Pounds per square inch -common unit measure used for water pressure, air pressure, hydraulic pressure and pounds of force. GPM: Gallons per minute (liters per minute [metric]) -common unit measure used for flow rate of water. Bypass Mode: In bypass mode, high pressure pump recirculates water because spray gun trigger is not pulled.

  • Page 11: Unpacking & Assembly

    6. Unpacking & Assembly 6.1 Unpacking 1.Carefully cut the box down the sides then remove the tool and any accessories from the box. Make sure than all items are included Unit is heavy. Do not attempt to lift and remove the pressure washer unit from the carton.
  • Page 12 7. Setting Up Before Use 7.1 Attaching One Side Of The Connection Hose To Pump 1. Pull back the slip ring on quick-disconnect fitting of the pump outlet. 2. Insert quick-disconnect plug on the connection hose into female quick-disconnect on the pump outlet. 3.
  • Page 13 7. Setting Up Before Use (Continued) 7.5 Add Oil To The Engine 1. Place pressure washer on a flat, level surface. 2. Clean area around oil fill and remove yellow oil fill cap. 3. Using oil funnel (optional), slowly pour contents of provided oil bottle into oil fill opening.

  • Page 14: Setting Up Before Use

    7. Setting Up Before Use (Continued) W W W . T M G I N D U S T R I A L . C O M P 1 4 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...

  • Page 15: Safe Working Environment

    8. Safe Working Environment Pressure Jetter Location Clearances and Air Movement • Exhaust heat/gases can ignite combustibles, structures or damage fuel tank causing a fire. Keep at least 5 ft. (1.5 m) clearance on all sides of pressure jetter including overhead. Place pressure jetter in a well ventilated area, which will allow for removal of deadly exhaust gas.

  • Page 16: Startup And Stop Procedure

    9.Startup and Stopping Procedure 9.1 How to Start Your Pressure Washer To start your pressure jetter for the first time, follow these instructions step-by-step. This starting information also applies if you have let the pressure washer sit idle for at least a day. 1.

  • Page 17: Operation

    10. Operation 10.1 Jet Nozzle Selection 1. Penetrating nozzle have an orifice in the front to cut through the stoppage, and a tight/narrow jetting angle (15°) has more driving power for long runs. 2. Flushing nozzle features with no front orifice and a wide spray pattern (40°) does a better job of cutting the grease off of the walls of the pipe.
  • Page 18 10. Operation (Continued) 10.4-1 Slowly fed and pull back At times, it will be necessary to move the hose slightly in and out of the drain line to assist the Jetting nozzle in clearing stubborn clogs, Obstructions, or tight corners 10.4-2 When the hose stucks Rotate the hose a quarter to half turn on orient the set of the hose to the direction change.

  • Page 19: Maintenance

    11. Maintenance To ensure efficient operation and longer life of your pressure jetter a routine maintenance schedule should be prepared and followed. If the equipment is used in unusual conditions such as high-temperature or dusty conditions more frequent maintenance checks will be required. Before performing any maintenance be aware that the equipment should be completely shutdown, depressurized and allowed to cool down.
  • Page 20 11. Maintenance ( Continued) 11.5 High Pressure Hose: The high pressure stream of water can cut Replace the high pressure hose when the hose through skin and its underlying tissues, leading to serious injury and possible have any of the below circumstance: amputation.

  • Page 21: Storage

    12. Storage 1. After General / Regular Use 1 . When completing pass through drain, watch for tape marker on hose as you pull the hose out. Reduce pressure gradually with pressure regulator knob until pressure gauge is at zero. Stop the jetter engine Continue to run water through pump and hose for 30 to 60 seconds.

  • Page 22: Troubleshooting

    13. Troubleshooting PROBLEM PROBABLE CAUSE SOLUTION Engine shuts down 1. 0ut of fuel. 1. Fill fuel tank. when running. 2. Low Engine Oil 2. Add oil. 1. Rocker switch set to "OFF" position. 1. Set switch to "ON" position. 2. Fuel valve is in "OFF" position. 2.
  • Page 23 13. Troubleshooting (Continued) PROBLEM PROBABLE CAUSE SOLUTION 1. Kinked or collapsed garden hose. 1. Remove kink or replace worn hose. 2. Water supply not turned on. 2. Turn water supply on. No Water Flow. 3. Clogged nozzle. 3. Remove nozzle & clean orifices. 4.

  • Page 24: Pressure Washer Exploded View & Parts List

    14. Pressure Jetter Exploded View & Parts List REF NO. DESCRIPTION Q’TY REF NO. DESCRIPTION Q’TY Handle Nut,Axle Wheel Hose reel assy Axle Washer D8 Nut M8 Bolt M8 x 16 Frame Anti-vibration feet M10 x 20 Battery 12V/20AH Pump bracket Nut M8 High pressure pump Washer D8...

  • Page 25: Pump Exploded View & Parts List

    15. Exploded View & Parts List (Triplex Pump) W W W . T M G I N D U S T R I A L . C O M P 2 5 / 2 6 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
  • Page 26 15. Exploded View & Parts List (Triplex Pump) REF NO. DESCRIPTION Q’TY REF NO. DESCRIPTION Q’TY Screw Jam nut Cover,crankshaft Unloader valve assy O-ring, oil sight glass Seat,valve body Oil side glass O-ring, valve seat Oil level plate Gasket, unloader valve housing Retain ring Unloader valve housing O-ring...
