HARBOR BREEZE and logo design are trademarks or
registered trademarks of LF, LLC. All rights reserved.
ATTACH YOUR RECEIPT HERE
Purchase Date _________________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also
contact us at partsplus@lowes.com.
AS23113
RETRACTABLE FAN
1
ITEM #5249289, 5336648
PRESTWICK
MODEL #42868, 42869
Español p. 16
Advertisement
Related Manuals for Harbor Breeze PRESTWICK 42868
Summary of Contents for Harbor Breeze PRESTWICK 42868
- Page 1 PRESTWICK RETRACTABLE FAN MODEL #42868, 42869 Español p. 16 HARBOR BREEZE and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. ATTACH YOUR RECEIPT HERE Purchase Date _________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 888-251-1003, 8 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents..............3 Preparation . -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Mounting Bracket Canopy Screw (preassembled to Mounting Bracket [A] Canopy Canopy Cover Downrod Pack Yoke Cover 12-Inch Downrod Tube (optional) Motor Assembly Set Screw (preassembled to Motor Assembly [H]) Fitter Plate Screw (preassembled to Fitter Plate [K]) Fitter Plate (preassembled to Motor Assembly [H]) Light Kit Lens... -
Page 4: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. Failure to do so could lead to electrical shock, fire or other injuries that could be hazardous or even fatal. • Before you begin installing the fixture, disconnect the power by removing fuses or turning off the circuit breakers. - Page 5 SAFETY INFORMATION CAUTION: • This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: 1) This device may cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. •...
-
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. Turn off the circuit breakers and the wall switch to the supply line leads. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. 2. Install the mounting bracket (A) to the outlet box (not included) using the screws and washers provided with the outlet box. - Page 7 ASSEMBLY INSTRUCTIONS 4. Loosen but do not remove the two set screws (I) in the yoke of the motor assembly (H). Slide the downrod tube into the yoke of the motor assembly Downrod Tube (H), align the holes, then install the downrod pin and downrod clip from downrod pack (E).
- Page 8 ASSEMBLY INSTRUCTIONS 7. Secure all wiring connections together with wire White (neutral) connectors from remote pack (N) according to the diagram and these steps: Green/Bare Black (hot) • Connect the green wires from the downrod and (ground) mounting bracket (A) to the bare/green (ground) Receiver supply wire.
- Page 9 ASSEMBLY INSTRUCTIONS 10. Connect the pin connectors on the wires from motor assembly (H) to the connector ports in the receiver Receiver Antenna from remote pack (N). Then, insert the receiver, antenna first, into the mounting bracket (A) with the flat side facing the ceiling.
- Page 10 ASSEMBLY INSTRUCTIONS 13. Connect the 2-pin connector from the fitter plate (K) to the 2-pin connector from the light kit (L). 2-Pin Connector 14. Bend the lens (M) just enough to fit it into the bottom edge of light kit (L). Note: Do not bend so much that it forms a crease in the lens (M).
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS 1. Remove the battery cover from the back of the remote found in remote pack (I). Insert the batteries from remote pack (I) into the remote; ensure polarity of battery matches the polarity indicated in the battery compartment -- positive (+) to positive (+) and negative (--) to negative (--). -
Page 12: Care And Maintenance
CARE AND MAINTENANCE At least twice each year, tighten all screws on the fan. Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. Total fixture wattage is 36 watts; do not attempt to replace LED. Battery Replacement: Use 1.5v (AAA) alkaline batteries. - Page 13 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. The blades are loose. 1. Check and tighten all screws that hold the fan blades to the blade arms and the motor. 2. There is a cracked blade. 2. Replace the cracked blade. 3.
-
Page 14: Limited Lifetime Warranty
LIMITED LIFETIME WARRANTY Set forth below, the manufacturer warrants the fan motor for this ceiling fan to be free from defects in workmanship and material for the life of the product. Also, subject to the limitations below, the manufacturer warrants all ceiling fan parts (“ceiling fan parts” excludes the motor and parts made in whole or in part with glass) to be free from defects in workmanship and material for a period of one year after the date of purchase by the original purchaser at retail. - Page 15 REPLACEMENT PARTS LIST For replacement parts, call the customer service department at 888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also contact us at partsplus@lowes.com. 5249289 5336648 PART DESCRIPTION PART# PART# Mounting Bracket 4L000016960 4L000016960 Canopy 4L000016970 4L000017030 Canopy Cover...
