- Page 1 The Embedded I/O Company TA900 Program and Debug Box Version 1.0 User Manual Issue 1.0.1 July 2012 TEWS TECHNOLOGIES GmbH Am Bahnhof 7 25469 Halstenbek, Germany Phone: +49 (0) 4101 4058 0 Fax: +49 (0) 4101 4058 19 e-mail: info@tews.com...
- Page 2 However TEWS TECHNOLOGIES GmbH reserves the right to change the product described in this document at any time without notice. TEWS TECHNOLOGIES GmbH is not liable for any damage arising out of the application or use of the device described herein.
- Page 3 Issue Description Date 1.0.0 Initial issue June 2011 1.0.1 General revision July 2012 TA900 User Manual Issue 1.0.1 Page 3 of 12...
-
Page 4: Table Of Contents
PIN ASSIGNMENT – I/O CONNECTOR ..............10 Front I/O ............................10 5.1.1 USB B-type Receptacle ......................10 5.1.1.1 Pin Assignment........................10 5.1.2 JTAG Header ..........................11 5.1.2.1 Pin Assignment........................11 FPC Connector ..........................12 5.2.1 Pin Assignment ........................12 TA900 User Manual Issue 1.0.1 Page 4 of 12... - Page 5 List of Figures FIGURE 1-1 : BLOCK DIAGRAM........................6 FIGURE 5-1 : TA900 FRONT I/O........................10 FIGURE 5-2 : USB B-TYPE RECEPTACLE VIEW ..................10 FIGURE 5-3 : JTAG HEADER VIEW ......................11 FIGURE 5-4 : FPC CONNECTOR VIEW ......................12 List of Tables TABLE 2-1 : TECHNICAL SPECIFICATION.....................7 TABLE 5-1 : USB B-TYPE RECEPTACLE DETAILS ..................10...
-
Page 6: Product Description
The Interface Box connects to compatible modules via a 20-pin Flexible Printed Circuit (FPC) Connector which can provide access to the module's JTAG Chain and the additional interfaces A and B. The TA900 can be accessed by USB 2.0 and by a 14-pin JTAG Header, and is equipped with a Pushbutton Switch which is offering the possibility to send an impulse to one of the connected module's I/O pins. -
Page 7: Technical Specification
If FIT rates are not available, MIL-HDBK-217F and MIL-HDBK-217F Notice 2 formulas are used for FIT rate calculation. Humidity 5 – 95 % non-condensing Weight 132 g Size 139.7mm x 82.6mm x 26.2mm Table 2-1 : Technical Specification TA900 User Manual Issue 1.0.1 Page 7 of 12... -
Page 8: Configuration
Lattice Devices for example can directly be programmed without the necessity of an additional Programming Cable, as the TA900 is directly supported by Lattice's Software Tool "ispVM". Whether the JTAG Chain of the module connected to the FPC Connector is accessed by the JTAG Header... -
Page 9: Led Configuration
LED Configuration The yellow LEDs for Interface A and Interface B in the TA900 Front Panel can be configured to operate in two different ways by setting DIP Switches: o Set to Logic, the LEDs indicate the logic level of the corresponding interface pins. -
Page 10: Pin Assignment - I/O Connector
5 Pin Assignment – I/O Connector Front I/O The following figure shows the Front I/O Interface of the TA900. Figure 5-1 : TA900 Front I/O 5.1.1 USB B-type Receptacle Pin-Count Connector Type USB B-type Receptacle Source & Order Info Kycon KUSBX-BS1N-W or compatible... -
Page 11: Jtag Header
Figure 5-3 : JTAG Header view 5.1.2.1 Pin Assignment The pinout of the TA900 JTAG Header matches the pinout of the "Xilinx Platform Cable USB II". This means that the Xilinx 14-pin ribbon cable can be connected to the TA900 without any adaption. -
Page 12: Fpc Connector
1mm pitch Flexible Printed Circuit Connector Source & Order Info Tyco 2-84953-0 or compatible Table 5-5 : FPC Connector details Figure 5-4 : FPC Connector view The TA900 comes with an FPC Flexcable (Adapt SYSTEM 280-1.00-B-20-200-5-5-10-10 or compatible) 5.2.1 Pin Assignment Signal...
