The Embedded I/O Company
TPMC463
4 Channel Serial Interface RS232/RS422
Version 1.0
User Manual
Issue 1.0.12
May 2020
TEWS TECHNOLOGIES GmbH
Am Bahnhof 7
25469 Halstenbek, Germany
Phone: +49 (0) 4101 4058 0
Fax: +49 (0) 4101 4058 19
e-mail:
info@tews.com
www.tews.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPMC463 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tews Technologies TPMC463

  • Page 1 The Embedded I/O Company TPMC463 4 Channel Serial Interface RS232/RS422 Version 1.0 User Manual Issue 1.0.12 May 2020 TEWS TECHNOLOGIES GmbH Am Bahnhof 7 25469 Halstenbek, Germany Phone: +49 (0) 4101 4058 0 Fax: +49 (0) 4101 4058 19 e-mail: info@tews.com...
  • Page 2 2 Channel Serial RS232, 2 Channel Serial in this document at any time without notice. RS422, front panel and P14 I/O TEWS TECHNOLOGIES GmbH is not liable for any TPMC463-20R damage arising out of the application or use of the 4 Channel Serial RS232, front panel and P14 I/O device described herein.
  • Page 3 Clarified the difference between front- and back-I/O RS422 signals August 2010 1.0.11 General Revision August 2014 1.0.12 Fixed typos May 2020 Corrected “Size” in “Table 3 1: XR17D154 Local Space Configuration” TPMC463 User Manual Issue 1.0.12 Page 3 of 25...
  • Page 4: Table Of Contents

    PROGRAMMING HINTS ..................18 6.1 UART Baud Rate Programming....................18 PIN ASSIGNMENT – I/O CONNECTOR ..............20 7.1 Front Panel I/O Connector (TPMC463-1xR) ................20 7.2 Front Panel I/O Connector (TPMC463-2xR) ................21 7.3 Serial Channel to Front Panel Port Mapping................21 7.4 Back I/O PMC Connector (P14)....................22 7.4.1...
  • Page 5 TABLE 7-2 : PIN ASSIGNMENT RJ45 FRONT PANEL I/O CONNECTOR ...........21 TABLE 7-3 : SERIAL CHANNEL TO FRONT PANEL PORT MAPPING............21 TABLE 7-4 : TPMC463-10R PIN ASSIGNMENT BACK I/O PMC CONNECTOR (P14) ........22 TABLE 7-5 : TPMC463-11R PIN ASSIGNMENT BACK I/O PMC CONNECTOR (P14) ........23 TABLE 7-6 : TPMC463-12R PIN ASSIGNMENT BACK I/O PMC CONNECTOR (P14) ........24...
  • Page 6: Product Description

    1 Product Description The TPMC463 is a standard single-width 32 bit PMC module and offers 4 channels of high performance serial interface. Three different standard modules are available: The TPMC463-10R provides 4 RS232 interfaces. The TPMC463-11R provides 4 RS422 interfaces. The TPMC463-12R provides 2 RS232 and 2 RS422 interfaces.
  • Page 7: Technical Specification

    I/O Connector 4x RJ45 Modular Jack (AMP 406 732-1) PMC P14 I/O (64 pin Mezzanine Connector) Front I/O Pinout RS232 (TPMC463-10R/-12R): Compliant to TIA/EIA-561 (EIA- 232D) RS232 (TPMC463-20R): Compliant to TIP866-TM-20 Termination RS422: 120Ω between RxD+/- and CTS+/- of each channel Programmable Baud Rates RS232: up to 921.6 kbps...
  • Page 8: Table 2-1 : Technical Specification

    Physical Data Power Requirements TPMC463-10R: 30 mA typical @ +5V DC (no load) TPMC463-11R: 40 mA typical @ +5V DC (no load) TPMC463-12R: 35 mA typical @ +5V DC (no load) TPMC463-20R: 30 mA typical @ +5V DC (no load)
  • Page 9: Local Space Addressing

    Table 3-1 : XR17D154 Local Space Configuration Device Configuration Space PCI Base Address: XR17D154 PCI Base Address 0 (Offset 0x10 in PCI Configuration Space). The TPMC463 uses the Exar XR17D154 Quad UART to provide and control the 4 channels. Device Configuration Space PCI Address Size Content...
  • Page 10: Uart Register Sets

    8, 16, 32 0x140 – 0x17F Reserved 0x180 – 0x1FF Read FIFO with errors – 16, 32 64 bytes of RX FIFO data + LSR Table 3-4 : UART Register Set TPMC463 User Manual Issue 1.0.12 Page 10 of 25...
  • Page 11: Device Configuration Registers

    The Device Configuration Registers control general operating conditions and monitor the status of various functions. This includes a 16 bit general purpose counter, multipurpose input/outputs (not supported by the TPMC463), sleep mode, soft-reset and device identification, and revision. They are embedded inside the UART 0 Register Set.
  • Page 12: Uart Channel Configuration Registers

    0x0D Reserved 0x00 Xoff-2 – Xoff Character 2 0x0E Reserved 0x00 Xon-1 – Xon Character 1 0x0F Reserved 0x00 Xon-2 – Xon Character 2 Table 3-6 : UART Channel Configuration Registers TPMC463 User Manual Issue 1.0.12 Page 12 of 25...
  • Page 13 (Offset of the LCR register within a UART register set) For a detailed description of the serial channel registers please refer to the XR17D154 data sheet which is available on the Exar website (www.exar.com). TPMC463 User Manual Issue 1.0.12 Page 13 of 25...
  • Page 14: Xr17D154 Target Chip

    Table 4-1 : PCI Header Device-ID: 0x01CF TPMC463 Vendor-ID: 0x1498 TEWS TECHNOLOGIES Revision ID: XR17D154 silicon revision Subsystem-ID: 0x000A -10R 0x000B -11R 0x000C -12R 0x0014 -20R Subsystem Vendor-ID: 0x1498 TEWS TECHNOLOGIES TPMC463 User Manual Issue 1.0.12 Page 14 of 25...
  • Page 15: Configuration Eeprom

    Subsystem Vendor ID 0x2E 0x1498 0x03 Subsystem ID 0x2C s.b. Table 4-2 : Configuration EEPROM TPMC463-xx Subsystem-ID Value (Offset 0x0C): TPMC463-10R 0x000A TPMC463-11R 0x000B TPMC463-12R 0x000C TPMC463-20R 0x0014 The words following the configuration data contain:  The module version and revision ...
  • Page 16: Table 4-3 : Physical Configuration Eeprom Data

    0x0000 0x000F (Front or Back I/O only) Channels with enhanced RTS & CTS 0x3A 0x0000 0x0000 0x0000 0x0000 Support for RS232 only 0x3B-0x3F Reserved Table 4-3 : Physical Configuration EEPROM Data TPMC463 User Manual Issue 1.0.12 Page 16 of 25...
  • Page 17: Configuration Hints

    5 Configuration Hints The following chart shows the UART interface mapping of the different variants of the TPMC463. TPMC463-10R TPMC463-11R TPMC463-12R TPMC463-20R RS232 RS422 RS232 RS422 RS232 RS422 RS232 RS422 UART0 UART1 UART2 UART3 Table 5-1 : UART interface mapping Other configurations are available as factory build option on a per channel base.
  • Page 18: Programming Hints

    6 Programming Hints UART Baud Rate Programming Each of the 4 UART channels of the TPMC463 provides a programmable Baud Rate Generator. The clock of the XR17D154 UART can be divided by any divisor from 1 to 2 – 1. The divisor can be programmed by the UART channel DLM (Divisor MSB) and DLL (Divisor LSB) registers.
  • Page 19 3. Set UART channel EFR register bit 4 to '0' (latch modified MCR register setting). Note that the maximum baud rate for RS232 channel is 921.6 kps. Thus the minimum divisor value for RS232 channels is 0x0003 with MCR[7] = 0. TPMC463 User Manual Issue 1.0.12 Page 19 of 25...
  • Page 20: Pin Assignment - I/O Connector

    PMC I/O. In this case ask support for special board options with front I/O only. Front Panel I/O Connector (TPMC463-1xR) The TPMC463 front panel I/O connector is a RJ45 modular jack connector (e.g. AMP# 406 732-1). Figure 7-1 : I/O Connector Pinout Signal RS232...
  • Page 21: Front Panel I/O Connector (Tpmc463-2Xr)

    Front Panel I/O Connector (TPMC463-2xR) The TPMC463 front panel I/O connector is a RJ45 modular jack connector (e.g. AMP# 406 732-1). Figure 7-2 : I/O Connector Pinout Signal RS232 Signal RS422 TxD+ TxD- RxD- RxD+ Table 7-2 : Pin Assignment RJ45 Front Panel I/O Connector The RS232 pinout is compliant to TIP866-TM-20 or to the “Motorola Standard”.
  • Page 22: Back I/O Pmc Connector (P14)

    TxD3 RS232 Table 7-4 : TPMC463-10R Pin Assignment Back I/O PMC Connector (P14) The DSR/RI signals are connected with the DSR and RI transceiver inputs, making both DSR and RI available at the UART. This leaves the choice which signal to use in an application.
  • Page 23: Tpmc463-11R

    CTS1- RS422 TxD2- RS422 TxD2+ RS422 RxD2- RS422 RxD2+ RS422 RTS2- RS422 RTS2+ RS422 CTS2+ RS422 CTS2- RS422 TxD3- RS422 Table 7-5 : TPMC463-11R Pin Assignment Back I/O PMC Connector (P14) TPMC463 User Manual Issue 1.0.12 Page 23 of 25...
  • Page 24: Tpmc463-12R

    TxD3- RS422 Table 7-6 : TPMC463-12R Pin Assignment Back I/O PMC Connector (P14) The DSR/RI signals are connected with the DSR and RI transceiver inputs, making both DSR and RI available at the UART. This leaves the choice which signal to use in an application.
  • Page 25: Tpmc463-20R

    TxD3 RS232 Table 7-7 : TPMC463-10R Pin Assignment Back I/O PMC Connector (P14) The DSR/RI signals are connected with the DSR and RI transceiver inputs, making both DSR and RI available at the UART. This leaves the choice which signal to use in an application.
