- Page 1 The Embedded I/O Company TXMC397 Conduction Cooled, 2 Channel 10GBASE-T Ethernet Version 1.0 User Manual Issue 1.0.0 May 2024 TEWS Technologies GmbH Eggerstedter Weg 14, 25421 Pinneberg, Germany Phone: +49 (0) 4101 4058 0 info@tews.com www.tews.com...
- Page 2 TEWS Technologies GmbH. Any (X12d); Conduction Cooled reproduction without written permission is forbidden. (RoHS compliant) TEWS Technologies GmbH has made any effort to ensure that this manual is accurate and complete. However, TEWS Technologies GmbH reserves the TXMC397-20R right to change the product described in this document at any time without notice.
- Page 3 Issue Description Date 1.0.0 Initial issue May 2024 TXMC397 User Manual Issue 1.0.0 Page 3 of 12...
-
Page 4: Table Of Contents
X710 PCI Express Identifiers ......................9 ETHERNET INTERFACE STATUS LEDS ..............10 PIN ASSIGNMENT – I/O CONNECTORS ..............11 Back I/O P16 Connector (TXMC397-10R) ..................11 Back I/O P16 Connector (TXMC397-20R) ..................12 TXMC397 User Manual Issue 1.0.0 Page 4 of 12... - Page 5 TABLE 4-1 : X710 PCI EXPRESS IDENTIFIERS ..................... 9 TABLE 5-1 : STATUS LEDS ........................... 10 TABLE 6-1 : BACK I/O P16 CONNECTOR (TXMC397-10R) ................. 11 TABLE 6-2 : BACK I/O P16 CONNECTOR (TXMC397-20R) ................. 12 TXMC397 User Manual Issue 1.0.0...
-
Page 6: Product Description
The controller is equipped with a 64 Mbit Serial Flash to support PXE and iSCSI boot and LEDs indicate the different network activities. The two Ethernet interfaces of the TXMC397 are capable of performing an auto negotiation algorithm which allows both link-partners to determine the best link-parameters. The TXMC397 supports IEEE 1588/802.1AS Precision Time Protocol (PTP). -
Page 7: Technical Specification
If FIT rates are not available, MIL-HDBK-217F and MIL-HDBK-217F Notice 2 formulas are used for FIT rate calculation. Humidity 5 – 95 % non-condensing Weight 99 g Table 2-1 : Technical Specification TXMC397 User Manual Issue 1.0.0 Page 7 of 12... -
Page 8: Handling And Operation Instructions
This CCXMC module is sensitive to static electricity. Packing, unpacking and all other module handling has to be done with appropriate care. Power Dissipation This CCXMC module requires adequate conduction cooling! TXMC397 User Manual Issue 1.0.0 Page 8 of 12... -
Page 9: Pci Express Interface
X710 PCI Express Identifiers Vendor-ID 0x8086 (Intel) Device-ID 0x15FF (X710 for 10GBASE-T) Class Code 0x020000 (Ethernet Controller) Subsystem Vendor-ID 0x8086 (Intel) Subsystem Device-ID 0x0000 Table 4-1 : X710 PCI Express Identifiers TXMC397 User Manual Issue 1.0.0 Page 9 of 12... -
Page 10: Ethernet Interface Status Leds
Ethernet Interfaces. Due to the fact that CCXMCs are mounted upside-down on the carrier card the Status LEDs are visible on the back side of the TXMC397. A marking is placed close to the three Status LEDs to indicate the Ethernet Port they correspond to. -
Page 11: Pin Assignment - I/O Connectors
PORT2_TX2/RX2- PORT2_TX3/RX3+ PORT2_TX3/RX3- PORT2_TX0/RX0+ PORT2_TX0/RX0- PORT2_TX1/RX1+ PORT2_TX1/RX1- PORT1_TX2/RX2+ PORT1_TX2/RX2- PORT1_TX3/RX3+ PORT1_TX3/RX3- PORT1_TX0/RX0+ PORT1_TX0/RX0- PORT1_TX1/RX1+ PORT1_TX1/RX1- Table 6-1 : Back I/O P16 Connector (TXMC397-10R) Both ports lie within the X12d mapping (VITA46.9) TXMC397 User Manual Issue 1.0.0 Page 11 of 12... -
Page 12: Back I/O P16 Connector (Txmc397-20R)
PORT2_TX2/RX2- PORT2_TX3/RX3+ PORT2_TX3/RX3- PORT2_TX0/RX0+ PORT2_TX0/RX0- PORT2_TX1/RX1+ PORT2_TX1/RX1- PORT1_TX2/RX2+ PORT1_TX2/RX2- PORT1_TX3/RX3+ PORT1_TX3/RX3- PORT1_TX0/RX0+ PORT1_TX0/RX0- PORT1_TX1/RX1+ PORT1_TX1/RX1- Table 6-2 : Back I/O P16 Connector (TXMC397-20R) Both ports lie within the X8d mapping (VITA46.9) TXMC397 User Manual Issue 1.0.0 Page 12 of 12...
