- Page 1 The Embedded I/O Company TCP270 CompactPCI PMC Carrier Version 1.0 User Manual Issue 1.0.3 October 2021 TEWS TECHNOLOGIES GmbH Am Bahnhof 7 25469 Halstenbek, Germany Phone: +49 (0) 4101 4058 0 Fax: +49 (0) 4101 4058 19 e-mail: info@tews.com www.tews.com...
- Page 2 However TEWS TECHNOLOGIES GmbH reserves the right to change the product described in this document at any time without notice. TEWS TECHNOLOGIES GmbH is not liable for any damage arising out of the application or use of the device described herein.
- Page 3 Issue Description Date Initial Issue April 2003 New address TEWS LLC September 2006 1.0.2 User Manual Notation Changed November 2008 1.0.3 Corrected figure Pin Assignment for Back - I/O October 2021 TCP270 User Manual Issue 1.0.3 Page 3 of 14...
-
Page 4: Table Of Contents
FIGURE 5-3 : COMPACTPCI J2 PIN ASSIGNMENT ..................11 FIGURE 5-4 : PMC J11/P11 PIN ASSIGNMENT ................... 12 FIGURE 5-5 : PMC J12/P12 PIN ASSIGNMENT ................... 13 FIGURE 5-6 : PMC J14/P14 PIN ASSIGNMENT ................... 14 TCP270 User Manual Issue 1.0.3 Page 4 of 14... -
Page 5: Product Description
1 Product Description The TCP270 is a standard 3U CompactPCI carrier that provides front I/O and rear I/O for a single width PMC module. 32 bit accesses are supported on PCI bus with PCI frequency 33MHz. The TCP270 could be used as a mechanical adaptor to connect a standard PMC module in 3U CompactPCI systems. -
Page 6: Technical Specification
PCI I/O Signaling Voltage 3.3V or 5.0V PMC Slots I/O Access Front panel I/O P14 I/O via P2/J2 (TCP270-11 only) Power Requirements 10 mA typical @ VI/O DC without PMC Module Additional power is required by the PMC module Temperature Range Operating –... -
Page 7: Pmc To Pci Interface
CompactPCI system and the PMC have the same PCI signaling voltage. If you want to plug a 3.3V only PMC onto the TCP270, first make sure that your PCI bus works with 3.3V signaling voltage, and then remove the keying pin of the TCP270 from the 5V location, and assemble it in the 3.3V location. -
Page 8: Installation Of A Pmc Module
CompactPCI backplanes. The PMC is mounted to the TCP270 prior to installation within the chassis. If the PMC has a front panel, first remove the cover from the CompactPCI front panel cut-out. Install the PMC at an angle so that the PMC front panel penetrates the CompactPCI front panel cut-out. -
Page 9: Pin Assignment
5 Pin Assignment Figure 5-1 : Pin Assignment for Back - I/O CompactPCI J2 is only assembled on the TCP270-11. TCP270 User Manual Issue 1.0.3 Page 9 of 14... -
Page 10: Compactpci J1
GNT# RST# BRSVP1B5 BRSVP1A5 INTS INTP V(I/O) HEALTHY# IPMB_PWR INTD# INTC# INTB# INTA# +12V TRST# -12V Figure 5-2 : CompactPCI J1 Pin Assignment Not all signals are used by the TCP270. TCP270 User Manual Issue 1.0.3 Page 10 of 14... -
Page 11: Compactpci J2
I/O 54 I/O 55 I/O 56 I/O 57 I/O 58 I/O 59 I/O 60 I/O 61 I/O 62 I/O 63 I/O 64 V I/O Figure 5-3 : CompactPCI J2 Pin Assignment TCP270 User Manual Issue 1.0.3 Page 11 of 14... -
Page 12: Pmc J11 / P11
AD[17] FRAME# IRDY# DEVSEL# LOCK# PCI-RSVD PCI-RSVD V (I/O) AD[15] AD[12] AD[11] AD[09] C/BE[0]# AD[06] AD[05] AD[04] V (I/O) AD[03] AD[02] AD[01] AD[00] REQ64# Figure 5-4 : PMC J11/P11 Pin Assignment TCP270 User Manual Issue 1.0.3 Page 12 of 14... -
Page 13: Pmc J12 / P12
TRDY# +3.3V STOP# PERR# +3.3V SERR# C/BE[1]# AD[14] AD[13] M66EN AD[10] AD[08] +3.3V AD[07] PMC-RSVD +3.3V PMC-RSVD PMC-RSVD PMC-RSVD PMC-RSVD PMC-RSVD ACK64# +3.3V PMC-RSVD Figure 5-5 : PMC J12/P12 Pin Assignment TCP270 User Manual Issue 1.0.3 Page 13 of 14... -
Page 14: Pmc J14 / P14
I/O 53 I/O 54 I/O 55 I/O 56 I/O 57 I/O 58 I/O 59 I/O 60 I/O 61 I/O 62 I/O 63 I/O 64 Figure 5-6 : PMC J14/P14 Pin Assignment TCP270 User Manual Issue 1.0.3 Page 14 of 14...
