- Page 1 The Embedded I/O Company TAMC020-TM MTCA.4 PIM-Carrier μRTM Version 1.0 User Manual Issue 1.0.0 October 2013 TEWS TECHNOLOGIES GmbH Am Bahnhof 7 25469 Halstenbek, Germany Phone: +49 (0) 4101 4058 0 Fax: +49 (0) 4101 4058 19 e-mail: info@tews.com www.tews.com...
- Page 2 However TEWS TECHNOLOGIES GmbH reserves the right to change the product described in this document at any time without notice. TEWS TECHNOLOGIES GmbH is not liable for any damage arising out of the application or use of the device described herein.
- Page 3 Issue Description Date 1.0.0 Initial Issue October 2013 TAMC020-TM User Manual Issue 1.0.0. Page 3 of 21...
-
Page 4: Table Of Contents
I2C I/O Extender ..........................12 INSTALLATION ......................14 PMC Interface Module (PIM) Installation..................14 6.1.1 Using PIMs with Mid-size faceplates ..................14 6.1.2 Component Height Violation on TAMC020-TM-10R ............14 6.1.3 Voltage Limits on PIM Modules ....................15 μRTM Installation ..........................15 6.2.1 Insertion ..........................16 6.2.2 Extraction ..........................16... - Page 5 TABLE 8-1: ZONE 3 RP30 CONNECTOR PIN ASSIGNMENT..............19 TABLE 8-2: ZONE 3 RP31 CONNECTOR PIN ASSIGNMENT..............19 TABLE 8-3 : PIN ASSIGNMENT J10 CONNECTOR..................20 TABLE 8-4 : PIN ASSIGNMENT J14 PIM CONNECTOR ................21 TAMC020-TM User Manual Issue 1.0.0. Page 5 of 21...
-
Page 6: Product Description
M-LVDS control and data lines to the PMC back I/O signals. According to MTCA.4, the TAMC020-TM provides an I2C EEPROM, an I2C temperature sensor and an I2C I/O Extender device. The I/O Extender is used to provide various management signals on the μRTM, with the management being handled by the MMC of the TAMC261. -
Page 7: Technical Specification
If FIT rates are not available, MIL-HDBK-217F and MIL-HDBK-217F Notice 2 formulas are used for FIT rate calculation. Humidity 5 – 95 % non-condensing Weight 214 g Table 2-1 : Technical Specification TAMC020-TM User Manual Issue 1.0.0. Page 7 of 21... -
Page 8: Handling And Operating Instructions
Otherwise, damage to the TAMC020-TM or the slot it is used in may occur! Refer to the chapter “Component Height Violation on TAMC020-TM- 10R”... -
Page 9: Ipmi Support
Field Replaceable Unit (FRU) information. The MMC communicates via an Intelligent Platform Management Interface (IPMI) with superordinated IPMI controllers. The TAMC020-TM is controlled by the Front-AMCs MMC and provides a temperature sensor, FRU information and management signals for hot swap handle status and LED control. -
Page 10: Board Info Area
If the Zone 3 Interface Compatibility record matches the Zone 3 Interface Compatibility record in the TAMC261, the TAMC261 considers the μRTM to be compatible. Otherwise, the TAMC261 considers the μRTM to be incompatible. TAMC020-TM User Manual Issue 1.0.0. Page 10 of 21... - Page 11 If a passive PIM does not use of any of the PIM supplies, the TAMC020-TM current requirement is 0 A. If an active PIM is used, the TAMC020-TM is able to supply up to 1 A on the +5 V and 1 A on the +3.3 V power rail.
-
Page 12: Functional Description
5 Functional Description JTAG The TAMC020-TM has no JTAG capable devices on-board; it just connects TDI with TDO, so that it does not break the Front-AMC’s JTAG chain. TCK and TMS are left unconnected. I2C Bus The TAMC020-TM implements the following I2C devices / addresses on the μRTM I2C management bus:... -
Page 13: Table 5-2 : Μrtm I2C I/O Extender Port Assignment
Handle Status 0 = Handle/Switch closed 1 = Handle/Switch open Table 5-2 : μRTM I2C I/O Extender Port Assignment TAMC020-TM User Manual Issue 1.0.0. Page 13 of 21... -
Page 14: Installation
It is within the responsibility of the user to carefully check if a specific PIM can be used on a mid-size TAMC020-TM. If you are not sure that the available spacing to conductive parts of the PIM is sufficient, it is strongly recommended to use a TAMC020-TM with full-size front panel. -
Page 15: Voltage Limits On Pim Modules
If you are not sure that the available spacing is sufficient, it is strongly recommended to use the Full-Size TAMC020-TM-11R. It is within the responsibility of the user to carefully check if the Mid-Size module with its component height violation can be used in his system. Otherwise damage of the TAMC020-TM or the μRTM slot may occur! 6.1.3 Voltage Limits on PIM Modules... -
Page 16: Insertion
Blue LED turns “ON” (Module is ready to be extracted) 2. Loosen the screws of the front plate 3. Pull the module handle out completely and extract the μRTM from the slot. Zone 3 Keying The TAMC020-TM provides the following male keying pin: View Voltage Levels Rotation Dependent on PMC Modules, but >±10V... -
Page 17: Indicators
μRTM is ready to be extracted No fault FAIL Failure or out of service status μRTM is not powered up Green μRTM is powered and OK Table 7-1 : Front Panel LEDs TAMC020-TM User Manual Issue 1.0.0. Page 17 of 21... -
Page 18: O Connectors
RP31 Figure 8-1 : Connector Overview Board Connectors 8.2.1 Zone 3 Connectors The TAMC020-TM provides two 30-pair ADF connectors (RP30 and RP31) at the Zone 3 Interface. Pin-Count 30 contact pairs (60 signal contacts) + 30 GND pins Connector Type Advanced Differential Fabric (ADF) connector Source &... -
Page 19: Pim Slot Connectors
This approach may support differential signaling (e.g. for Ethernet etc.) but does not cause cross-talk when used with cards that provide single-ended I/O. Pin-Count Connector Type PMC Connector Source & Order Info Molex 71436-2864 or compatible TAMC020-TM User Manual Issue 1.0.0. Page 19 of 21... -
Page 20: Table 8-3 : Pin Assignment J10 Connector
DIR_TCLKC TCLKA TCLKA DIR_TCLKD TCLKA DIR_Rx_17 +3.3V DIR_Tx_17 Rx_17 Tx_17 DIR_Rx_18 Rx_18 DIR_Tx_18 DIR_Rx_19 Tx_18 Rx_19 DIR_Tx_19 Tx_19 DIR_Rx_20 +3.3V DIR_Tx_20 Rx_20 -12V Tx_20 Table 8-3 : Pin Assignment J10 Connector TAMC020-TM User Manual Issue 1.0.0. Page 20 of 21... -
Page 21: Table 8-4 : Pin Assignment J14 Pim Connector
IO_42 IO_43 IO_44 IO_45 IO_46 IO_47 IO_48 IO_49 IO_50 IO_51 IO_52 IO_53 IO_54 IO_55 IO_56 IO_57 IO_58 IO_59 IO_60 IO_61 IO_62 IO_63 IO_64 Table 8-4 : Pin Assignment J14 PIM Connector TAMC020-TM User Manual Issue 1.0.0. Page 21 of 21...
