Compiling the Standalone RDK Libraries

Before compiling the library, configure it as explained in
BRARIES USING THE RDK-GUI, page
1. Run the ST Visual Develop v3.2.0 or Softec STDV7 v3.10 and choose "File > Open Workspace".
2. Select the "RDK Libraries\AC\acmotor.stw," "RDK Libraries\PMDC\pmdcmotor.stw," or
"RDK Libraries\PMAC\pmacmotor.stw" as workspace files, depending on the motor type.
3. The default project in use is for Cosmic compiler. It will be "ac_cosmic.stp", "pmdc_cosmic.stp", or
"pmac_cosmic.stp", depending on the motor type. If Metrowerks Compiler is being used, select the
Metrowerks-specific projects, "ac_metrowerks.stp", "pmdc_metrowerks.stp", or
"pmac_metrowerks.stp", depending on the motor type.
4. Use the "Build" pull-down menu to display and select the "Build" command. The project will be
compiled and built, and an executable file will be generated.
Table 1. Reference Kit GUI Subfolders
Folder Name
template\
RDK Libraries\AC\
RDK Libraries\AC\Source\
RDK Libraries\AC\Release\
RDK Libraries\PMDC\
RDK Libraries\PMDC\Source\
RDK Libraries\PMDC\Release\ where the executable and object files will be created
RDK Libraries\PMAC\
RDK Libraries\PMAC\Source\
RDK Libraries\PMAC\Release\
16/21
3.
where the template files for the GUI are stored
root path of the software library for the AC Induction motor
where the source code of the library for the 3PH AC Induction motor is stored
where the executable and object files will be created
root path of the software library for Brushless DC motor
where the source code of the library for the 3PH PMDC/AC or BLDC/AC motor is
stored
root path of the software library for the PMAC motor
where the source code of the library for the 3PH PMAC or BLAC motor is stored
where the executable and object files will be created
CONFIGURING THE STANDALONE RDK LI-
Description
