  • Page 1 OWNER´S MANUAL REFERENCE LINE CD PLAYER HIGH END MADE IN GERMANY BURMESTER HOME AUDIO GMBH • WILHELM-KABUS-STRAßE 47 • 10829 BERLIN • GERMANY TEL +49/(0)30/78 79 68 – 0 • FAX +49/(0)30/78 79 68 – 68 • E-MAIL: mail@burmester.de • www.burmester.de...
  • Page 2 VERSION BA_069_en_1-9_2211...
  • Page 3 Dear Audiophile, Thank you for choosing this Burmester audio component. We sincerely appreciate your trust in us. You have purchased a unit which excels in musical fidelity and combines uncompromising manufacturing quality with technical innovation and the highest degree of operating flexibility.

  • Page 4: Table Of Contents

    C O N T E N T S UNPACKING AND SETTING UP FUNCTIONAL OVERWIEW OF FRONT AND REAR PANEL FIRST STARTUP CONNECTIONS OPERATING CONTROLS AND FUNCTION INDICATORS 9-10 SYSTEM-SETUP 11-14 REMOTE CONTROL 15-16 PROGRAMMING A FAVORITE TRACK SELECTION OF A CD NOTES TO THE MANAGEMENT OF CD PROGRAMS BURLINK 19-20...

  • Page 5: Unpacking And Setting Up

    UNPACKING AND SETTING UP CAUTION: The CD player 069 and the external power supply unit (if existent) are very heavy. To avoid injuries while unpacking it is suggested that only personnel with experiences in heavy weights unpack the units. CAUTION: The CD player 069 is shipped inside a plastic protective cover. Make sure that children do not play with it to avoid the danger of suffocation.

  • Page 6: Functional Overwiew Of Front And Rear Panel

    FUNCTIONAL OVERVIEW OF CD PLAYER UNIT FRONT PANEL Sliding cover (13) SKIP >>| button for selecting the next TRACK display indicates the current track tracks OPERATING MODE display of the CD drive (14) PROGRAMM-LED illuminates when a music REPEAT display program has been selected and saved TIME display shows time elapsed or remaining (15)
  • Page 7 FUNCTIONAL OVERVIEW OF CD PLAYER UNIT REAR PANEL WITH INTERAL POWER SUPPLY (not longer available) (23a) AC Mains Switch (32) Digital audio output RCA (75Ω) (23b) AC Mains Terminal (33) Digital audio input TORX (24) BURLINK interface RS-232 with check LEDs for optical cables (25) BURLINK interface USB with check LEDs...
  • Page 8 FUNCTIONAL OVERVIEW OF CD PLAYER UNIT REAR PANEL WITH EXTERNAL POWER SUPPLY (23) POWER SUPPLY terminal (32) Digital audio output RCA (75Ω) (24) BURLINK interface RS-232 with check LEDs (33) Digital audio input TORX (25) BURLINK interface USB with check LEDs for optical cables (26) MMI slot for new inputs or outputs...
  • Page 9 FUNCTIONAL OVERVIEW OF POWER SUPPLY UNIT IN REFERENCE LINE HOUSING FRONT PANEL (41) Base plate (43) POWER LED lights up red when the unit is on (42) Foot – constructed as spike REAR PANEL (44) AC mains terminal (46) POWER SUPPLY terminal (45) AC mains switch...

  • Page 10: First Startup

    FIRST STARTUP CAUTION: Before connecting the unit, please check if the input voltage of the 061 is equal to the local voltage of your wall outlet. Make sure the ground lead in your power outlet is working correctly. A missing or faulty ground is extremely dangerous! In case of doubt contact a licensed electrician.

  • Page 11: Connections

    CONNECTIONS All terminals for hook up are located on the rear panel. While connecting the CD player, all components of the music system must be turned off. There are various possibilities for connecting the CD player, depending upon the kind of audio components and auxiliary devices used.
  • Page 12 The pinning of the balanced inputs are: PIN1=GND, PIN2=NEG, PIN3=POS. ADDITIONAL CONNECTIONS REMOTE Connecting DC OUT (29) to the corresponding DC IN jack of another BURMESTER-unit offers to switch on or off this other unit simultaneous by the 069. In this case, 069 has the master function.

  • Page 13: Operating Controls And Function Indicators

    This shows that the unit is in standby mode. When the POWER switch is in “STBY“ position, the unit can be turned on and off by pushing up the POWER switch or pushing the POWER button on the BURMESTER remote control (accessory).
  • Page 14 THE FUNCTION INDICATORS POWER LED The POWER LED (22) of the CD player lights up orange and the POWER LED (43) of the power supply unit (if at hand) lights up green, if the CD player is in standby mode. Both LEDs lights up red, when the units are turned on.

  • Page 15: System-Setup

    SYSTEM SETUP The SYSTEM SETUP menu of the CD player 069 allows the easy programming of certain basic settings. All settings of the SYSTEM SETUP will be saved automatically after leaving the SETUP and remain after switching off the unit. The SYSTEM SETUP can be operated only with the key D MENU and the navigation keys ▲, ▼, ►, ◄...
  • Page 16 SHORT DESCRIPTION OF THE MENU ITEMS MENU ITEM SHAORT DESCRIPTION DEFAULT The CD player starts automatically playback of the CD AUTO after switching on (ON) or not (OFF) You can choose between defined (FIX) or adjustable OUTPUT VARIABLE (VARIABLE) output level of the analog outputs. You can select the initial volume level, if you have INIT-VOLUME selected the adjustable output (VARIABLE) in the menu...
  • Page 17 DESCRIPTION OF THE MENU ITEMS OF THE SYSTEM SETUP AUTO You can choose, if the CD player should start playback directly after switching on the unit. The unit reads only the table of content and remains in STOP mode. The unit begins playing the CD directly after switching on. OUTPUT You can choose between defined (FIX) or adjustable (VARIABLE) output level of the analog outputs.
  • Page 18 Attenuation of the analog outputs is set to 10dB. BUR-LIB This menu item either enables or disables the Burmester Library function, see chapters PROGRAMMING A FAVOURITE TRACK SELECTION OF A CD and HINTS FOR ADMINISTRATING CD PROGRAMS for further details.

  • Page 19: Remote Control

    REMOTE CONTROL POWER The key POWER switches the CD player on or off, provided the mains switch on the rear panel of the CD player or on the rear panel of the external power supply (if at hand) is set to ON and the power switch on the front panel is set to STBY.
  • Page 20 SKIP |< By briefly pressing the key SKIP |< playback is returned to the beginning of the playing track. By pressing it several times you can skip back step by step. SEARCH >> Briefly pressing the key SEARCH >> alternately activates the slow or the fast forward mode. To switch back to normal playback mode, press the key PLAY/PAUSE.

  • Page 21: Programming A Favorite Track Selection Of A Cd

    PROGRAMMING A FAVOURITE TRACK SELECTION OF A CD A total of 20 tracks from a CD can be programmed for playback in a selected order. Programming can only be done using the remote control. The program plays the tracks in the selected order. Activating the To start the program function, press the key PROGR.

  • Page 22: Notes To The Management Of Cd Programs

    HINTS FOR ADMINISTRATING CD PROGRAMS The 069 remembers user defined CD programs and stores them into a library memory. If you play any CD that ever had a user program, the CD player asks you to play the stored program after having read the table of content (PLAY LIB?) assumed that the BUR-LIB item in the SETUP MENU is turned ON.

  • Page 23: Burlink

    BURLINK CONNECTIONS Connecting to the BURLINK interface can be done either with the 9 pin D-SUB connector (RS-232) or with the USB connector. RS-232 configuration: 9600Baud, 8bit, parity: none, 1 stop bit, no hardware handshake A USB device driver needs to be installed when using the USB connector. System requirements for using the USB software are either WINDOWS 2000 or WINDOWS XP operating system.
  • Page 24 REPEAT\r switches on the repeat modes (Track, Disc) or off REPEATTRACK\r switches on the track repeat function REPEATDISC\r switches on the disc repeat function REPEATOFF\r switches off any repeat function REPEATAB\r switches successively: set of beginning mark, set of end mark, off MENU\r opens and closes the SETUP-MENU PROGRAM\r...

  • Page 25: General Instructions

    For the cleanest power supply we recommend our triple-shielded power cord BURMESTER- POWER. IR receiver The IR receiver receives signals from the BURMESTER remote control and must not be covered up by objects. Heat development Be careful when touching the housing – it may get quite warm during operation.
  • Page 26 Fuses The fuses are located inside the unit and should be changed only by a qualified technician. We provide a three-year warranty on your Burmester device. In order for the warrantyto be Warranty valid, the device must have been connected and operated properly withoutoverloading, the mechanical integrity of the device must not have been compromised, and the device must have been registered.

  • Page 27: Technical Specifications

    TECHNICAL SPECIFICATIONS Dimensions 450 x 160 x 340 mm CD player incl. base plate (W x H x D) (17.7 x 6.3 x 13.4 inches) Power supply unit incl. base plate (W x H x D) 450 x 160 x 340 mm (17.7 x 6.3 x 13.4 inches) Power supply unit TOP LINE (W x H x D) 482 x 95 x 340 mm...
