Summary of Contents for Burmester 061

  • Page 3 Dear Audiophile, Thank you for choosing this Burmester audio component. We sincerely appreciate your trust in us. You have purchased a unit which excels in musical fidelity and combines uncompromising manufacturing quality with technical innovation and the highest degree of operating flexibility.

  • Page 4: Table Of Contents

    C O N T E N T S UNPACKING AND SETTING UP FUNCTIONAL OVERWIEW OF FRONT AND REAR PANEL CONNECTIONS OPERATING CONTROLS AND FUNCTION INDICATORS SYSTEM-SETUP REMOTE CONTROL 9-10 PROGRAMMING A FAVORITE TRACK SELECTION OF A CD BURLINK (optional) GENERAL INSTRUCTIONS 13-14 TECHNICAL SPECIFICATIONS SECURITY NOTICE...

  • Page 5: Unpacking And Setting Up

    UNPACKING AND SETTING UP CAUTION: The CD player 061 is shipped inside a plastic protective cover. Make sure that children do not play with it to avoid the danger of suffocation. Unpacking To avoid damaging the housing, please do not use pointed or sharp tools to open the box.

  • Page 6: Functional Overwiew Of Front And Rear Panel

    FUNCTIONAL OVERVIEW FRONT PANEL INPUT LEDs indicates the selected input (10) IR receiver for remote control SYNC LED indicates a correct data stream input (11) AUDIO LED shows upsampling of 192kHz Sliding cover (12) STOP button TRACK display indicates the current track (13) PLAY/PAUSE button TIME display shows time elapsed or remaining...

  • Page 7: Connections

    CAUTION: Before connecting the unit please check if the input voltage of the 061 is equal to the local voltage of your wall outlet. Make sure the ground lead in your power outlet is working correctly. A missing or faulty ground is extremely dangerous! In case of doubt contact a licensed electrician.
  • Page 8 REMOTE Connecting DC OUT (22) to the corresponding DC IN-jack of another BURMESTER-unit offers to switch on or off this other unit simultaneous by the 061. In this case, 061 has the master function. Connecting DC IN (23) to the corresponding DC OUT-jack of another BURMESTER-unit offers to switch on or off the 061 simultaneous by the other unit.

  • Page 9: Operating Controls And Function Indicators

    In operating mode (ON) the POWER LED (16) lights up red and all functions of the CD player are activated. PLEASE NOTE: Always switch off the 061 with the POWER switch first before bringing the AC mains switch into OFF position.
  • Page 10 THE FUNCTION INDICATORS POWER LED The POWER LED (16) lights up orange, if the CD player is in standby mode and lights up red, when the unit is turned on. AUDIO LED The AUDIO LED (11) illuminates, when the internal sample rate of the D/A converter is switched to 192kHz.

  • Page 11: System-Setup

    SYSTEM SETUP The SYSTEM SETUP menu of the CD player 061 allows the easy programming of certain basic settings. All settings of the SYSTEM SETUP will be saved automatically after leaving the SETUP and remain after switching off the unit.
  • Page 12 DESCRIPTION OF THE MENU ITEMS OF THE SYSTEM SETUP AUTO You can choose, if the CD player should start playback directly after switching on the unit. The unit reads only the table of content and remains in STOP mode. The unit begins playing the CD directly after switching on. You can choose, if the type and the serial number of the unit will be shown in the alphanumeric display after switching on the player.

  • Page 13: Remote Control

    REMOTE CONTROL POWER The key POWER switches the CD player on or off, provided the Mains switch is set to ON and the power switch on the front panel is set to STBY. Pressing the key DIM varies the brightness of the alphanumeric display in four steps between “max.
  • Page 14 TORX, MMI (optional) or the internal CD drive. A lit INPUT LED (1) indicates the selected input. Input selecting with the STATION keys is only possible, when the menu item RC-I in the SYSTEM SETUP is set to ON. All other keys of the remote control have no functions with respect of the 061.

  • Page 15: Programming A Favorite Track Selection Of A Cd

    PROGRAMMING A FAVOURITE TRACK SELECTION OF A CD A total of 50 tracks from a CD can be programmed for playback in a selected order. Programming can only be done using the remote control. The program plays the tracks in the selected order. Activating the To start the program function press the key PROGR.

  • Page 16: Burlink (Optional)

    USB software are either WINDOWS 2000 or WINDOWS XP operating system. COMMANDS Following are listed the possible commands to control the CD player 061. All commands needs to be sent in capital letters finished with a “carriage return“ \r .

  • Page 17: General Instructions

    For the cleanest power supply we recommend our triple-shielded power cord BURMESTER- POWER. IR receiver The IR receiver receives signals from the BURMESTER remote control and must not be covered up by objects. Heat development Be careful when touching the housing – it may get quite warm during operation.
  • Page 18 Lightening strikes During the summer months, malfunctions often occur due to voltage spikes in the power lines after lightning strikes. Completely unplugging the power cord offers the only effective protection. Merely switching the unit off does not suffice since voltage spikes are able to arc over separated contacts.

  • Page 19: Technical Specifications

    TECHNICAL SPECIFICATIONS Dimensions Width x Height x Depth 482 x 112 x 340 mm (19.0 x 4.4 x 13.4 inches) Weight ca. 9.6 kg (21.1 lbs) Mains voltage and fuses for 200V - 240V 50/60Hz 1 x slo 50mA E, 1 x slo 500mA E for 100V - 127V 50/60Hz 1 x slo 50mA E, 2 x slo 1A E Power consumption...

This manual is also suitable for:

Reference 069
