User Guide
GETTING STARTED
Enabling Toggle Mode
Toggle mode can be enabled by selecting the Enable Toggle/Dith-
er Functionality check box (see
the toggle view shown in Figure
applied to the selected pin or supplied internally.
Enabling Dither Mode
After enabling the toggle view shown in
the Enabling Toggle Mode section, select the dither mode from the
analog.com
Figure 5). This check box enables
6. The toggle signal can then be
Figure 6 as described in
Mode dropdown box to bring up the dither options (see
The default values for the dither phase (ⱷ
and N = 4. The phase and period of the dither can be modified
using the dropdown boxes to select from a fixed list of options.
Figure 6. Toggle View
UG-2001
Figure 7).
) and period (N) are 0°
0
Rev. 0 | 7 of 12
