TAKING A PICTURE

FLASH READY LED

Note: Do not power the camera off or switch modes while the camera is capturing or storing a picture or
video clip to prevent corrupting the picture or video clip being stored.
TAKING A PICTURE WITH THE LCD
4
A
AWB AWB
AWB
⁄ 07 ⁄ 04 ⁄ 03 02:40PM
Taking a picture with the LCD:
1. Turn on the camera.
2. Frame the subject in the LCD.
3. Press the shutter button half-way to activate the auto-focus lock until the green
AF LED lights up. (For more information on Focus Lock, please go to
page 12.) (fig.1.1)
• The camera will focus the lens at different distances to find the correct focus
range, and you will hear a rapid click sound from the camera.
4. Press the shutter button fully to capture the image. (fig.1.2)
• The camera will beep when the image is captured if sound is activated.
• The camera will make a click sound.
• When the image has been captured, the Flash Ready LED next to the
viewfinder will blink to indicate that the image is being stored.
• A preview of the image will be displayed on the LCD for 2 seconds and the
picture counter number displayed in the LCD will be updated.
Note: The best shooting range is from 50 cm to infinity. (20 in. to infinity)
fig.1.3
Steady
The camera is capturing
a picture or video clip.
AWB
Hold the camera steady
to prevent blurry
AWB
pictures.
AWB
AWB
M
28/45
A
A
AWB
⁄ ⁄
⁄ ⁄
AWB
fig.1.4
Blinking
A A
The flash is recharging.
You may move the
A A
AWB
⁄ ⁄ ⁄ ⁄ camera in this mode.
AWB
⁄ ⁄ ⁄ ⁄
A
A
⁄ ⁄
⁄ ⁄
CAMERA MODE
A
CAPTURE MODE
Q QUALITY SETUP
IMAGE SIZE
DIGITAL ZOOM
SCENE SELECTION
⁄ RETURN ⁄ SELECT
A
11
A
⁄ ⁄
CAPTURE MODE
A
+
+
AWB
RETURN SET
⁄ ⁄ OK
A
4 M
A 28/45
AWB
⁄ ⁄
AWB N
fig.1.1 ⁄ ⁄
4 M
A 28/45
A
AWB N
⁄ ⁄
fig.1.2
AWB
⁄ ⁄
⁄
AWB
⁄ ⁄
A
AWB
⁄ ⁄
