WESTERSTRAND CIRCLE LINE NTP User Manual page 10

Setting light intensity
The light intensity for the digits can be adjusted in 8 levels.
An automatic dimmer function regulates the light intensity.
Push [F] until display shows:
Push [P]
Display shows:
Push [P] for desired light intensity. Accept with [F].
Display shows:
Push [R] for entering base mode or push [F] for next function.
View / configure IP address
The Clocks IP address can be either static or dynamic (DHCP). Configuration of IP addressing work
mode is done using a web-browser. The default setting is DHCP.
Using the R F & P buttons it is possible to view or change the current IP-address. It is also possible to
see if the Clock is using static or dynamic IP address.
If the work mode is DHCP it is not possible to change the IP address manually.
To view the current IP address:
In this example we demonstrate IP address 192.168.2.51
1. Push [F] until display shows
IP mode d = dynamic (DHCP), s = static IP
2. Push [P] to select
3. Display shows
4. Push [P] to select
5. Display shows
6. Push [P] to select
7. Display shows
8. Push [P] to select
9. Display shows
10. Push [R]. Return to base mode
di sp
di 1
. Light intensity 1 (weakest) - 8 (strongest)
Sy nc
IP d
(IP mode)
A1 92
(first part)
b1 68
(second part)
C 2
(third part)
d 51
(fourth part)
DOK11108en02
2023-03-31
10 (28)
