    To distribute correct time to different users in a Local Area Network (LAN) the Network Time Protocol (NTP) is used. NTP is a part of the protocol family TCP/IP. Westerstrand analogue clocks type Ethernet LAN are operated and controlled by Time distributed in the Network...
  • Page 3 6. Connect the cable for the movement and remount the clock side. 7. Tighten the 4 clock side screws. 8. Connect the power to the clock. 9. The clock is ready for configuration. WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se...

  • Page 4: Configuration Using A Web-Browser

    If the first letter of the password is blank no question about user and password will appear. If you forget the password, then start TELNET. The last line shows a number of characters within square brackets []. Contact Westerstrand and enter this value. After login a list of functions is displayed: WESTERSTRAND URFABRIK AB P.O.
  • Page 5 A Alarms A/B_Hour/Min/Sec Side A or side B. No signal from hour, minute or second sensor, e.g. 'B_Min' - no signal from minute sensor on side B WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se SE-545 23 TÖREBODA...
  • Page 6 Download Firmware below. Save Save parameters. If new password was entered then the clock will restart. Then the web reader (e.g. Internet Explorer) also must be restarted. WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se SE-545 23 TÖREBODA Fax.
  • Page 7 Enter country GBR, SWE, FIN or CHE. The NTP protocol is based on UTC time so a country must be selected. Rules for DST (daylight saving time) for each country is hardcoded in the firmware. WESTERSTRAND URFABRIK AB P.O. Box 133 Tel.

  • Page 8: Telnet

    Select country. This info is used for calculation of local time from the UTC time in the NTP message. The controller contains day-light saving rules. Example: >C 46 [Enter] for Sweden. WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se...
  • Page 9 Document: 1855en02.doc WESTERSTRAND Author: TAn/MS Date: 2010-12-22 Page: 9 of 18 D – Display data Clock information is displayed NUR-B104 Westerstrand Urfabrik AB http://www.westerstrand.se ** Platform 4 clock C !! B_Hour B_Min UTC=2006-12-22 07:48:44.787 Fri LT =2006-12-22 08:48:44.787 Fri (Winter)
  • Page 10 X 71 – static IP address Inform that function X 54 refers to static IP address X 72 - DHCP Inform that the unit assigns IP-address automatically by DHCP. WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se...
  • Page 11 X 98 – Save Save settings to memory. The program is not restarted. Telnet is interrupted. X 99 – Save and restart Save and restart the program. Telnet is interrupted. WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se...

  • Page 12: Snmp

    Start the program on the server, e.g. 192.168.14.1. Import MIB file, here it is WESTERSTRAND_EN_110.MIB. Enter IP address for the clock, here it is 192.168.14.201. Enter ’Operations Walk’. Mark the MIB file and then Go. All the parameters is collected from the clock: WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se...
  • Page 13 Amount of seconds since the clock were started. Nationcode Country code ClockType Type of clock Manual Manual for the clock ClockIdent Text for identify the clock WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se SE-545 23 TÖREBODA Fax. +46 506 48051 E-mail: info@westerstrand.se...
  • Page 14 WESTERSTRAND Author: TAn/MS Date: 2010-12-22 Page: 14 of 18 Trap with program Ireasoning Enter function Tools|Trap Receiver. The traps are indicated from connected clocks. WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se SE-545 23 TÖREBODA Fax. +46 506 48051 E-mail: info@westerstrand.se...

  • Page 15: Raser

    This program are used for finding network clocks and setting parameters. RASER sends broadcast messages on UDP port 9999. All Westerstrand Ethernet controllers will answer. Install with setup file SETUP_RASERxxx.EXE (xxx=version e.g. 105). Icon 'RaSer' is created on the desktop.
  • Page 16 If the info window is right-clicked more functions are displayed. [Clear] Blank the info window [Log communication] Logg communication. Test. [About] Show program information WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se SE-545 23 TÖREBODA Fax. +46 506 48051 E-mail: info@westerstrand.se...

  • Page 17: Firmware

    Enter Download. The download starts automatically. After download the clocks restarts and the white screen will be blank. Check again that all the clocks are at the network with the program RASER. WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se...

  • Page 18: Technical Data

    Web-Based (requires web browser) or via Telnet Additional information: Support for DNS Temperature range: –20 ºC till +50 ºC. Power electronic: Elektronic 230V AC 50 Hz/4.5VA WESTERSTRAND URFABRIK AB P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se SE-545 23 TÖREBODA Fax. +46 506 48051 E-mail: info@westerstrand.se...
