Alarms
Shows if the Clocks has any alarms. The following alarm texts can be displayed.
No Alarms = Clock OK.
Not synchronised = The Clock is not synchronised.
5-minute limit = The received time message is more than 5 minutes wrong compared to internal
time. The message is not accepted.
Authentication = The MD5 authentication has failed.
Temp is out of bounds = Temperature reading is currently out of bounds.
NTP
Synchronised = The clock has been synchronised from an NTP server with name/IP ntp.se
s = Stratum, time quality. A low value is better.
n = Number of time settings from this NTP server.
TO = Timeout in minutes before NTP alarm.
Sensor
Dimmer=4/5: Current dimmer value / Set dimmer level. Maximum value 8.
Sensor=8784: Current light sensor data. Possible values 0-65535.
Temp=21° C: Current temperature reading.
Uptime
Time in operation since last power failure.
Firmware
Firmware version.
