DA7210/11 USER MANUAL
January 2022
User manual for the set-up and operation of the DA7210/11
evaluation board and control software

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA7210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Renesas DA7210

Summary of Contents for Renesas DA7210

  • Page 1 DA7210/11 USER MANUAL January 2022 User manual for the set-up and operation of the DA7210/11 evaluation board and control software...

  • Page 2: Table Of Contents

    Volume Control Panel RT Filters GUI Software Installation Control Panels 5.2.1 Running the Interface and USB Initialisation Filter Setup Panel Coefficients Tab Five-band Equaliser and Voice Filter Panel DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 3: Introduction

    The evaluation PCB is supplied together with a DVD ROM containing documentation and driver files. The driver software uses a simple graphical user interface (GUI), allowing the DA7210/11 device to be controlled via a USB port of a PC. An additional GUI is available to control the highly configurable filter paths within the DA7210/11;...
  • Page 4 A USB-I2C bridge is used for communication with the device, and there are number of external active components to reduce the requirement for external equipment. Figure 2 Evaluation Board 44-179-93-02-C Mainboard DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 5 DA7210/11 USER MANUAL Figure 3 DA7210 44-179-93-04-C Miniboard Figure 4 DA7211-00 44-179-93-04-B Miniboard DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 6: Power Supplies

    DUT the power supply pins. This configuration allows complete DUT operation using just USB and TOSLINK connections only, but maximum headphone power output will be limited when using +1.8V VDDDCP power supply. DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 7: Jumpers And Link Positions

    Headphone sense ground connected Should be disconnected for DA7211 Headphone sense ground disconnected HPL 16Ω load selected HPL 32Ω load selected Short link Short AVDD current measurement point DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 8 S/PDIF receiver +5V supply enabled S/PDIF receiver +5V supply disabled SPDIF word clock SPDIF bit clock Short links only if no sources are connected to J52 SPDIF data SPDIF master clock DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 9 XVDDD disconnected from VDDCP XVDDD connected to VDDDIO XVDDD disconnected from VDDDIO VDDCP connected to AVDD VDDCP disconnected from AVDD REG_+1.8V supply connected REG_+1.8V disconnected Table 1 Jumpers and Link Positions DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 10 The digital audio interface jumpers are set to receive a TOSLINK input and should be removed to accept other external clocks at J52. Figure 9 shows the extra links required to enable the onboard supplies. Figure 6 DA7210 Default Link locations DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 11 DA7210/11 USER MANUAL Figure 7 DA7211-00 Default Link Locations DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 12 DA7210/11 USER MANUAL Figure 8 DA7211-01 Default Link Locations DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 13 DA7210/11 USER MANUAL Figure 9 shows the locations of the jumper links when using the DA7210 with external power supplies to AVDD J66, VDDCP J17, XVDDD J62 and VDDDIO J64. The digital audio interface jumpers are set to receive a TOSLINK input and should be removed to accept other external I2S clocks at J52.

  • Page 14: Evaluation Board Features

    The USB interface control signals can be isolated from rest of the evaluation board by removing J51, J53 and J55 described in Table 1. Removing these jumpers will allow external signal access to the DA7210 control interface. The USB interface can also be used to supply the power supplies to the DUT on the evaluation board.
  • Page 15 DA7210/11 USER MANUAL Select Install from a list or specific location (Advanced) and press Next > Select Browse and locate the folder C:\Program Files\Dialog Semiconductor\Audio\DA7210_11 Rev x.x DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 16 DA7210/11 USER MANUAL Select dlgezusb.inf and press Next > Press Continue Anyway Select Browse and locate C:\Program Files\Dialog Semiconductor\Audio\DA7210_11 Rev x.x then press OK DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 17: Set-Up Files

    To add a delay in the file the register value is entered as Delay followed by the delay time require in milliseconds. The example in Figure 10 shows a 100ms delay added as the third entry. DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 18: Spreadsheet File

    0 then the register map bit will be highlighted in grey. This highlighting allows easy visual reference to the register changes from the default settings. DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 19 DA7210/11 USER MANUAL Figure 11 Spreadsheet Set-up File DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 20: Control Panels

    DA7210/11 USER MANUAL 4.3 Control Panels Run the DA7210/11 program by clicking the shortcut on the appropriate item in the Start menu. The best setting for the PC display size is 1024x768 pixels or above. Font size on the PC display should be Normal (95dpi).

  • Page 21: Register Map

    To select readback of an individual register click on the R/W bit of the required register and select R. To read the value press the submit button of the same row. DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
  • Page 22 Readback from Page 1 registers is limited, but individual register readback can be selected in the same way as Page 1 where available. DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 23: Gp Filters Register Map

    Figure 18 Filter Coefficients Set-up Panel An alternative ’RT Filters’ GUI is available that allows easy submission of any of the DAC or ADC filters paths present within the DA7210/11. This is contained on the installation DVD within the distribution kit.

  • Page 24: Volume Control Panel

    It is possible to change the headphone and OUT1 gain control registers as stereo pairs by simultaneously selecting the HPL follow HPR and OUT1L follow OUT1R buttons. Figure 19 Volume Control Panel DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 25: Rt Filters Gui

    DA7210/11 USER MANUAL 5 RT Filters GUI The RT filters GUI allows easy control of all the filter options within the DA7210/11 device through USB control. This includes general purpose filters, five-band equalisers and voice filters for ADC and DAC.
  • Page 26 Select I accept the License Agreement and press Next>> Press Next>> Allow the application to install. If Labview run-time files have not been installed on the target computer previously, the installation may take a few minutes. DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 27: Control Panels

    The RT Filters Rev x.x GUI can be used in conjunction with the DA7210_11 Register Control Software Rev x.x to set up the DA7210/11 device registers. In order to allow both interfaces to access the DA7210/11 simultaneously it is necessary to initialise the RT Filters GUI first before opening the DA7210_11 Register Control Software.
  • Page 28 Are Any GP Filter Enter Text File Paths Selected? Filter Response Press ‘SUBMIT Enter I2S PATHS’ Button Sample Rate Press ‘CREATE COEFFICIENTS’ Button Figure 20 RT Filter Setup Flowchart DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 29: Filter Setup Panel

     Lower Fc – lower frequency cut-off  Upper Fc – upper frequency cut-off  PB Ripple – passband ripple level  SB attenuation – sideband attenuation level DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 30: Coefficients Tab

    DA7210/11 are displayed on the Coefficients panel. Important: Be aware that if any of the general purpose filter paths are selected and no coefficients have been entered, then the DA7210/11 will be unable to pass the signal to the selected output. 5.4 Coefficients Tab The Generate Coefficients panel displays the forward and reverse coefficients for all of the general purpose filters and lists the register writes submitted to the DA7210/11.
  • Page 31 Output Coefficient Registers button and by selecting a valid output file path. The spreadsheet file must already exist for the register values to be output. The I2C device address and access speed can also be entered here. DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...

  • Page 32: Five-Band Equaliser And Voice Filter Panel

    These registers can be submitted real-time while the interface is running by pressing the Submit button. Figure 24 Five-band Equaliser and Voice Filter Panel DA7210/11 User Manual Rev 2.9 - January 2022 © 2022 Renesas Electronics...
