Renesas DA9062/i.MX 7 Quick Start Manual

Demonstration kit

DA9062 / i.MX 7 Demonstration Kit

Dear Customer,

Thank you for evaluating the Dialog DA9062 / i.MX 7 Demonstration Kit. This kit showcases the

Dialog DA9062 reference design for the i.MX 7 family of processors.

Quick Start Instructions

To start the board:

1. Connect the micro-USB cable on the top board (The 'CPU Board') to a USB port or a 5.0 V

supply. You might find that this cable has already been connected. Important: be careful

not to disturb or damage the LCD screen cable when inserting the micro-USB plug.

2. Turn on the supply. Both green LEDs should now be lit.

3. Press the small button nearest to the USB cable as shown in the figure below. Hold the

button for approximately 1.5 seconds.

4. When the button is released, the system should boot. The Android home-screen should be

displayed after a short while. This might take 2-3 minutes.

Optional

For a debug port:

5. Before starting the system, connect the second USB cable (on the lower 'IO Board') to a PC

USB port. This will create two COM ports.

6. Open a terminal program such as PuTTY or uCon. Connect to the lowest of the two new

COM ports. 115.2 kbits/s, 8 bits, parity = none, Stop bits = 1.

7. An OS root prompt can then be obtained by pressing ENTER.

User Manual

Revision 2.0

1 of 3

02-Mar-2022
