User Manual
DA9063/63L Evaluation Board
UM-PM-009
Abstract
This document describes the hardware and software used in Dialog Semiconductor to test and
evaluate the DA9063 power management controller.
The hardware solution is based on PCB numbered 44-179-176-05-A.
The software uses a PC operating Windows 2000/XP/Vista/Windows 7 ™ with a USB (1.1, 2.0 or
3.0) interface.
The software permits configuration of the device using one of the pre-defined templates, read and
operations to all control registers, and provides monitoring of device status.
The section 'Quick Start Tutorial' provides an abbreviated quick start guide with some practical
examples on how to run the evaluation kit.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Renesas DA9063
Summary of Contents for Renesas DA9063
-
Page 1: Abstract
Abstract This document describes the hardware and software used in Dialog Semiconductor to test and evaluate the DA9063 power management controller. The hardware solution is based on PCB numbered 44-179-176-05-A. The software uses a PC operating Windows 2000/XP/Vista/Windows 7 ™ with a USB (1.1, 2.0 or 3.0) interface. -
Page 2: Table Of Contents
– Register Text File ..................... 36 C Register Text File Format ....................36 - The OTP Programmed Sequence ................39 - Known Issues of DA9063 ..................40 - Evaluation Board Features ..................41 Motherboard USB Interface ....................41 Motherboard Control and IO signals ................... 42 Voltage Outputs (Motherboard) .................. -
Page 3: Figures
UM-PM-009 DA9063/63L Evaluation Board Figures Figure 1: Evaluation Board Assembly Diagram..................4 Figure 2: Initial Interface ........................9 Figure 3: Default Link Locations - Motherboard .................. 50 Figure 4: Default Link Locations - Daughter Board ................52 Tables Table 1: Hardware Links Description - Motherboard ................49 Table 2: Hardware Links Description - Daughter Board .............. -
Page 4: Introduction
The DA9063 Evaluation Boards have been produced to allow measurement, evaluation and programming of the DA9063 device. Note that the DA9063L is a variant of the DA9063 with slightly reduced functionality. This guide is also applicable for the DA9063L. The motherboard in... -
Page 5: Software Installation
UM-PM-009 DA9063/63L Evaluation Board Software Installation When the supplied media is inserted into the computer the installation should begin automatically. If the installation does not start automatically, run the program ‘setup.exe’. This will be found in the directory ‘Software’ on the media. An automated script will install the program on your PC. By default, the directory C:\Dialog Semiconductor\Power Management\DA9063_vxx will be used. - Page 6 UM-PM-009 DA9063/63L Evaluation Board When you plug in the USB cable Windows will detect the USB device. It will prompt for the drivers, which should be automatically located in the ‘Driver_PID-1011’ directory of the media. If this does not happen automatically you should open the Device Manager and get a list similar to the following: After double clicking on the unknown Dialog device, you should update the driver as shown below: By selecting the appropriate directory the driver should be found.
- Page 7 UM-PM-009 DA9063/63L Evaluation Board If installed correctly, the Dialog USB Driver should be listed on Device Manager as shown above. To uninstall the software please use the Windows ‘Add/Remove Programs’ function that can be found under ‘Start’->’Settings’->’Control Panel’. Application Note Revision 2.2...
-
Page 8: Hardware
UM-PM-009 DA9063/63L Evaluation Board Hardware The DA9063 Motherboard comprises the DA9063 device, a USB-I C bridge for communication with the device, and a few external active components to reduce the requirement for external equipment. Notes and limitations: ● When a socketed daughter board is plugged into the motherboard it is primarily intended to allow low power evaluation of the device (due to the high contact resistance of up to 50 mΩ). -
Page 9: Configuration Panel
DA9063/63L Evaluation Board Configuration Panel Run the DA9063 program by clicking the shortcut in the Start menu. The optimum setting for the PC display is 1024x768 pixels or above. Font size on the PC display should be Normal (95dpi). It is important to note that a display size other than the recommended setting may affect the way in which the panels appear. - Page 10 IRQ status and RTC at 1sec intervals, and load the RTC and Alarm register with current local time and date. Deselecting ‘Autostart’ allows more options for evaluating wakeup conditions, but is more complicated to use. The command button ‘Stop Program’ ends the DA9063 program. Application Note Revision 2.2 25-Feb-2022...
-
Page 11: Quick Start Tutorial Guide
UM-PM-009 DA9063/63L Evaluation Board Quick Start Tutorial Guide This section will go step by step through starting up the evaluation board and software to get the device up and running. It will also tackle the first steps of using a project template and making modifications. - Page 12 POWER-DOWN state, which is mapped into the OFF mode. At this point DA9063 is waiting for a wake up event, for example an nONKEY press. After the key press there is a second software download equivalent to the second OTP read, which is performed by pressing the Download button again.
- Page 13 UM-PM-009 DA9063/63L Evaluation Board An initial check is to monitor the output of the CORE supply. This should be enabled, and read approximately 1.38 V on a multimeter. Go to the ‘Bucks A’ tab and locate register BCORE1_CONT. The control BCORE1_EN should be green and showing enabled.
- Page 14 UM-PM-009 DA9063/63L Evaluation Board The new configuration will be loaded along with the first and the second software downloads, (equivalent to the OTP reads) in the power up sequence. If you have the ‘Autostart’ selected, a simple press on the ‘Start Device’ button will bring you automatically back to ACTIVE.
- Page 15 Powerdown mode. The second only sets the LDO and Buck voltages back to their default state. They may have been altered temporarily in the active state. DA9063 is a very powerful and flexible device, but that brings with it complexity and some logic puzzles. This software will evolve to assist.
-
Page 16: Modifying The Configuration File
UM-PM-009 DA9063/63L Evaluation Board Modifying the Configuration File The software is provided with a number of official variant files (DA9063_xxxx.ini), which should be suitable for most designs. Commercially viable customer variants will be considered. This procedure will describe making a change to one of these files by changing 2 parameters. - Page 17 UM-PM-009 DA9063/63L Evaluation Board Clicking the ‘LDO3’ button on the configuration panel opens a dialog box shown below. The alias name VGEN3_2V5 can be entered into the text box. When ‘Save’ in the dialog box is pressed the alias name change is written to the temporary working area.
- Page 18 UM-PM-009 DA9063/63L Evaluation Board Verify on the ‘Power Sequencer’ tab that LDO3_STEP (in Register ID_4_3) has changed to ‘Slot 8’ Select the tab ‘LDO’s 1-4’ Select menu item Settings=>Configuration Mode=>Config Mode starting point=>Current values. This is selected to prevent disturbing any changes made since the project load, and the Slot number of LDO3 has already been changed.
- Page 19 UM-PM-009 DA9063/63L Evaluation Board The slot number is 8, as shown in the Power Sequence window. AUTO_BOOT has been set to Disabled. As a final check, a Text Difference, produced by a text processing tool would highlight only the lines that begin with ‘LDO3_Alias’, ‘R16 =‘, ‘R132 =‘, ‘R171 =‘, and ‘GUID = ‘.
-
Page 20: Configuration Panel Details
UM-PM-009 DA9063/63L Evaluation Board Configuration Panel Details This page is used to select a suitable template file for the processor, allow modifications and store the modified file as a new project name. The aim of the configuration process is to arrive at a set of setup conditions which will be permanently programmed into the production device to allow a start-up configuration which is optimised for the processor and all associated peripheral devices. -
Page 21: Saving Configuration Items
UM-PM-009 DA9063/63L Evaluation Board Saving Configuration items A simple method has been provided for entering settings into the configuration file. It is recommended that the menu setting ‘Settings>Read Current Page Registers When Polling’ is turned off during this procedure. Press the menu item ‘Settings => Configuration Mode=> Config Mode starting point’, then select either ‘Current values’... -
Page 22: Power Sequence
UM-PM-009 DA9063/63L Evaluation Board Power Sequence Clicking on the Power Sequence button brings up the Sequence Control panel. This graph shows the relative timing of all the LDOs, Buck regulators and switches, their placement in the slots and the positions of the control markers. -
Page 23: Download
Power Commander is selected if the green light is on (provided jumper J28 is inserted). When DA9063 is waiting for a software download a red light on the Download button is illuminated as shown below: Any download will be made on the currently activated port of the device (HS2 I C or SPI Mode) overriding any programmed mode until Power Commander mode is exited. -
Page 24: Menu Items
UM-PM-009 DA9063/63L Evaluation Board Menu Items File> New Project file: Creates a blank project, not using a template, with all registers set to zero. File> Open Project file: Selects a project to open. Right clicking on a filename allows editing, copying pasting and such like. - Page 25 UM-PM-009 DA9063/63L Evaluation Board Settings> Read Current Page Registers When Polling: Reads all registers on the current tab once per second. Controls are updated with results of the read- back (default). Settings> Dialog Use> Test Pages: Allows viewing of internal test pages (only for Dialog Semiconductor use). A password is required for access.
- Page 26 UM-PM-009 DA9063/63L Evaluation Board Settings>History Log: This enables a popup panel which will log all manual and file activity. This panel is extremely useful in capturing operations for later scripting. This log is interactive. Comments can be added using ‘//’ either as separate lines or inline. Lines can be deleted or modified.
-
Page 27: Status And Controls
DA9063 please refer to the Datasheet. Start Device: If the ‘Start Device’ text in the button is red, DA9063 can be started by pressing the button. The button initialises the device (by pulsing ONKEY low, with J31 in its rightmost position) and automatically downloads the data. - Page 28 UM-PM-009 DA9063/63L Evaluation Board Read Chip ID: If a device is active, clicking this button will read the device ID. The panel will be updated with the device information. When a device is inactive, this information is not correct and clicking ‘Read Chip ID’...
- Page 29 UM-PM-009 DA9063/63L Evaluation Board SDA low: This LED indicates if the SDA line is stuck low. No Ack: This LED indicates no acknowledgement has been received from the I C bus when one was expected. Slave Address: Set slave address of the device. This affects all I C communications.
- Page 30 UM-PM-009 DA9063/63L Evaluation Board Synchronise Panel from Device: Reads all the register contents of the device and updates the panel to match. Synchronise Device from Panel: Writes all the device registers to match the panel. (Refresh operation). Reload Configuration: Resets registers to values specified in configuration file.
-
Page 31: Event Status Page
UM-PM-009 DA9063/63L Evaluation Board Event Status Page This page indicates the status of the device, wakeup and interrupt events and provides the ability to mask events from causing an interrupt. Note that masking an interrupt does not prevent the event from being flagged in the event register. It is assumed that the application software will gate events with the mask register. -
Page 32: Control
UM-PM-009 DA9063/63L Evaluation Board Control Pages The pages ‘Controls’, ‘Config’, ‘GPIO’, ‘LDO’s 1-4’, ‘LDO’s 5-8’, ‘LDO’s 9-11’, ‘BucksA’, ‘BucksB’, ‘Regulators’, ‘Power Sequencer’, ‘ADC’, ‘RTC’, ‘Customer OTP’ all have the same format. Each register cluster comprises a control with a mixture of Boolean toggle buttons, multi-value ring controls, or slide controls;... -
Page 33: Io Controls
UM-PM-009 DA9063/63L Evaluation Board IO Controls If the jumpers on J10 are fitted, the logic state of GPIO0 through GPIO13 can be set from the front panel. It is assumed that the corresponding GPIO is configured as a logic input; the software does not control this. -
Page 34: Troubleshooting
UM-PM-009 DA9063/63L Evaluation Board - Troubleshooting This section is an aid to resolving problems. Software Issues The USB device should automatically install without difficulty. Make sure that the installation finds and uses the driver contained on the supplied media. If the program is started before the USB Interface board is plugged in, the program will default to offline mode. -
Page 35: Hardware Issues
UM-PM-009 DA9063/63L Evaluation Board Hardware Issues Most hardware problems can be traced to incorrect jumper positions. Check carefully all jumper positions comparing them with the default positions shown in Figure Use the jumper table details and the board schematic as a guide to the jumper functions and locations. -
Page 36: Register Text File
UM-PM-009 DA9063/63L Evaluation Board – Register Text File The software includes the ability to save and load a text file containing hex codes representing the register addresses and data. This file is principally used to verify or test a customer’s own driver details. - Page 37 UM-PM-009 DA9063/63L Evaluation Board Example file contents: // Write to PMIC in 3 ways PMIC LDO10 0x61 WRITE LDO9 0x62 0xB0 0x39 0x61 // Read PMIC starting at LDO1 // for next 10 registers // Result is visible in Datalog window...
- Page 38 UM-PM-009 DA9063/63L Evaluation Board Application Note Revision 2.2 25-Feb-2022 CFR0014 38 of 54 © 2022 Renesas Electronics...
-
Page 39: The Otp Programmed Sequence
(TP pin grounded) these devices can be operated normally without Power Commander mode. The power up sequence of an OTP programmed device shipped in the DA9063 Evaluation Kit might be similar to the following example: The above oscilloscope plot is equivalent to viewing the sequence using the GUI Sequence Control panel (see below). -
Page 40: Known Issues Of Da9063
UM-PM-009 DA9063/63L Evaluation Board - Known Issues of DA9063 Please refer to the official errata document (if existent). Application Note Revision 2.2 25-Feb-2022 CFR0014 40 of 54 © 2022 Renesas Electronics... -
Page 41: Evaluation Board Features
The USB device is powered via the USB bus cable via a fixed 3.3 V regulator. The jumpers J1 and J2 are used to select between I C and SPI communication to DA9063. This has to be configured together with the IC_TYPE field of register CONFIG_A. -
Page 42: Motherboard Control And Io Signals
DA9063/63L Evaluation Board Motherboard Control and IO signals All of the Control and IO signals from the DA9063 appear on the headers pins shown above. These are the most useful monitor points for debug purposes. If required, a suitable connector can bring these signals to the system board for integrated development. - Page 43 UM-PM-009 DA9063/63L Evaluation Board The arrangement of the jumper links to the GPIO pins allows for a very flexible use of these resources. The jumpers may be inserted in J10 for USB control and monitor. They can be placed in J9 in the left hand location, connecting to VDD_IO via 100 kΩ...
-
Page 44: Voltage Outputs (Motherboard)
UM-PM-009 DA9063/63L Evaluation Board Voltage Outputs (Motherboard) The LDOs and Buck regulator outputs are accessible on the pairs of terminal pins shown above. They are arranged in pairs to allow meaningful measurements under load conditions. Each pin is connected separately to the regulator output, to a point as close as possible to the device pin. -
Page 45: Vddio Selection
Jumper J17 allows selection between the 3.3 V and 1.8 V (default) regulators. Consideration should be given that a VDDIO voltage may cause back powering of DA9063 from the VDDIO rail. In particular, if 3.3 V is used without the main VSYS supply, this may keep the digital core of DA9063 powered, thereby preventing a reset of the logic: this may lead to undesired operating modes. -
Page 46: Pc Mode And Otp Programming
UM-PM-009 DA9063/63L Evaluation Board PC Mode and OTP Programming The ‘TP select’ switch selects between normal and PC mode/OTP programming. If configured in the right hand position, the TP pin is grounded via a 10 kΩ pull down resistor, thereby selecting normal mode operation, with the register settings loaded from the programmed OTP. -
Page 47: Voltage Outputs (Daughter Board)
UM-PM-009 DA9063/63L Evaluation Board Voltage Outputs (Daughter Board) The left hand side of J19 allows the output voltage of the LDOs to be directly sensed on the daughter board. The right hand side of J19 is intended for higher current and direct connection of output load for each LDO. - Page 48 UM-PM-009 DA9063/63L Evaluation Board J20 and J21 of the daughter board allow for monitoring the output voltage and currents for each Buck regulator. The outer pins are intended for voltage sensing and the inner pins are designed for current handling.
-
Page 49: Hardware Links Description (Motherboard)
Function Applicable (Left/Down) SK to ATSAM3U SK to ATSAM3U SCL Selects between SPI and I C for DA9063’s 4-WIRE interface (Note 1) SPI_MCLK SI to ATSAM3U SI to ATSAM3U SDA Selects between SPI and I C for DA9063’s 4-WIRE interface... -
Page 50: Figure 3: Default Link Locations - Motherboard
A wired connection from CHG_WAKE to ground may be needed if CHG_WAKE is not used in the application as a floating level may cause wake up events that may unintentionally cause DA9063 to move into the ACTIVE state. -
Page 51: Table 2: Hardware Links Description - Daughter Board
UM-PM-009 DA9063/63L Evaluation Board Table 2: Hardware Links Description - Daughter Board Link Position 1 (Right/Up) Position 2 - Where Function Applicable (Left/Down) Connects nRESET via 100 kΩ pull up NRSET VDDIO2 resistor to VDDIO2 Connects nIRQ via 100 kΩ pull up... -
Page 52: Figure 4: Default Link Locations - Daughter Board
UM-PM-009 DA9063/63L Evaluation Board Figure 4 Shows the Default Locations of All the Jumper Links. Figure 4: Default Link Locations - Daughter Board Application Note Revision 2.2 25-Feb-2022 CFR0014 52 of 54 © 2022 Renesas Electronics... -
Page 53: Revision History
UM-PM-009 DA9063/63L Evaluation Board Revision History Revision Date Description 05-Mar-2013 Initial version. 15-Oct-2015 Update to new corporate template, correction of typographical errors 18-May-2017 Added note about the DA9063L 25-Feb-2022 File was rebranded with new logo, copyright and disclaimer Application Note Revision 2.2... - Page 54 UM-PM-009 DA9063/63L Evaluation Board Status Definitions Status Definition DRAFT The content of this document is under review and subject to formal approval, which may result in modifications or additions. APPROVED The content of this document has been approved for publication.
